274Service and maintenanceService and
maintenanceGeneral information ...................274
Service information ..................274
Recommended fluids, lubricants
and parts .................................... 275
Recommended fluids and lubricants ................................ 275General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 101.
European service intervals Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 101.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold starting, stop and go operation, trailer
operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

Service and maintenance275driving at high altitude and large
variations of temperature. Under
these severe operating conditions, certain service work may be required
more frequently than the regular service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 101.
Confirmations Confirmation of service is recorded inthe Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 101.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

320IndexAAccessories and vehicle modifications .......................... 226
Active emergency braking ..........195
Active head restraints ...................46
Adaptive cruise control .......109, 183
Adaptive forward lighting ...109, 132
AdBlue ................................ 107, 164
Adjustable air vents ...................151
Airbag and belt tensioners .........104
Airbag deactivation ..............62, 104
Airbag label................................... 57 Airbag system .............................. 57
Air conditioning regular operation ................................ 153
Air conditioning system .............. 140
Air intake .................................... 152
Air vents...................................... 151
All-wheel drive ........................... 172
Antilock brake system ................ 173
Antilock brake system (ABS) .....106
Anti-theft alarm system ................34
Anti-theft locking system .............. 33 Appearance care ........................271
Armrest ................................... 52, 53
Armrest storage ........................... 70
Ashtrays ....................................... 92 Automatic anti-dazzle ..................39
Automatic climate control system .................................... 142Automatic dimming ......................38
Automatic light control ...............129
Automatic locking ........................27
Automatic transmission .............167
Automatic transmission fluid .......229
Autostop ............................. 109, 159
Auxiliary heater ........................... 151
B
Baselevel display ........................110
Battery discharge protection ......139
Battery voltage ........................... 120
Belts.............................................. 54
BlueInjection ............................... 164
Bonnet ....................................... 227
Brake and clutch fluid .................275
Brake and clutch system ...........105
Brake assist ............................... 175
Brake fluid .................................. 232
Brakes ............................... 173, 232
Breakdown.................................. 267
Bulb replacement ....................... 235
C Capacities .................................. 293
Cargo management system ........76
Car Pass ...................................... 21
Catalytic converter .....................164
Central locking system ................24
Centre console lighting ..............138
Changing tyre and wheel size ...257

321Charging system ........................ 104
Child locks ................................... 28
Child restraint installation locations ................................... 65
Child restraints.............................. 63
Child restraint systems ................63
Climate control ............................. 15
Climate control systems .............140
Clock............................................. 89
Collision damage repair ..............315
Colour-Info-Display .....................117
Control indicators........................ 103
Control of the vehicle .................155
Controls ........................................ 85
Convex shape .............................. 37
Coolant and antifreeze ...............275
Cruise control ....................109, 180
Cupholders .................................. 69
Curtain airbag system .................. 61
Curve lighting.............................. 132
D Danger, Warnings and Cautions ...4
Daytime running lights ...............131
Declaration of conformity ............312
DEF ............................................ 164
Diesel exhaust fluid ....................164
Diesel fuel system bleeding .......234
Diesel particle filter .............107, 163
Door open .................................. 110Doors............................................ 29
Driver assistance systems ..........180
Driver Information Centre ...........110
Driving characteristics and towing tips .............................. 221
Driving hints ................................ 155
Dual automatic climate control system ..................................... 147
E Electric adjustment ......................37
Electrical system......................... 245
Electric parking brake .........105, 174
Electric parking brake fault .........105
Electronic driving programmes ..170
Electronic key system ...................22
Electronic Stability Control.......... 176
Electronic Stability Control and Traction Control system ..........107
Electronic Stability Control off..... 107
End-of-life vehicle recovery .......227
Engine compartment fuse box ...247
Engine coolant ........................... 230
Engine coolant temperature ......107
Engine coolant temperature gauge ..................................... 101
Engine data ............................... 283
Engine exhaust .......................... 163
Engine identification ...................279
Engine oil ................... 228, 275, 280Engine oil pressure ....................108
Entry lighting .............................. 138
Event data recorders ..................317
Exit lighting ................................ 138
Exterior care .............................. 271
Exterior light ............................... 109
Exterior lighting ....................12, 128
Exterior mirrors ............................. 37
F
Fault ........................................... 171
First aid ......................................... 80
First aid kit ................................... 80
Fixed air vents ........................... 152
Fog light ..................................... 109
Fog lights ................................... 240
Folding mirrors ............................. 37
Following distance ......................106
Following distance indication ......194
Forward collision alert................. 191
Front airbag system .....................60
Front fog lights ........................... 135
Front seats.................................... 47
Front storage ................................ 70
Front turn signal light ..................236
Fuel............................................. 213
Fuel consumption - CO 2-
Emissions ............................... 220
Fuel for diesel engines ..............214
Fuel for liquid gas operation .......214

