brake fluid VAUXHALL GRANDLAND X 2019 Owner's Manual

In brief17Transmission
Manual transmission
To engage reverse on 6-speed
transmission, depress the clutch
pedal, pull the ring under the selector
lever and move the selector lever
quite to the left and front.
Manual transmission 3 149.
Automatic transmissionP:park positionR:reverseN:neutral modeD:automatic modeM:manual mode<:upshift]:downshift
Automatic transmission 3 146.
Starting off
Check before starting off ● tyre pressure 3 220 and
condition 3 255
● engine oil level and fluid levels 3 203
● all windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational
● proper position of mirrors 3 36,
seats 3 44 and seat belts
3 51
● brake function at low speed, particularly if the brakes are wet

94Instruments and controlsSeek the assistance of a workshop
immediately.
Stop engine
Y illuminates red.
Illuminates briefly when the ignition is
switched on.
Illuminates together with other control indicators, accompanied by a warning chime and a corresponding message
in the Driver Information Centre.
Stop engine immediately and seek
the assistance of a workshop.
System check J illuminates yellow or red.
Illuminates yellow A minor engine fault has been
detected.
Illuminates red A major engine fault has been
detected.
Stop engine as soon as possible and
seek the assistance of a workshop.Brake and clutch system
R illuminates red.
The brake and clutch fluid level is too low.9 Warning
Stop. Do not continue your
journey. Consult a workshop.
Brake fluid 3 205.
Electric parking brake
m illuminates or flashes red.
Illuminates
Electric parking brake is applied
3 150.
Flashes
Electric parking brake is not applied
automatically. The application or the
release are faulty.
9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
o illuminates yellow.
Illuminates
Automatic operation is deactivated or faulty. Activate automatic operation
again or have the cause remedied by
a workshop in the event of a fault.
Automatic operation 3 150.
Electric parking brake fault E illuminates yellow.
Illuminates
Electric parking brake has a fault
3 150.
9 Warning
Have the cause of the fault
remedied immediately by a
workshop.

200Vehicle careVehicle careGeneral Information...................200
Accessories and vehicle modifications .......................... 200
Vehicle storage ........................201
End-of-life vehicle recovery .....202
Vehicle checks ........................... 202
Performing work ......................202
Bonnet ..................................... 202
Engine oil ................................. 203
Engine coolant ......................... 204
Washer fluid ............................ 205
Brakes ..................................... 205
Brake fluid ............................... 205
Vehicle battery ......................... 205
Diesel fuel system bleeding .....207
Wiper blade replacement ........207
Bulb replacement .......................208
Halogen headlights ..................208
LED headlights ........................ 209
Front fog lights ......................... 209
Tail lights ................................. 210
Side turn lights ......................... 213
Number plate light ...................213
Interior lights ............................ 213Electrical system........................214
Fuses ....................................... 214
Engine compartment fuse box . 215
Instrument panel fuse box .......216
Vehicle tools .............................. 218
Tools ........................................ 218
Wheels and tyres .......................219
Winter tyres ............................. 219
Tyre designations ....................219
Tyre pressure .......................... 220
Tyre deflation detection system .................................... 221
Tread depth ............................. 222
Changing tyre and wheel size . 222
Wheel covers ........................... 223
Tyre chains .............................. 223
Tyre repair kit .......................... 223
Wheel changing .......................226
Spare wheel ............................ 228
Jump starting ............................. 231
Towing ....................................... 233
Towing the vehicle ...................233
Towing another vehicle ...........234
Appearance care .......................235
Exterior care ............................ 235
Interior care ............................. 237General Information
Accessories and vehiclemodifications
We recommend the use of genuine
parts and accessories and factory approved parts specific for your
vehicle type. We cannot assess or guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control
units) may invalidate the warranty
offered by Vauxhall. Furthermore,
such changes may affect driver
assistance systems, may impact fuel
consumption, CO 2 emissions and
other emissions of the vehicle and
cause the vehicle to no longer
conform to the operating permit,
impacting the validity of your vehicle
registration.

