242Vehicle care
Vehicles with spare wheel
The jack with wheel wrench, the tools,
an extension bolt for securing a
damaged wheel and the towing eye
are placed in the tool box below the
spare wheel in the load compartment. Spare wheel 3 253.
Wheels and tyres
Tyre condition, wheel condition
Drive over edges slowly and at right
angles if possible. Driving over sharp
edges can cause tyre and wheel
damage. Do not trap tyres on the kerb when parking.
Regularly check the wheels for
damage. Seek the assistance of a
workshop in the event of damage or
unusual wear.
Winter tyres Winter tyres improve driving safety at
temperatures below 7 °C and should
therefore be fitted on all wheels.
In accordance with country-specific
regulations, affix the speed sticker in
the driver's field of view.
All tyre sizes are permitted as winter
tyres 3 286.
5-door Hatchback, 4-door Saloon,
Sports TourerTyre sizes 205/60 R 16 and
235/45 R 18 are only suitable as
winter tyres.
Tyre designations E.g. 215/60 R 16 95 H215=Tyre width, mm60=Cross-section ratio (tyre height
to tyre width), %R=Belt type: RadialRF=Type: RunFlat16=Wheel diameter, inches95=Load index e.g. 95 is
equivalent to 690 kgH=Speed code letter
Speed code letter:
Q=up to 100 mphS=up to 112 mphT=up to 118 mphH=up to 130 mphV=up to 150 mphW=up to 168 mph

284Technical dataVehicle dimensions4-door Saloon5-door HatchbackSports TourerCountry TourerLength [mm]4842484249134920Width without exterior mirrors [mm]1856185618561856Width with two exterior mirrors [mm]2084208420842084Height (without antenna) [mm]1484148415141525Vehicle height - Rear compartment open [mm]1830217521842195Length of load compartment floor [mm]1003100310861086Length of load compartment with folded rear seats [mm]1895189519081908Load compartment width [mm]1027102710301030Load compartment height [mm]356436677677Wheelbase [mm]2737273727372737Turning circle diameter [m]11.411.411.411.4
