Vehicle care187
2. Press both clips together andwithdraw the bulb socket from theheadlamp housing.
3. Remove the bulb from the socket by pulling.
4. Replace and insert new bulb into socket.
5. Insert the bulb socket into the headlamp housing and turn
clockwise.
Sidelight/daytime running light
with LEDs Sidelights and daytime running lights
consist of LEDs which cannot be
changed. Consult a workshop in case
of a defective LED.
Xenon headlights9 Danger
Xenon headlights work under
extremely high electrical voltage.
Do not touch. Have bulbs replaced by a workshop.
Sidelight/daytime running lights are
designed as LEDs and cannot be
changed.
Bulbs for corner lighting can be
changed.
Front turn signal lights 3 188.
Corner lighting
1. Rotate the cap (3) anticlockwise
and remove it.

194Vehicle careEngine compartment fuse
box
The fuse box is in the front left of the
engine compartment.
Disengage the cover and fold it
upwards until it stops. Remove the
cover vertically upwards.
No.Circuit1Trailer interface module2Exterior mirror switch3Battery sensor4Chassis control module5ABS6Daytime running light left7–8Transmission control module9Body control module10Headlamp levelling/TPMS/
Trailer interface module11Rear wiper12Window defog13Daytime running light right14Mirror defog15–

Vehicle care195
No.Circuit16Chassis control module/Pump
kit17Interior mirror18Engine control module19Fuel pump20–21Injection coil22–23Injection system24Washer system25Lighting system26Engine control module27Heater shut off valve28Engine control module29Engine control module30Engine control module31Left headlampNo.Circuit32Right headlamp33Engine control module34Horn35Clutch36Front fog lights
