Page 251 of 275
Technical data249Engine dataEngine identifier codeB12XHT / D12xHTA16NHTD16XHTSales designation1.2 Turbo1.61.6Engineering codeEB2DTS / EB2ADTSEP6FDTMEP6FADTXDPiston displacement [cm3
]120015981598Engine power [kW]96121133at rpm550060005500Torque [Nm]230240250at rpm175014001750Fuel typePetrolPetrolPetrolOctane rating RON 2)3)recommended959595possible989898possible919191Additional fuel type–––2)
A country specific label at the fuel filler flap can supersede the engine specific requirement.
3) In certain countries, the use of a particular fuel, e.g. a specific octane rating, may be required to ensure proper engine operation.
Page 252 of 275
250Technical dataEngine identifier codeA16DTHD15DTD15DTHD20DTHSales designation1.61.51.52.0Engineering codeDV6FCDV5RDDV5RCDW10FCPiston displacement [cm3
]1560149914991997Engine power [kW]887596130at rpm3500350037503750Torque [Nm]300250300400at rpm1750175017502000Fuel typeDieselDieselDieselDiesel
Page 253 of 275
Technical data251PerformanceEngineB12xHTA16DTHD16XHTD15DTD15DTHD20DTHA16NHTMaximum speed [mph]Manual transmission117117–111121––Automatic transmission1171154)–1181331254)Not available at time of printing.
Page 254 of 275
252Technical dataVehicle weight
Kerb weight, basic model without any optional equipmentEngineManual transmissionAutomatic transmission[kg]B12xHT13501370D16XHT–5)A16DTH13921430D15DT1289–D15DTH1360 / 1375 (ECO)1380D20DTH–1500A16NHT–5)5) Not available at time of printing.
Optional equipment and accessories increase the kerb weight.
Loading information 3 75.
Page 255 of 275
Technical data253Vehicle dimensionsLength [mm]4478Width without exterior mirrors [mm]1841Width with two exterior mirrors folded [mm]1970Width with two exterior mirrors [mm]2098Height (without antenna) [mm]1623Length of load compartment floor [mm]876Length of load compartment with folded second row [mm]1869Load compartment width [mm]1053Load compartment height at tailgate [mm]997Wheelbase [mm]2675Turning circle diameter [m]10.5
Page 256 of 275
254Technical dataCapacities
Engine oilEngineB12xHTD16XHTA16DTHD15DTD15DTHD20DTHA16NHTincluding filter [l]3.54.253.753.953.955.24.25between MIN and MAX [l]1.06)1.51.61.61.21.26) Not available at time of printing.
Fuel tank
Petrol / diesel, refilling quantity [l]53
AdBlue tank
AdBlue, refilling quantity [l]17
Page 257 of 275
Technical data255Tyre pressuresVehicle with up to 3 peopleWith full loadEngineTyresfrontrearfrontrear[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])B12XHT215/70 R16,
215/65 R17210/2.1 (30)210/2.1 (30)230/2.3 (33)240/2.4 (35)225/55 R18220/2.2 (32)220/2.2 (32)240/2.4 (35)250/2.5 (36)205/55 R19240/2.4 (35)240/2.4 (35)260/2.6 (38)270/2.7 (39)235/50 R19220/2.2 (32)210/2.1 (30)230/2.3 (33)240/2.4 (35)A16NHT,
D15DT,
D15DTH,
A16DTH215/70 R16,
215/65 R17210/2.1 (30)210/2.1 (30)230/2.3 (33)240/2.4 (35)225/55 R18,
235/50 R19220/2.2 (32)220/2.2 (32)240/2.4 (35)250/2.5 (36)205/55 R19240/2.4 (35)240/2.4 (35)260/2.6 (38)270/2.7 (39)D20DTH215/65 R17220/2.2 (32)220/2.2 (32)240/2.4 (35)250/2.5 (36)225/55 R18,
235/50 R19230/2.3 (33)230/2.3 (33)250/2.5 (36)260/2.6 (38)205/55 R19250/2.5 (36)250/2.5 (36)280/2.8 (41)290/2.9 (42)
Page 258 of 275
256Technical dataVehicle with up to 3 peopleWith full loadEngineTyresfrontrearfrontrear[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])[kPa/bar] ([psi])D16XHT7)AllTemporary spare wheel 135/80 R18420/4.2 (60)420/4.2 (60)420/4.2 (60)420/4.2 (60)7)Not available at time of printing.
