Instruments and controls87Overdued service is indicated by a
message in the Driver Information
Centre which indicates the overdued
distance. F flashes and then lights up
permanently until service is executed.
Reset of service interval
After each service, the service
indicator must be reset to ensure
proper functionality. It is
recommended to seek the assistance of a workshop.
If service is executed by yourself,
operate as following:
● switch off ignition
● press and hold button M or
CHECK
● switch on ignition; the distance indication begins a countdown
● when the display indicates =0,
release the button. Symbol F
disappearsRetrieving service information
To retrieve the status of the service
information at any time press button
M or CHECK . The service
information is displayed for a few
seconds.
Service information 3 225.
Control indicators The control indicators described are
not present in all vehicles. The
description applies to all instrument
versions. Depending on the
equipment, the position of the control indicators may vary. When the
ignition is switched on, most control
indicators will illuminate briefly as a
functionality test.
The control indicator colours mean:red:danger, important reminderyellow:warning, information, faultgreen:confirmation of activationblue:confirmation of activationwhite:confirmation of activation
See all control indicators on different
instrument clusters 3 79.
Turn lights
O illuminates or flashes green.
Illuminates briefly The parking lights are switched on.
Flashes
A turn light or the hazard warning
flashers are activated.
Rapid flashing: failure of a turn light or associated fuse, failure of turn light on
trailer.
Bulb replacement 3 192, Fuses
3 200.
Turn lights 3 112.
Seat belt reminder
Seat belt reminder on all seats
X illuminates or flashes red in the
instrument cluster together with the
indication in the roof console for each
seat belt.

Vehicle care185Vehicle careGeneral Information...................185
Accessories and vehicle modifications .......................... 185
Vehicle storage ........................186
End-of-life vehicle recovery .....186
Vehicle checks ........................... 187
Performing work ......................187
Bonnet ..................................... 187
Engine oil ................................. 188
Engine coolant ......................... 189
Washer fluid ............................ 189
Brakes ..................................... 190
Brake fluid ............................... 190
Vehicle battery ......................... 190
Diesel fuel system bleeding .....191
Wiper blade replacement ........192
Bulb replacement .......................192
Halogen headlights ..................192
LED headlights ........................ 195
Fog lights ................................. 195
Tail lights ................................. 195
Side turn lights ......................... 199
Number plate light ...................200
Interior lights ............................ 200
Instrument panel illumination ...200Electrical system ........................200
Fuses ....................................... 200
Engine compartment fuse box . 201
Instrument panel fuse box .......202
Vehicle tools .............................. 205
Tools ........................................ 205
Wheels and tyres .......................205
Winter tyres ............................. 205
Tyre designations ....................206
Tyre pressure .......................... 206
Tyre deflation detection system .................................... 207
Tread depth ............................. 208
Changing tyre and wheel size . 209
Wheel covers ........................... 209
Tyre chains .............................. 209
Tyre repair kit .......................... 210
Wheel changing .......................213
Spare wheel ............................ 214
Jump starting ............................. 218
Towing ....................................... 219
Towing the vehicle ...................219
Towing another vehicle ...........220
Appearance care .......................221
Exterior care ............................ 221
Interior care ............................. 223General Information
Accessories and vehiclemodifications
We recommend the use of genuine
parts and accessories and factory approved parts specific for your
vehicle type. We cannot assess or guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control
units) may invalidate the warranty
offered by Vauxhall. Furthermore,
such changes may affect driver
assistance systems, may impact fuel
consumption, CO 2 emissions and
other emissions of the vehicle and
cause the vehicle to no longer
conform to the operating permit,
impacting the validity of your vehicle
registration.