Vehicle care201Caution
When transporting the vehicle on
a train or on a recovery vehicle, the
mud flaps might be damaged.
Cold protection covers
In order to prevent the accumulation
of snow at the radiator cooling fan, it is recommended to install removable
protection covers.
The protection covers must be
professionally installed, consult a
workshop.
Caution
The protection covers must be removed when one of the
following conditions occur:
● The ambient temperature is abbove 10 °C.
● When the vehicle is towed.
● The vehicle is driven at speeds
above 75 mph.
Vehicle storage
Storage for a long period of timeIf the vehicle is to be stored for several
months:
● Wash and wax the vehicle.
● Have the wax in the engine compartment and underbody
checked.
● Clean and preserve the rubber seals.
● Fill up fuel tank completely.
● Change the engine oil.
● Drain the washer fluid reservoir.
● Check the coolant antifreeze and
corrosion protection.
● Adjust tyre pressure to the value specified for full load.
● Park the vehicle in a dry, well ventilated place. Engage first or
reverse gear or set selector lever to P. Prevent the vehicle from
rolling.
● Do not apply the parking brake.● Open the bonnet, close all doors and lock the vehicle.
● Disconnect the clamp from the negative terminal of the vehicle
battery. Note that all systems are
not functional, e.g. anti-theft
alarm system.
Putting back into operation When the vehicle is to be put back into
operation:
● Connect the clamp to the negative terminal of the vehicle
battery. Initialize the power
windows 3 39.
● Check tyre pressure.
● Fill up the washer fluid reservoir.
● Check the engine oil level.
● Check the coolant level.
● Fit the number plate if necessary.

Vehicle care205the coolant concentration checked
and have the cause of the coolant
loss remedied by a workshop.
Washer fluid
Fill with clean water mixed with a
suitable quantity of approved
windscreen washer fluid which
contains antifreeze.
Caution
Only washer fluid with a sufficient
antifreeze concentration provides
protection at low temperatures or
a sudden drop in temperature.
Washer fluid 3 242.
Brakes In the event of minimum thickness of
the brake lining, a squealing noise
sounds during braking.
Continued driving is possible but
have the brake lining replaced as
soon as possible.
Once new brake linings are installed,
do not brake unnecessarily hard for
the first few journeys.
Brake fluid9 Warning
Brake fluid is poisonous and
corrosive. Avoid contact with eyes, skin, fabrics and painted surfaces.
The brake fluid level must be betweenthe DANGER and MAX marks.
If fluid level is below DANGER seek
the assistance of a workshop.
Brake and clutch fluid 3 242.
Vehicle battery
The vehicle battery is maintenance-
free provided that the driving profile
allows sufficient charging of the
battery. Short-distance-driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.

Service and maintenance243All of the recommended viscositygrades are suitable for high ambient
temperatures.
Coolant and antifreeze Use only organic acid type-long life
coolant (LLC) antifreeze approved for
the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
cold regions with very low
temperatures the factory filled coolant
provides frost protection down to
approx. -37 °C. This concentration
should be maintained all year round.
The use of additional coolant
additives that intend to give additional
corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences
resulting from the use of additional
coolant additives will be rejected.Washer fluid
Use only washer fluid approved for
the vehicle to prevent damage of wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
Brake and clutch fluid Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified
interval.
AdBlue Only use AdBlue to reduce the
nitrogen oxides in the exhaust
emission 3 143.

