stop start VAUXHALL CROSSLAND X 2018 Owner's Guide

186Vehicle careVehicle checks
Performing work9 Warning
Only perform engine compartment
checks when the ignition is off.
The cooling fan may start
operating even if the ignition is off.
9 Danger
The ignition system uses
extremely high voltage. Do not
touch.
Bonnet
Opening
Open the driver's door.
Pull the release lever and return it to
its original position.
Move the safety catch sideways to the
left vehicle side and open the bonnet.
The bonnet is held open
automatically.
If the bonnet is opened during an
Autostop, the engine will be restarted automatically for safety reasons.
Stop-start system 3 137.
Closing Lower the bonnet and let it fall into the
latch from a low height (20-25 cm).
Check that the bonnet is engaged.

190Vehicle careAfter having reconnected the battery
of a vehicle equipped with an anti-
theft alarm system, wait 10 minutes
until you start the engine.
Replacing the vehicle battery Notice
Any deviation from the instructions
given in this section may lead to
temporary deactivation or
disturbance of the stop-start system.
When the vehicle battery is being replaced, please ensure that there
are no open ventilation holes in the
vicinity of the positive terminal. If a
ventilation hole is open in this area, it
must be closed off with a dummy cap, and the ventilation in the vicinity of the
negative terminal must be opened.
Ensure that the battery is always
replaced by the same type of battery.
The vehicle battery has to be
replaced by a workshop.
Stop-start system 3 137.Charging the vehicle battery9 Warning
On vehicles with stop-start
system, ensure that the charging potential does not exceed
14.6 volts when using a battery
charger. Otherwise the vehicle
battery might be damaged.
Jump starting 3 216.
Warning label
Meaning of symbols: ● No sparks, naked flames or smoking.
● Always shield eyes. Explosive gases can cause blindness or
injury.
● Keep the vehicle battery out of reach of children.
● The vehicle battery contains sulphuric acid which could cause
blindness or serious burn
injuries.
● See the Owner's Manual for further information.
● Explosive gas may be present in the vicinity of the vehicle battery.
Diesel fuel system bleeding If the tank has been run dry, the diesel
fuel system must be bled. Switch on
the ignition three times for
15 seconds at a time. Then crank the
engine for a maximum of 40 seconds. Repeat this process after
no less than five seconds. If the
engine fails to start, seek the
assistance of a workshop.

206Vehicle careFor the tyres approved for your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.
The driver is responsible for correct
adjustment of tyre pressure.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
9 Warning
For specific tyres the
recommended tyre pressure as
shown in the tyre pressure table may exceed the maximum tyre
pressure as indicated on the tyre.
Never exceed the maximum tyre
pressure as indicated on the tyre.
Temperature dependency
The tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase. Tyre pressure
values provided on the tyre
information label and tyre pressure
chart are valid for cold tyres, which means at 20 °C.
The pressure increases by nearly
1.5 psi for a 10 °C temperature
increase. This must be considered
when warm tyres are checked.
Tyre deflation detectionsystem
The tyre deflation detection system
continually checks the rotation speed
of all four wheels and warns on low
tyre pressure condition once vehicle
is driving. This is achieved by
comparing tyre rolling circumference
with reference values.
If a tyre loses pressure the control
indicator w illuminates and a warning
message is displayed in the Driver Information Centre.In this case reduce speed, avoid
sharp cornering and strong braking.
Stop at next safe opportunity and
check tyre pressure.
Control indicator w 3 93.
After adjusting tyre pressure initialise
system to extinguish the control
indicator and restart system.Caution
Deflation detection system warns
just about low tyre pressure
condition and does not replace
regular tyre maintenance by the
driver.
In case of a system malfunction a
message is displayed in the Driver
Information Centre. Set correct tyre
pressure and reinitialise system. If the
failure continues to be displayed,
contact a workshop. The system is
inoperable when ABS or ESC has a
malfunction or a temporary spare
wheel is used. Once the road tyre has
been refitted, check the tyre pressure with cold tyres and initialise the
system.

