212Vehicle careVehicle tools
Tools
Vehicles without spare wheel
The tools are located together with
the towing eye in the load
compartment below the floor cover.
The tools and the towing eye are
located on the right side of the load compartment behind a cover.
On VXR or LPG version or versions
with rear carrier system, the tools are located together with the towing eye
on the right side of the load
compartment, behind a cover.
Vehicles with spare wheel
The jack, wheel bolt wrench and
some tools are located on the right
side of the load compartment, behind a cover 3 69.

228Vehicle care
Front arm position of the lifting
platform at the underbody.
Spare wheel If mounting a spare wheel, which is
different from the other wheels, this
wheel might be classified as a
temporary spare wheel and the
corresponding speed limits apply,
even though no label indicates this.
Seek the assistance of a workshop to
check the applicable speed limit.
The spare wheel has a steel rim.
Caution
The use of a spare wheel that is smaller than the other wheels or in combination with winter tyres
could affect driveability. Have the defective tyre replaced as soon as
possible.
3-door/5-door hatchback
The spare wheel is located in the load
compartment beneath the floor
covering. It is secured with a wing nut.
Fitting a double load-bay floor in this
case in the upper position 3 69.
To remove, unscrew wing nut, lift
spare wheel, move to a vertical
position and remove from above.
When stowing the replaced wheel or
the temporary spare wheel back in
the spare wheel well, always secure
with the wing nut.Delivery van
Remove load floor.
The spare wheel is screwed down
together with the floor cover.
Unscrew wing nut and lift load cover.

Vehicle care229
Remove spacer above the spare
wheel, lift the wheel, move to a
vertical position and remove from
above.
When stowing the replaced wheel or
the temporary spare wheel back in
the spare wheel well, always insert
the adapter and secure the load cover with the wing nut.
Depending on the defective replaced
wheel, the spacer can be omitted if
necessary, or the wheel can be bolted down without the floor cover.
Temporary spare wheelCaution
The use of the temporary spare
wheel could affect driveability.
Have the defective tyre renewed
or repaired as soon as possible.
Only mount one temporary spare
wheel. The permissible maximum
speed on the label on the temporary
spare wheel is only valid for the
factory-fitted tyre size.
If your vehicle gets a flat tyre on the
rear while towing another vehicle,
mount the temporary spare wheel in
the front and the full size tyre in the
rear.
Tyre chains 3 220.
Spare wheel with directional tyre If possible, fit directional tyres such
that they roll in the direction of travel.
The rolling direction is indicated by a
symbol (e.g. an arrow) on the
sidewall.
The following applies to tyres fitted
opposing the rolling direction:
● Driveability may be affected. Have the defective tyre renewed
or repaired as soon as possible
and fit it instead of the spare
wheel.
● Drive particularly carefully on wet
and snow-covered road
surfaces.

Vehicle care2313. Connect the black lead to thenegative terminal of the booster
vehicle battery.
4. Connect the other end of the black
lead to a vehicle grounding point,
such as the engine block or an
engine mounting bolt. Connect as far away from the discharged
vehicle battery as possible,
however at least 60 cm.
Route the leads so that they cannot
catch on rotating parts in the engine
compartment.
To start the engine: 1. Start the engine of the vehicle providing the jump.
2. After five minutes, start the other engine. Start attempts should be
made for no longer than
15 seconds at an interval of one
minute.
3. Allow both engines to idle for approx. three minutes with the
leads connected.4. Switch on electrical consumers (e.g. headlights, heated rear
window) of the vehicle receiving
the jump start.
5. Reverse above sequence exactly when removing leads.Towing
Towing the vehicle
Insert a screwdriver in the slot at the
lower part of the cap. Release the cap
by carefully moving the screwdriver
downwards.
The towing eye is stowed with the
vehicle tools 3 212.