268IndexAAccessories and vehicle modifications .......................... 200
Active emergency braking ....98, 169
Adaptive cruise control .........98, 161
AdBlue .................................. 96, 143
Adjustable air vents ...................130
Advanced parking assist ............177
Airbag and belt tensioners ...........92
Airbag deactivation ................58, 93
Airbag label................................... 53 Airbag system .............................. 53
Air conditioning regular operation ................................ 132
Air conditioning system .............. 123
Air intake .................................... 131
Air vents...................................... 130
Antilock brake system ................ 150
Antilock brake system (ABS) .......95
Anti-theft alarm system ................34
Anti-theft locking system .............. 34
Appearance care ........................235
Armrest ................................... 49, 50
Ashtrays ....................................... 86
Automatic anti-dazzle ..................38
Automatic light control ...............113
Automatic locking ........................27
Automatic transmission .............146
Autostop ............................... 97, 138
Auxiliary heater ........................... 130B
Battery discharge protection ......121
Battery voltage ........................... 103
BlueInjection ............................... 143
Bonnet ....................................... 202
Brake and clutch fluid .................242
Brake and clutch system .............94
Brake assist ............................... 152
Brake fluid .................................. 205
Brakes ............................... 150, 205
Breakdown.................................. 233
Bulb replacement ....................... 208
C Capacities .................................. 254
Catalytic converter .....................142
Central locking system ................23
Centre console lighting ..............120
Centre console storage ...............68
Changing tyre and wheel size ...222
Charging system .......................... 93
Child locks ................................... 28
Child restraint installation locations ................................... 63
Child restraints.............................. 60
Child restraint systems ................60
Cigarette lighter ........................... 85
Climate control ............................. 15
Climate control systems .............122
Clock............................................. 82

269Collision damage repair..............260
Control indicators.......................... 91
Control of the vehicle .................134
Controls ........................................ 78
Convex shape .............................. 36
Coolant and antifreeze ...............242
Cruise control ...................... 98, 156
Cupholders .................................. 67
Curtain airbag system .................. 58
Curve lighting.............................. 114
D
Danger, Warnings and Cautions ...4
Daytime running lights ...............114
Declaration of conformity ............257
DEF ............................................ 143
Deflation detection system ...........96
Diesel exhaust fluid ....................143
Diesel fuel system bleeding .......207
Door open .................................... 99
Doors ............................................ 29
Driver alert .................................. 190
Driver assistance systems ..........156
Driver Information Centre .............99
Driving characteristics and towing tips .............................. 195
Driving hints ................................ 134
E
Electric adjustment ......................36
Electrical system......................... 214Electric parking brake ...........94, 150
Electric parking brake fault ...........94
Electronic climate control system 126
Electronic driving programmes ..148
Electronic key system ...................22
Electronic Stability Control and Traction Control system ....95, 153
End-of-life vehicle recovery .......202
Engine compartment fuse box ...215
Engine coolant ........................... 204
Engine coolant temperature ........95
Engine coolant temperature gauge ....................................... 90
Engine data ............................... 249
Engine exhaust .......................... 142
Engine identification ...................245
Engine oil ................... 203, 242, 246
Engine oil level monitor ................90
Engine oil pressure ......................96
Entry lighting .............................. 120
Event data recorders ..................263
Exhaust filter ......................... 96, 142
Exit lighting ................................ 121
Exterior care .............................. 235
Exterior light ................................. 97
Exterior lighting ....................12, 112
Exterior mirrors ............................. 36F
Fault ........................................... 148
First aid ......................................... 74
First aid kit ................................... 74
Fixed air vents ........................... 131
Folding mirrors ............................. 37
Forward collision alert................. 168
Front airbag system .....................57
Front fog lights .............98, 118, 209
Front pedestrian protection ........173
Front seats.................................... 44
Fuel............................................. 192
Fuel for diesel engines ..............192
Fuel for petrol engines ...............192
Fuel gauge ................................... 90
Fuses ......................................... 214
G
Gauges ......................................... 89
Gear shifting ................................. 95
General information ...................195
Glass panel .................................. 42
Glovebox ..................................... 67
Glovebox cooler ......................... 131
H Halogen headlights ....................208
Hazard warning flashers ............117
Headlight flash ........................... 113
Headlight range adjustment ......114
Headlights................................... 112