Service and maintenance223Service and
maintenanceGeneral information ...................223
Service information ..................223
Recommended fluids, lubricants and parts .................................... 225
Recommended fluids and lubricants ................................ 225General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Severe operating conditions exist if one or more of the following
circumstances occur frequently: Cold
starting, stop and go operation, e.g.
for taxis and police vehicles, trailer
operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,
driving at high altitude and large
variations of temperature.
Under these severe operating
conditions, certain service work may
be required more frequently than the
regular service interval indicated inthe service display. Contact a
workshop for customised service
schedules.
Service display 3 88.
Service intervals - country group 1 Maintenance of your vehicle is
required every 16,000 miles or after
one year, whichever occurs first, unless otherwise indicated in theservice display.
These service intervals are valid for
the following countries:
Andorra, Austria, Belgium, Cyprus,
Denmark, Finland, France, Germany, Greece, Greenland, Iceland, Ireland,
Italy, Liechtenstein, Luxembourg,
Malta, Monaco, Netherlands,
Norway, Portugal, San Marino, Spain,
Sweden, Switzerland, United
Kingdom.
Service intervals - country group 2
Maintenance of your vehicle
equipped with engine EB2F, EB2DT
or EB2DTS is required every
10,000 miles or after one year,
whichever occurs first, unless

251Preheating ................................... 93
Puncture ..................................... 212
Q Quickheat ................................... 127
R Radio Frequency Identification (RFID) ..................................... 247
Radio remote control ...................22
Rain sensor .................................. 94
REACH ....................................... 243
Reading lights ............................ 116
Rear floor storage cover ..............68
Rear fog light ....................... 94, 115
Rear seats .................................... 47
Rear view camera ...................... 172
Rear window wiper/washer .......... 77
Recommended fluids and lubricants ........................ 225, 229
Refuelling ................................... 178
Registered trademarks ...............246
Reversing lights .........................115
Ride control systems ..................149
Roof .............................................. 40
Roof load ...................................... 71
Roof rack ..................................... 71
S
Safety belts ................................... 48
Seat adjustment ....................... 7, 44Seat belt ........................................ 8
Seat belt reminder .......................89
Seat belts ..................................... 48 Seat heating ................................. 46
Seat position ................................ 43
Selective catalytic reduction .......141
Selector lever ............................. 144
Service ............................... 130, 223
Service display ............................ 88
Service information ....................223
Service vehicle soon .................... 91
Side airbag system ......................54
Side blind spot alert ....................168
Sidelights .................................... 110
Side turn signal lights ................198
Software acknowledgement .......243
Software update ......................... 245
Spare wheel ............................... 214
Speed limiter......................... 95, 153
Speedometer ............................... 84
Starting and operating ................132
Starting off ................................... 17
Starting the engine ....................135
Steering ...................................... 132
Steering wheel adjustment ......9, 74
Steering wheel controls ...............74
Stop engine .................................. 91
Stop-start system........................ 137
Storage ......................................... 64
Storage compartments .................64Sunvisor lights ........................... 117
Sun visors .................................... 40
Symbols ......................................... 4
System check ............................... 91
T
Tachometer ................................. 85
Tail lights ................................... 194
Three-point seat belt .................... 49
Tools .......................................... 204
Tow bar....................................... 180 Towing ................................ 180, 217
Towing another vehicle .............218
Towing equipment .....................181
Towing the vehicle .....................217
Traffic sign assistant .....................95
Trailer coupling ........................... 180
Trailer towing ............................. 180
Transmission ............................... 16
Transmission display .................144
Tread depth ............................... 207
Trip odometer .............................. 85
Turn and lane-change signals ...114
Turn signal ................................... 89
Tyre chains ................................ 208
Tyre deflation detection system . 206
Tyre designations ......................205
Tyre pressure ............................ 205
Tyre pressures ........................... 238
Tyre repair kit ............................. 209