Page 259 of 275
Customer information257Customer
informationCustomer information ................257
Declaration of conformity .........257
REACH .................................... 260
Collision damage repair ...........260
Software acknowledgement ....261
Software update ......................262
Registered trademarks ............263
Vehicle data recording and pri‐
vacy ........................................... 263
Event data recorders ...............263
Radio Frequency Identification (RFID) ..................................... 266Customer information
Declaration of conformity
Radio transmission systems
This vehicle has systems that
transmit and / or receive radio waves
subject to Directive 2014/53/EU. The
manufacturers of the systems listed
below declare conformity with
Directive 2014/53/EU. The full text of
the EU declaration of conformity for each system is available at the
following internet address:
www.opel.com/conformity.
Importer is
Opel / Vauxhall, Bahnhofsplatz,
65423 Ruesselsheim am Main,
Germany.
Navi 5.0 IntelliLink
Continental
LCIE Bureau Veritas-Site de
Fontenay aux Roses, 33 avenue du
général Leclerc, 92260 Fontenay aux Roses, FranceOperation
frequency (MHz)Maximum output
(dBm)2400.0 - 2483.52.22400.0 - 2483.515
Infotainment system R 4.0 IntelliLink
LG Electronics
European Shared Service center B.V.
Krijgsman 1, 1186 DM Amstelveen,
The Netherlands
Operation frequency:
2400.0 - 2483.5 MHz
Maximum output: 4 dBm
Infotainment system R 4.0
Clarion
244 rue du Pré à Varois, 54670
Custines, France
Operation frequency:
2400 - 2480 MHz
Maximum output: 4 dBm
OnStar module
LG Electronics
European Shared Service center B.V.
Page 260 of 275
258Customer informationKrijgsman 1, 1186 DM Amstelveen,
The NetherlandsOperation
frequency (MHz)Maximum output
(dBm)2402 - 248042412 - 246218880 - 915331710 - 1785241850 - 1910241920 - 1980242500 - 257023
Antenna module
Laird
Daimlerring 31, 31135 Hildesheim,
Germany
Operation frequency: N/A
Maximum output: N/A
ASK Automotive Pvt. Ltd.
Unit 2 Plot No. 30-31, Fathepur-
Nawada, Manesar, Gurugram,
Haryana 122050, India
Operation frequency: N/A
Maximum output: N/A
Radio remote control transmitter
Hülsbeck & Fürst GmbH & Co. KG
Steeger Str. 17, 42551 Velbert,
Germany
Operation frequency: 433.92 MHz
Maximum output: 10 dBm
Radio remote control receiver
Delphi European, Middle Eastern &
African Regional Offices Customer
Technology
Center Avenue de Luxembourg,
L-4940 Bascharage, G.D. of
Luxembourg
Operation frequency: 119 - 128.6 Maximum output: 16dBµA/m @ 10m
Electronic key transmitter
Valeo
43 Rue Bayen, 75017 Paris, France
Operation frequency: 433.92 MHz
Maximum output: 10 dBm
Immobiliser
KOSTAL of America, Inc.350 Stephenson Hwy, Troy MI 48083,
USA
Operation frequency: 125 kHz
Maximum output: 5 dBμA/m at 10m
Radar unit
ZF TRW Autocruise SAS
Secteur de la Pointe du Diable,
Avenue du technopôle, 29280
Plouzane, France
Operation frequency:
24.15 - 24.25 GHz
Maximum output: 20 dBm
