VAUXHALL CROSSLAND X 2019.75 Owner's Manual

Technical data219Technical dataVehicle identification..................219
Vehicle identification number ..219
Identification plate ...................219
Engine identification ................220
Vehicle data ............................... 221
Recommended fluids and lubricants ................................ 221
Engine data ............................. 223
Performance ............................ 224
Vehicle dimensions .................226
Capacities ................................ 227
Tyre pressures ........................ 228Vehicle identification
Vehicle identificationnumber
The vehicle identification number is
stamped on the identification plate
and on the floor pan, under the floor
covering, visible under a cover.
The vehicle identification number
may be embossed on the instrument
panel, visible through the windscreen, or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

220Technical dataInformation on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weight
rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight.
Vehicle's kerb weight depends on the
specification of the vehicle, e.g.
optional equipment and accessories. Refer to the EEC Certificate of
Conformity provided with your vehicle
or other national registration
documents.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables use the
engine identifier code. The engine
data table additionally shows the
engineering code.
Engine data 3 223.
To identify the respective engine,
refer to the EEC Certificate of
Conformity provided with this vehicle
or other national registration
documents.
The Certificate of Conformity shows the engine identifier code, other
national publications may show the
engineering code. Check piston
displacement and engine power to
identify the respective engine.

Technical data221Vehicle data
Recommended fluids and lubricants
Required engine oil quality Country groups 3 213
Countries included in country groups 1 to 3EB2FA
EB2ADT
EB2ADTS
EP6FADTXD
DV5RC
DV5RD
DV5REEP6FDTM
EB2DT
EC5F
DW10FC
DV6D
DV6FD
DV6FEVauxhall Original engine oilB71 2010 / B71 2312B71 2312
Engine EC5F: B71 2290, B71 2296 or B71 300 may also be used.
Countries included in country group 4
all enginesVauxhall Original engine oilB71 2302 / B71 2297
Engine EC5F: B71 2296 or B71 300 may also be used.

222Technical dataCountries included in country group 5all enginesVauxhall Original engine oilB71 2297
Engine oil viscosity gradesCountry groups 3 213
B71 2010B71 2312B71 2302B71 2297Engine oil viscosity gradeSAE 0W-20SAE 0W-30SAE 0W-30SAE 5W-30

Technical data223Engine dataEngine identifier codeD12xE / F12xED12xHL / F12xHLD12xHT / F12xHTSales designation1.21.2 Turbo1.2 TurboEngineering codeEB2FAEB2DT / EB2ADTEB2ADTSPiston displacement [cm3
]119911991199Engine power [kW]618196at rpm575055005500Torque [Nm]118205230at rpm275017501750Fuel typePetrolPetrolPetrolOctane rating RON 1)2)recommended959595possible989898possible–––1)
A country-specific label at the fuel filler flap can supersede the engine-specific requirement.
2) In certain countries, the use of a particular fuel, e.g. a specific octane rating, may be required to ensure proper engine operation.

224Technical data
Engine identifier code
D15DTD15DTHA16DT
Z16DTSales designation1.51.51.6Engineering codeDV5RDDV5RCDV6DPiston displacement [cm 3
]149914991560Engine power [kW]758868at rpm350037504000Torque [Nm]250300230at rpm175017501750Fuel typeDieselDieselDiesel
Performance
EngineD12xE / F12xED12xHL / F12xHLD12xHT / F12xHTMaximum speed [mph]Manual transmission106116125Automatic transmission–116–

Technical data225EngineD15DTD15DTHA16DT / Z16DTMaximum speed [mph]Manual transmission111–106Automatic transmission–114–

226Technical dataVehicle dimensionsCrossland XLength [mm]4212Width with two exterior mirrors [mm]1976Width with two exterior mirrors folded [mm]1825Height [mm]1597Length of load compartment floor [mm]793Length of load compartment with folded rear seats [mm]1483Load compartment width [mm]947Load compartment height with cover [mm]584Load compartment height without cover [mm]894Height of load compartment opening [mm]712Turning circle diameter [m]11.2

Technical data227Capacities
Engine oilEngineD12xE / F12xED12xHL / F12xHL
D12xHT / F12xHTD15DT
A16DT / Z16DTD15DTHincluding filter [l]3.253.53.753.95between MIN and MAX [l]1.01.01.01.6
Fuel tank
Petrol / diesel, refilling quantity [l]45
AdBlue tank
AdBlue, refilling quantity [l]14.8

228Technical dataTyre pressuresComfort with up to 3 peopleECO with up to 3 peopleWith full loadTyresfrontrearfrontrearfrontrear[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])195/65 R15,
195/60 R16230/2.3 (33)230/2.3 (33)250/2.5 (36)250/2.5 (36)240/2.4 (35)290/2.9 (42)205/60 R16,
215/50 R17230/2.3 (33)230/2.3 (33)250/2.5 (36)250/2.5 (36)240/2.4 (35)270/2.7 (39)Temporary spare wheel
125/80 R16420/4.2 (60)420/4.2 (60)––420/4.2 (60)420/4.2 (60)
