child lock VAUXHALL INSIGNIA 2019 Owner's Manual

Keys, doors and windows19Keys, doors and
windowsKeys, locks ................................... 19
Keys .......................................... 19
Radio remote control .................20
Electronic key system ................21
Memorised settings ...................24
Central locking system ..............24
Automatic locking ......................26
Child locks ................................. 27
Doors ........................................... 28
Load compartment ....................28
Vehicle security ............................ 33
Anti-theft locking system ...........33
Anti-theft alarm system ..............33
Immobiliser ................................ 36
Exterior mirrors ............................ 36
Convex shape ........................... 36
Electric adjustment ....................36
Folding mirrors .......................... 37
Heated mirrors ........................... 38
Automatic dimming ....................38
Parking assist ............................ 38Interior mirrors............................. 38
Manual anti-dazzle ....................38
Automatic anti-dazzle ................39
Windows ...................................... 39
Windscreen ............................... 39
Power windows ......................... 39
Heated rear window ..................41
Heated windscreen ....................42
Sun visors .................................. 42
Roof ............................................. 42
Sunroof ...................................... 42Keys, locks
Keys Replacement keys
The key number is specified on a
detachable tag.
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser system.
Locks 3 295, Central locking 3 24,
Starting the engine 3 178.
Radio remote control 3 20.
Electronic key 3 21.
The code number of the adapter for
the locking wheel nuts is specified on
a card. It must be quoted when
ordering a replacement adapter.
Wheel changing 3 287.
Replacing battery Replace the battery as soon as the
system no longer operates properly
or the range is reduced. The need for

Keys, doors and windows27Activation or deactivation of
automatic relock can be set in the
menu Settings , I Vehicle in the Info-
Display.
Info-Display 3 117.
Vehicle personalisation 3 123.
The setting can be saved for each electronic key being used 3 24.
Passive locking This feature locks the vehicle
automatically after several seconds if
an electronic key has been
recognised previously inside the
vehicle, all doors have then been
closed and the electronic key does
not remain within the vehicle.
If the electronic key remains in the
vehicle or the ignition is not off,
passive locking will not be permitted.
If there have been two or more
electronic keys in the vehicle and the
ignition was on once, the feature
locks the vehicle if just one electronic key is taken out of the vehicle.To prevent passive locking of the
vehicle e.g. when refuelling or if
passengers remain in the vehicle, the
system must be disabled.
To disable the system, press the
central locking button c for a few
seconds while one door is open. An
acoustic signal sounds three times to confirm deactivation. The function
remains disabled until the central
locking button e is pressed or the
ignition is switched on.
Activation or deactivation of passive
locking can be set in the menu
Settings , I Vehicle in the Info-Display.
Info-Display 3 117.
Vehicle personalisation 3 123.
The setting can be saved for each electronic key being used 3 24.Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.
Move the pin in the rear door to the front position. The door cannot be
opened from the inside.
To deactivate, move the pin to the
rear position.

28Keys, doors and windowsDoors
Load compartment Tailgate
OpeningGrand Sport
After unlocking, push the brand
emblem and open the tailgate.
Sports Tourer, Country Tourer
After unlocking, push the touchpad
switch under the tailgate moulding
and open the tailgate.
Central locking system 3 24.
Closing
Use the interior handle.
Central locking system 3 24.
Power tailgate
9 Warning
Take care when operating the
power tailgate. Risk of injury,
particularly to children.
Keep a close watch on the
movable tailgate when operating.
Ensure that nothing becomes

Seats, restraints55Seat belts
The seat belts are locked during
heavy acceleration or deceleration of
the vehicle, holding the occupants in
the seat position. Thereby the risk of
injury is considerably reduced.
9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Seat belts are designed to be used by only one person at a time. Child
restraint system 3 63.
Periodically check all parts of the belt
system for damage, soiling and
proper functionality.
Have damaged components replaced by a workshop. After an accident,
have the belts and triggered belt
pretensioners replaced by a
workshop.
Notice
Make sure that the belts are not
damaged by shoes or sharp-edged objects or are trapped. Prevent dirt
from getting into the belt retractors.
Seat belt reminder
Indicates seat belt status for front
seats by control indicators X and k,
or for rear seats by the symbol X in
the Driver Information Centre 3 104.
Belt force limiters
Stress on the body is reduced by the
gradual release of the belt during a
collision.Belt pretensioners
In the event of a head-on, rear-end or side-on collision of a certain severity,
the front and rear seat belts are
tightened. The front seat belts and the
outer rear seat belts are tightened by
one pretensioner per seat.9 Warning
Incorrect handling (e.g. removal or
fitting of belts) can trigger the belt
pretensioners.
Deployment of the belt pretensioners
is indicated by continuous illumination
of control indicator v 3 105.
Triggered belt pretensioners must be replaced by a workshop. Belt
pretensioners can only be triggered
once.
Notice
Do not affix or install accessories or
other objects that may interfere with
the operation of the belt
pretensioners. Do not make any
modifications to belt pretensioner components as this will invalidate
the operating permit of your vehicle.

337Central locking system ................24
Centre console lighting ..............141
Centre console storage ...............73
Changing tyre and wheel size ...281
Charging system ........................ 106
Child locks ................................... 27
Child restraint installation locations ................................... 66
Child restraints.............................. 63
Child restraint systems ................63
Climate control ............................. 15
Clock............................................. 91
Collision damage repair ..............328
Connected navigation .................156
Connecting a phone ...................161
Control elements ........................144
Control indicators........................ 104
Control of the vehicle .................176
Controls ........................................ 87
Convex shape .............................. 36
Coolant and antifreeze ...............300
Cruise control ....................110, 201
Cupholders .................................. 72
Curtain airbag system .................. 61
Curve lighting.............................. 134
D
DAB announcements .................152
DAB-DAB linking ........................152
DAB-FM linking........................... 152Danger, Warnings and Cautions ...4
Daytime running lights ...............134
Declaration of conformity ............324
DEF ............................................ 185
Diesel exhaust fluid ....................185
Diesel fuel system bleeding .......259
Display operation ........................148
Door open .................................. 110
Doors ............................................ 28
Driver assistance systems ..........201
Driver Information Centre ...........111
Driving characteristics and towing tips .............................. 249
Driving hints ................................ 176
E
Electric adjustment ......................36
Electrical system......................... 270
Electric parking brake .........106, 194
Electric parking brake fault .........106
Electronic climate control system 166
Electronic key system ...................21
Electronic Stability Control.......... 197
Electronic Stability Control and Traction Control system ..........107
Electronic Stability Control off..... 107
End-of-life vehicle recovery .......253
Engine compartment fuse box ...271
Engine coolant ........................... 256
Engine coolant temperature ......108Engine coolant temperature
gauge ..................................... 103
Engine data ............................... 307
Engine exhaust .......................... 183
Engine identification ...................303
Engine oil ................... 255, 300, 304
Engine oil pressure ....................108
Entry lighting .............................. 141
Event data recorders ..................331
Exhaust filter ............................... 183
Exit lighting ................................ 141
Extended status view .................144
Exterior care .............................. 295
Exterior light ............................... 109
Exterior lighting ....................12, 131
Exterior mirrors ............................. 36
F
First aid kit ................................... 83
Fixed air vents ........................... 173
Folding mirrors ............................. 37
Following distance ......................107
Following distance indication ......217
Forward collision alert................. 214
Front airbag system .....................60
Front fog lights ...........109, 138, 262
Front pedestrian protection ........221
Front seats.................................... 46
Front storage ................................ 73
Fuel............................................. 244
