display VAUXHALL INSIGNIA 2015.5 Owners Manual

Driving and operating209
event, No Traffic Sign Detection
due to Weather is indicated on the
display.
■ Traffic signs are incorrectly mounted or damaged.
■ Traffic signs do not comply with the
Vienna Convention on traffic signs
(Wiener Übereinkommen über
Straßenverkehrszeichen).Caution
The system is intended to help the driver within a defined speed
range to recognise certain traffic
signs. Do not ignore traffic signs
which are not displayed by the
system.
The system does not recognise
any other than the conventional
traffic signs that might give or end
a speed limit.
Do not let this special feature
tempt you into taking risks when
driving.
Always adapt speed to the road
conditions.
The driver assistance systems do not relieve the driver from full
responsibility for vehicle
operation.
Lane departure warning
The lane departure warning system
observes the lane markings between
which the vehicle is driving, via a front camera. The system detects lane
changes and warns the driver in the
event of an unintended lane change
by visual and acoustic signals.
Criteria for the detection of an
unintended lane change are:
■ No operation of turn signals.
■ No brake pedal operation.
■ No active accelerator operation or speeding-up.
■ No active steering.
If the driver is active, no warning will
be issued.
Activation
The lane departure warning system is activated by pressing ). The
illuminated LED in the button
indicates that the system is switched
on. When the control indicator ) in
the instrument cluster illuminates
green, the system is ready to operate.
The system is only operable at
vehicle speeds above 35 mph and if
lane markings are available.

246Vehicle care
In right-hand drive vehicles, the fuse
box is located behind a cover in the
glovebox. Open the glovebox and
remove the cover.
No.Circuit1Infotainment system/Info
display2Body control unit3Body control unit4Infotainment system/Info
display5Infotainment system/Info
display6Cigarette lighter7Power outlet8Body control unit9Body control unit10Body control unit11Interior fan12–13–14Diagnostic connector15AirbagNo.Circuit16Central locking system/Tailgate17Air conditioning system18Transportation fuse19Memory20–21Instrument22Ignition23Body control unit24Body control unit25–26Power outlet load compartment
Power seats, No's. 12 and 13, have
an overload protection. The circuit will
be closed again after cooling down.

Vehicle care251Tyre pressure monitoring
system
The tyre pressure monitoring system
checks the pressure of all four wheels once a minute when vehicle speed
exceeds a certain limit.Caution
Tyre pressure monitoring system
warns just about low tyre pressure
condition and does not replace
regular tyre maintenance by the
driver.
All wheels must be equipped with
pressure sensors and the tyres must
have the prescribed pressure.
Notice
In countries where the tyre pressure monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle type approval.
Select the Tyre pressure monitoring
page under the Info Menu in the
Driver Information Centre (DIC)
3 111.
System status and pressure warnings
are displayed by a message with the
corresponding tyre flashing in the
DIC.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 109.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 293.
After inflating, some driving may be
required to update the tyre pressure
values in the DIC. During this time w
may illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for
approaching a low tyre pressure
condition. Check tyre pressure.
Vehicle messages 3 120.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operational
for these wheels. Control indicator w

252Vehicle care
illuminates. For the further three
wheels the system remains
operational.
The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.
Each time the tyres are replaced tyre
pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor replace valve core and sealing ring, for clipped
sensor replace complete valve stem.
Vehicle loading status Adjust tyre pressure to load condition according tyre information label or
tyre pressure chart 3 293, and select
the appropriate setting in the Tyre
loading page under the Settings
menu in the DIC 3 111.
Select:
■ Light for comfort pressure up to
3 people.
■ Eco for Eco pressure up to
3 people.
■ Max for full loading.
Auto learn function
After changing wheels the vehicle
must be stationary for approx.
20 minutes, before the system
recalculates. The following relearn
process takes up to 10 minutes of
driving with a minimum speed of
12 mph. In this case $ can be
displayed or pressure values can
swap in the DIC.
If problems occur during the relearn
process, a warning message is
displayed in the DIC.
Temperature dependency
Tyre pressure depends on the
temperature of the tyre. During
driving tyre temperature and pressure increase.
The tyre pressure value displayed in
the DIC shows the actual tyre
pressure. Therefore it is important to
check tyre pressure with cold tyres.
Tread depth
Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).
For safety reasons, it is
recommended that the tread depth of
the tyres on one axle should not vary
by more than 2 mm.