322Fuel for petrol engines ...............213
Fuel gauge ................................. 100
Fuel selector .............................. 101
Fuses ......................................... 245
G Gauges ......................................... 99
General information ...................221
Glovebox ..................................... 69
H Halogen headlights ....................236
Hand brake ......................... 173, 174
Hazard warning flashers ............134
Headlight flash ........................... 130
Headlight range adjustment ......131
Headlights................................... 128 Headlights when driving abroad 131
Head restraint adjustment .............8
Head restraints ............................ 45
Heated mirrors ............................. 38
Heated rear window ..................... 42
Heated steering wheel .................85
Heating ........................................ 53
High beam ......................... 109, 129
High beam assist ................109, 130
Hill start assist ........................... 175
Horn ....................................... 13, 86I
Identification plate .....................278
Ignition switch positions .............155
Immobiliser .......................... 36, 108
Indicators ...................................... 99
Information displays.................... 110
Instrument cluster ........................93
Instrument panel fuse box .........249
Instrument panel illumination .....245
Instrument panel illumination control .................................... 136
Instrument panel overview ........... 10
Interactive driving system ...........178
Interior care ............................... 273
Interior lighting ............................ 136
Interior lights ...................... 136, 245
Interior mirrors .............................. 39
Interruption of power supply ......171
Introduction .................................... 3
ISOFIX child restraint systems ....68
J Jump starting ............................. 266
K Key, memorised settings ..............23
Keys ............................................. 20
Keys, locks ................................... 20L
Lane change alert .......................204
Lane departure warning .....106, 212
Lashing eyes ............................... 75
Lighting features .........................138
Light switch ................................ 128
Load compartment ................29, 71
Load compartment cover .............73
Load compartment fuse box ......250
Loading information .....................82
Low fuel ..................................... 108
M
Malfunction indicator light ..........105
Manual anti-dazzle ......................39
Manual mode ............................. 169
Manual seat adjustment ...............48
Manual transmission .................. 172
Manual windows ..........................40
Memorised settings ......................23
Midlevel display .......................... 110
Mirror adjustment ........................... 8
Misted light covers .....................136
N New vehicle running-in ..............155
Number plate light .....................244
O Object detection systems ...........196
Odometer ..................................... 99