200Vehicle care4. Insert bulb holder and turnclockwise.
5. Insert left end of the lamp, slide to
the left and insert right end.
Number plate light
The number plate light is designed as
LEDs and can not be changed. In
case of defective LEDs, have them
replaced by a workshop.
Interior lights
Courtesy light, reading lights
Have bulbs replaced by a workshop.
Load compartment light
Have bulbs replaced by a workshop.
Instrument panel illumination
Have bulbs replaced by a workshop.Electrical system
Fuses Data on the replacement fuse must
match the data on the defective fuse.
There are three fuse boxes in the
vehicle:
● engine compartment
● instrument panel
Before replacing a fuse, turn off the
respective switch and the ignition.
A blown fuse can be recognised by its melted wire.Caution
Do not replace the fuse until the
cause of the fault has been
remedied.
Some functions are protected by
several fuses.
Fuses may also be inserted without
existence of a function.
Fuse extractor
A fuse extractor may be located in the
fuse box in the engine compartment.

202Vehicle careNo.Circuit10Engine control11Engine control12Engine cooling unit13Body control module14Intelligent battery sensor15–16Front fog light17–18High beam right19High beam left20Engine control fuel pump21Starter22–23Starter24Trailer hitch25Instrument panel fuse box26Transmission control moduleNo.Circuit27Body control module28Engine control module29Front wiper30Body control module
After having changed defective fuses,
close the fuse box cover and press
until it engages.
If the fuse box cover is not closed
correctly, malfunction may occur.
Instrument panel fuse box
Fuse box on the left side of the
instrument panel
In right-hand drive vehicles, the fuse
box is located behind a cover in the
glovebox. Open the glovebox and
remove the cover.

253Clock............................................. 76
Control indicators.......................... 87
Control of the vehicle .................130
Controls ........................................ 72
Convex shape .............................. 33
Coolant and antifreeze ...............227
Cruise control ...................... 93, 149
Cupholders .................................. 62
Curtain airbag system .................. 54
D Danger, Warnings and Cautions ...4
Daytime running lights ...............110
Declaration of conformity ............242
DEF ............................................ 139
Deflation detection system ...........91
Diesel exhaust fluid ....................139
Diesel fuel system bleeding .......191
Diesel particle filter ...............91, 138
Door open .................................... 93
Doors ............................................ 29
Driver alert .................................. 174
Driver assistance systems ..........149
Driver Information Centre .............93
Driving characteristics and towing tips .............................. 181
Driving hints ................................ 130
E
Electric adjustment ......................33
Electrical system......................... 200Electronic climate control system 121
Electronic driving programmes ..144
Electronic key system ...................22
Electronic Stability Control and Traction Control system ....90, 148
Electronic Stability Control and Traction Control system off .......90
End-of-life vehicle recovery .......186
Engine compartment fuse box ...201
Engine coolant ........................... 189
Engine coolant temperature ........91
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 234
Engine exhaust .......................... 138
Engine identification ...................230
Engine oil ................... 188, 227, 231
Engine oil level monitor ................86
Engine oil pressure ......................91
Entry lighting .............................. 115
Event data recorders ..................248
Exit lighting ................................ 115
Exterior care .............................. 221
Exterior light ................................. 92
Exterior lighting ....................12, 108
Exterior mirrors ............................. 33
F Fault ........................................... 144
First aid ......................................... 68First aid kit ................................... 68
Fixed air vents ........................... 127
Fog light ....................................... 92
Fog lights ................................... 195
Folding mirrors ............................. 34
Forward collision alert................. 154
Front airbag system .....................53
Front fog lights ........................... 112
Front pedestrian protection ........158
Front seats.................................... 42
Fuel............................................. 175
Fuel for diesel engines ..............175
Fuel for liquid gas operation .......176
Fuel for petrol engines ...............175
Fuel gauge ................................... 84
Fuel selector ................................ 84
Fuses ......................................... 200
G Gauges ......................................... 83
Gear shifting ................................. 90
General information ...................180
Glass panel .................................. 39
Glovebox ..................................... 62
H
Halogen headlights ....................192
Hand brake ......................... 146, 147
Hazard warning flashers ............111
Headlight flash ........................... 109
Headlight range adjustment ......110