232Vehicle care
Screw in the towing eye as far as it will
go until it stops in a horizontal
position.
Attach a tow rope – or better still a tow
rod – to the towing eye.
The towing eye must only be used for towing and not for recovering the
vehicle.
Switch on ignition to release steering
wheel lock and to permit operation of
brake lights, horn and windscreen
wiper.
Switch the selector lever to neutral.
Release the parking brake.
Caution
Drive slowly. Do not drive jerkily.
Excessive tractive force can
damage the vehicle.
When the engine is not running,
considerably more force is needed to
brake and steer.
To prevent the entry of exhaust gases from the towing vehicle, switch on the
air recirculation and close the
windows.
Vehicles with automatic transmission: the vehicle must be towed facing
forwards, not faster than 50 mph nor
further than 60 miles. In all other
cases and when the transmission is
defective, the front axle must be
raised off the ground.
Vehicles with manual transmission
automated: the vehicle must only be
towed facing forwards with the front
axle raised off the ground.
Seek the assistance of a workshop. After towing, unscrew the towing eye.
Insert cap at the top and engage
downwards.
Towing another vehicle
Insert a screwdriver in the slot at the
lower bend of the cap. Release the
cap by carefully moving the
screwdriver downwards.
The towing eye is stowed with the
vehicle tools 3 212.

Vehicle care233
Screw in the towing eye as far as it will
go until it stops in a horizontal
position.
The lashing eye at the rear
underneath the vehicle must never be used as a towing eye.
Attach a tow rope – or even better a
tow bar – to the towing eye.
The towing eye must only be used for
towing and not for recovering a
vehicle.
Caution
Drive slowly. Do not drive jerkily.
Excessive tractive force can
damage the vehicle.
After towing, unscrew the towing eye.
Insert cap at the top and engage
downwards.
Appearance care
Exterior care Locks
The locks are lubricated at the factory using a high quality lock cylinder
grease. Use a de-icing agent only
when absolutely necessary, as this
has a degreasing effect and impairs
lock function. After using a de-icing
agent, have the locks regreased by a workshop.
Washing
The paintwork of your vehicle is
exposed to environmental influences. Wash and wax your vehicle regularly.
When using automatic vehicle
washes, select a programme that
includes waxing. Restrictions for
filmed or matt painted body parts or
decor tapes, see "Polishing and
waxing".
Bird droppings, dead insects, resin,
pollen and the like should be cleaned
off immediately, as they contain
aggressive constituents which can
cause paint damage.

Vehicle care235Remove dirt residues from smearing
wiper blades by using a soft cloth and
window cleaner. Also make sure to
remove any residues such as wax,
insect residues and similar from the
window.
Ice residues, pollution and continuous wiping on dry windows will damage or
even destroy the wiper blades.
Sunroof Never clean with solvents or abrasive
agents, fuels, aggressive media (e.g.
paint cleaner, acetone-containing solutions etc.), acidic or highly
alkaline media or abrasive pads. Do
not apply wax or polishing agents to
the sunroof.
Wheels and tyres Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.Paintwork damage
Rectify minor paintwork damage with
a touch-up pen before rust forms.
Have more extensive damage or rust areas repaired by a workshop.
Underbody
Some areas of the vehicle underbody
have a PVC undercoating while other critical areas have a durable
protective wax coating.
After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.Liquid gas system9 Danger
Liquid gas is heavier than air and
can collect in sink points.
Take care when performing work
at the underbody in a pit.
For painting work and when using a
drying booth at a temperature above
60 °C, the liquid gas tank must be
removed.
Do not make any modifications to the
liquid gas system.
Towing equipment
Do not clean the coupling ball bar with a steam-jet or high-pressure jet
cleaner.
Rear carrier system Clean the rear carrier system with a
steam-jet or high-pressure jet cleaner
at least once a year.
Operate the rear carrier system
periodically if not in regular use, in
particular during winter.