323Oil, engine.......................... 275, 280
OnStar ........................................ 124
Operate pedal ............................. 105
Outside temperature ....................89
Overrun cut-off ........................... 159
P Parking ................................ 18, 162
Parking assist ...................... 38, 196
Parking brake ............................ 174
Parking lights ............................. 135
Performance .............................. 285
Performing work ........................227
Pollen filter ................................. 152
Power button .............................. 156
Power outlets ............................... 91
Power seat adjustment .................50
Power steering fluid ....................231
Power windows ............................ 40
Preheating ................................. 107
Puncture ..................................... 261
Q
Quickheat ................................... 151
R Radio Frequency Identification (RFID) ..................................... 318
Radio remote control ...................21
Reading lights ............................ 137
Rear cross traffic alert ................207Rear floor storage cover ..............74
Rear fog light ............................. 109
Rear fog lights ........................... 135
Rear seats .................................... 53
Rear view camera ...................... 205
Rear window wiper/washer .......... 88
Recommended fluids and lubricants ........................ 275, 280
Refuelling ................................... 216 Registered trademarks ...............317
Retained power off .....................157
Reversing lights .........................136
Ride control systems ..................176
Roller blinds ................................. 42
Roof .............................................. 43
Roof load ...................................... 82
Roof rack ..................................... 81
S Safety belts ................................... 54
Safety net .................................... 77
Seat adjustment ............................. 6 Seat belt ........................................ 8
Seat belt reminder .....................103
Seat belts ..................................... 54
Seat heating ................................. 53
Seat position ................................ 47
Selective catalytic reduction .......164
Selector lever ............................. 168
Service ............................... 153, 274Service display .......................... 101
Service information ....................274
Side airbag system ......................61
Side blind spot alert ....................202
Sidelights .................................... 128
Side turn signal lights ................243
Smartphone controller ................118
Software acknowledgement .......315
Spare wheel ............................... 263
Speed limiter....................... 110, 182
Speedometer ............................... 99
Starting and operating ................155
Starting off ................................... 16
Starting the engine ....................158
Steering ...................................... 155
Steering wheel adjustment ......9, 85
Steering wheel controls ...............85
Stop-start system........................ 159
Storage ......................................... 69
Storage compartments .................69
Sunroof ........................................ 43
Sunvisor lights ........................... 137
Sun visors .................................... 42
Symbols ......................................... 4
T
Tachometer ............................... 100
Tail lights ................................... 241
Three-point seat belt .................... 55 Tools .......................................... 252

324Top-tether fastening eyes ............68
Tow bar....................................... 221
Towing ................................ 221, 267
Towing another vehicle .............269
Towing equipment .....................222
Towing the vehicle .....................267
Traction Control system ............. 176 Traction Control system off......... 107
Traffic sign assistant ...........110, 208
Trailer coupling ........................... 221
Trailer stability assist .................224
Trailer towing ............................. 222
Transmission ............................... 16
Transmission display .................167
Tread depth ............................... 256
Trip odometer .............................. 99
Turn and lane-change signals ...134
Turn signal ................................. 103
Tyre chains ................................ 258
Tyre designations ......................253
Tyre pressure ............................ 253
Tyre pressure monitoring system ............................ 108, 255
Tyre pressures ........................... 294
Tyre repair kit ............................. 258
U Ultrasonic parking assist ...106, 196
Upholstery .................................. 273
Uplevel display ........................... 110Upshift........................................ 106
Using this manual ..........................3
V Valet mode ................................. 117
Variable effort steering ...............106
Vehicle battery ........................... 232
Vehicle checks............................ 227
Vehicle data ................................ 280
Vehicle data recording and privacy ..................................... 317
Vehicle detected ahead ..............109
Vehicle dimensions .................... 291
Vehicle Identification Number ....278
Vehicle jack ................................ 252
Vehicle messages .....................119
Vehicle personalisation .............120
Vehicle security ............................ 33
Vehicle specific data ......................3
Vehicle storage ........................... 226
Vehicle tools ............................... 252
Vehicle unlocking ........................... 6
Vehicle weight ........................... 288
Ventilating ..................................... 53
Ventilation ................................... 140
W
Warning chimes .........................119
Warning lights ............................... 99
Warning triangle .......................... 80
Washer and wiper systems .........13Washer fluid ............................... 231
Wheel changing .........................261
Wheel covers ............................. 257
Wheels and tyres .......................253
Windows ....................................... 39
Windscreen................................... 39
Windscreen wiper/washer ...........86
Winter tyres ............................... 253
Wiper blade replacement ..........234
X Xenon headlights .......................238