Vehicle care269
SunroofNever clean with solvents or abrasive
agents, fuels, aggressive media
(e.g. paint cleaner, acetone-
containing solutions etc.), acidic or
highly alkaline media or abrasive
pads. Do not apply wax or polishing
agents to the sunroof.
Wheels and tyres
Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.
Paintwork damageRectify minor paintwork damage with
a touch-up pen before rust forms. Have more extensive damage or rust
areas repaired by a workshop.
Underbody
Some areas of the vehicle underbody
have a PVC undercoating while other critical areas have a durable
protective wax coating.After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Liquid gas system9 Danger
Liquid gas is heavier than air and
can collect in sink points.
Take care when performing work
at the underbody in a pit.
For painting work and when using a
drying booth at a temperature above
60 °C, the liquid gas tank must be
removed.
Do not make any modifications to the
liquid gas system.
Towing equipment
Do not clean the coupling ball bar with
a steam-jet or high-pressure jet
cleaner.
Interior care Interior and upholsteryOnly clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.

Service and maintenance271Service and
maintenanceGeneral information ...................271
Recommended fluids, lubricants and parts .................................... 272General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 102.
European service intervals
Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Macedonia,
Malta, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
Serbia, Slovakia, Slovenia, Spain,
Sweden, Switzerland, United
Kingdom.
Service display 3 102.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 102.

272Service and maintenance
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.The date and mileage is completed
with the stamp and signature of the servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining engine oil life duration The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 102.Recommended fluids,
lubricants and parts
Recommended fluids and
lubricants Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 276.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.

325
Centre console lighting ..............135
Changing tyre and wheel size ...253
Charging system ........................ 105
Child locks ................................... 28
Child restraint installation locations ................................... 66
Child restraints.............................. 64
Child restraint systems ................64
Climate control ............................. 15
Climate control systems .............138
Clock............................................. 91
Colour-Info-Display .....................118
Control indicators........................ 104
Control of the vehicle .................152
Controls ........................................ 86
Convex shape .............................. 36
Coolant and antifreeze ...............272
Cruise control ....................110, 177
Cupholders .................................. 70
Curtain airbag system .................. 62
Curve lighting.............................. 129
D Danger, Warnings and Cautions ...4
Daytime running lights ...............129
Declaration of conformity ............320
DEF ............................................ 161
Diesel exhaust fluid ....................161
Diesel fuel system bleeding .......230
Diesel particle filter .............108, 160Door open .................................. 111
Doors ............................................ 28
Driver assistance systems ..........177
Driver Information Centre ...........111
Driving characteristics and towing tips .............................. 218
Driving hints ................................ 152
Dual automatic climate control system ..................................... 144
E Electric adjustment ......................36
Electrical system......................... 242
Electric parking brake .........106, 170
Electric parking brake fault .........106
Electronic driving programmes ..167
Electronic key system ...................22
Electronic Stability Control.......... 173
Electronic Stability Control and Traction Control system ..........108
Electronic Stability Control off..... 108
End-of-life vehicle recovery .......223
Engine compartment fuse box ...243
Engine coolant ........................... 226
Engine coolant temperature gauge ..................................... 102
Engine data ............................... 279
Engine exhaust .......................... 160
Engine identification ...................275
Engine oil ................... 224, 272, 276Engine oil pressure ....................109
Entry lighting .............................. 135
Event data recorders ..................322
Exit lighting ................................ 136
Exterior care .............................. 267
Exterior light ............................... 110
Exterior lighting ....................12, 126
Exterior mirrors ............................. 36
F
Fault ........................................... 167
First aid ......................................... 82
First aid kit ................................... 82
Fixed air vents ........................... 150
Fog light ..................................... 110
Fog lights ................................... 236
Folding mirrors ............................. 37
Following distance ......................107
Following distance indication ......190
Forward collision alert................. 187
Front airbag system .....................61
Front fog lights ........................... 132
Front seats.................................... 47 Front storage ................................ 71
Front turn signal light ..................232
Fuel............................................. 210
Fuel consumption - CO 2-
Emissions ............................... 217
Fuel for diesel engines ..............211
Fuel for liquid gas operation .......211