265Control indicators.......................... 88
Control of the vehicle .................135
Controls ........................................ 75
Convex shape .............................. 28
Coolant and antifreeze ...............238
Corner lighting ............................ 117
Cruise control ...................... 96, 155
Cupholders .................................. 56
Curtain airbag system .................. 48
D Danger, Warnings and Cautions ...4
Daytime running lights ...............117
Declaration of conformity ............256
Diesel fuel system bleeding .......198
Diesel particle filter ...............94, 141
Door open .................................... 96
Doors ............................................ 25
Driver assistance systems ..........155
Driver Information Centre .............97
Driving characteristics and towing tips .............................. 185
Driving hints ................................ 135
E Easy entry..................................... 38
Electric adjustment ......................28
Electrical system......................... 207
Electronic climate control system 127
Electronic driving programmes . ........................................ 144, 149Electronic Stability Control.......... 153
Electronic Stability Control and Traction Control system ............94
Electronic Stability Control off....... 94
End-of-life vehicle recovery .......192
Engine compartment fuse box ...208
Engine coolant ........................... 194
Engine coolant temperature gauge ....................................... 86
Engine data ............................... 246
Engine exhaust .......................... 141
Engine identification ...................242
Engine oil ................... 193, 238, 243
Engine oil pressure ......................95
Entry lighting .............................. 122
Event data recorders ..................262
Exit lighting ................................ 122
Exterior care .............................. 233
Exterior light ................................. 96
Exterior lighting ....................12, 114
Exterior mirrors ............................. 28
F
Fault ................................... 145, 149
First aid ......................................... 71
First aid kit ................................... 71
Fixed air vents ........................... 132
Flex-Fix system ............................ 58
Fog light ....................................... 96
Fog lights ................................... 202Folding mirrors ............................. 29
Following distance indication ......161
Forward collision alert................. 158
Front airbag system .....................46
Front fog lights ........................... 119
Front seats.................................... 36
Front storage ................................ 57
Front turn signal lights ...............203
Fuel............................................. 179
Fuel consumption - CO 2-
Emissions ............................... 184
Fuel for diesel engines ..............180
Fuel for liquid gas operation .......180
Fuel for petrol engines ...............179
Fuel gauge ................................... 84 Fuel selector ................................ 85
Fuses ......................................... 207
G Gauges ......................................... 83
Gear shifting ................................. 93
General information ...................185
Glovebox ..................................... 56
Graphic-Info-Display ...................102
H Halogen headlights ....................199
Hand brake ......................... 150, 151
Hazard warning flashers ............118
Headlight flash ........................... 116
Headlight range adjustment ......116

267RRadio Frequency Identification (RFID) ..................................... 262
Radio remote control ...................21
REACH ....................................... 259
Reading lights ............................ 122
Rear carrier system ......................58
Rear floor storage cover ..............69
Rear fog light ....................... 96, 119
Rear view camera ...................... 173
Rear window wiper/washer .......... 77 Recommended fluids and lubricants ........................ 238, 243
Reduced engine power ................95
Refuelling ................................... 181
Registered trademarks ...............261
Retained power off .....................136
Reversing lights .........................120
Ride control systems ..................152
Roof .............................................. 33
Roof load ...................................... 72
Roof rack ..................................... 71
S Safety belts ................................... 40
Seat adjustment ....................... 7, 37 Seat belt ........................................ 8
Seat belt reminder .......................91
Seat belts ..................................... 40
Seat folding .................................. 38Seat heating ................................. 39
Seat position ................................ 36
Selector lever ..................... 143, 147
Service ....................................... 133
Service display ............................ 87
Service information ....................237
Service vehicle soon .................... 92
Side airbag system ......................47
Side blind spot alert ....................172
Sidelights .................................... 114
Side turn signal lights ................205
Software acknowledgement .......259
Spare wheel ............................... 228
Speed limiter......................... 96, 157
Speedometer ............................... 83
Starting and operating ................135
Starting off ................................... 17
Starting the engine ............136, 147
Steering wheel adjustment ......9, 75
Steering wheel controls ...............75
Stop-start system........................ 137
Storage ......................................... 56
Storage compartments .................56
Sunroof ........................................ 33
Sun visors .................................... 32
Symbols ......................................... 4
T
Tachometer ................................. 84
Tail lights ................................... 203Three-point seat belt .................... 41
Tools .......................................... 212
Tow bar....................................... 185
Towing ................................ 185, 231
Towing another vehicle .............232
Towing equipment .....................186
Towing the vehicle .....................231
Traction Control system ............. 152
Traction Control system off........... 94
Traffic sign assistant .............96, 175
Trailer coupling ........................... 185
Trailer stability assist .................189
Trailer towing ............................. 185
Transmission ............................... 16
Transmission display .........142, 147
Tread depth ............................... 219
Trip odometer .............................. 83
Turn and lane-change signals ...119
Turn signal ................................... 90
Tyre chains ................................ 220
Tyre designations ......................213
Tyre pressure ............................ 213
Tyre pressure monitoring system ............................... 95, 215
Tyre pressures ........................... 254
Tyre repair kit ............................. 220
U
Ultrasonic parking assist ...... 94, 161
Underseat storage .......................58