326
Fuel for petrol engines ...............210
Fuel gauge ................................. 101
Fuel selector .............................. 102
Fuses ......................................... 242
G Gauges ....................................... 100
Gear shifting ............................... 107
General information ...................218
Glovebox ..................................... 70
H Halogen headlights ....................232
Hand brake ......................... 169, 170
Hazard warning flashers ............132
Headlight flash ........................... 128
Headlight range adjustment ......128
Headlights................................... 126 Headlights when driving abroad 129
Head restraint adjustment .............8
Head restraints ............................ 45
Heated mirrors ............................. 38
Heated rear window ..................... 41
Heated steering wheel .................87
Heating ........................................ 53
High beam ......................... 110, 127
High beam assist ................110, 127
Hill start assist ........................... 172
Horn ....................................... 13, 87I
Identification plate .....................274
Ignition switch positions .............153
Immobiliser .......................... 36, 109
Indicators .................................... 100
Information displays.................... 111
Instrument cluster ........................95
Instrument panel fuse box .........245
Instrument panel illumination .....241
Instrument panel illumination control .................................... 134
Instrument panel overview ........... 10
Interactive driving system ...........174
Interior care ............................... 269
Interior lighting ............................ 134
Interior lights ...................... 134, 241
Interior mirrors .............................. 38
Interruption of power supply ......168
Introduction .................................... 3
ISOFIX child restraint systems ....69
J Jump starting ............................. 262
K Key, memorised settings ..............23
Keys ............................................. 20
Keys, locks ................................... 20L
Lane change alert .......................201
Lane departure warning .....107, 209
Lashing eyes ............................... 77
Lighting features .........................135
Light switch ................................ 126
Load compartment ................28, 72
Load compartment cover .............74
Load compartment fuse box ......247
Loading information .....................84
Low fuel ..................................... 109
M
Malfunction indicator light ..........106
Manual anti-dazzle ......................38
Manual mode ............................. 166
Manual transmission .................. 168
Manual windows ..........................39
Memorised settings ......................23
Mirror adjustment ........................... 9
Misted light covers .....................133
N New vehicle running-in ..............153
Number plate light .....................240
O Object detection systems ...........193
Odometer ................................... 100
Oil, engine .......................... 272, 276

327
Operate pedal............................. 106
Outside temperature ....................90
Overrun cut-off ........................... 156
P Parking ................................ 18, 159
Parking assist ......................38, 193
Parking brake ............................ 170
Parking lights ............................. 133
Performance .............................. 281
Performing work ........................223
Pollen filter ................................. 150
Power button .............................. 153
Power outlets ............................... 92
Power seat adjustment .................50
Power steering fluid ....................227
Power windows ............................ 39
Preheating ................................. 108
Puncture ..................................... 257
Q
Quickheat ................................... 149
R Radio Frequency Identification (RFID) ..................................... 323
Radio remote control ...................21
Reading lights ............................ 134
Rear cross traffic alert ................204
Rear floor storage cover ..............76Rear fog light ............................. 110
Rear fog lights ........................... 133
Rear seats .................................... 54
Rear view camera ...................... 202
Rear window wiper/washer .......... 90 Recommended fluids and lubricants ........................ 272, 276
Refuelling ................................... 213 Retained power off .....................155
Reversing lights .........................133
Ride control systems ..................172
Roller blinds ................................. 42
Roof .............................................. 42
Roof load ...................................... 84
Roof rack ..................................... 83
S
Safety belts ................................... 54
Safety net .................................... 79
Seat adjustment ....................... 6, 47
Seat belt ........................................ 8
Seat belt reminder .....................104
Seat belts ..................................... 54 Seat position ................................ 47
Selective catalytic reduction .......161
Selector lever ............................. 165
Service ............................... 151, 271
Service display .......................... 102
Service information ....................271
Side airbag system ......................62Side blind spot alert ....................199
Sidelights .................................... 126
Side turn signal lights ................240
Smartphone controller ................120
Spare wheel ............................... 260
Speed limiter....................... 111, 179
Speedometer ............................. 100
Starting and operating ................153
Starting off ................................... 16
Starting the engine ....................155
Steering ...................................... 152
Steering wheel adjustment ......9, 86
Steering wheel controls ...............86
Stop-start system........................ 157
Storage ......................................... 70
Storage compartments .................70
Sunroof ........................................ 42
Sunvisor lights ........................... 135
Sun visors .................................... 41
Symbols ......................................... 4
T Tachometer ............................... 101
Tail lights ................................... 237
Three-point seat belt .................... 55
Tools .......................................... 248
Top-tether fastening eyes ............69
Tow bar....................................... 218
Towing ................................ 218, 264
Towing another vehicle .............266
