VAUXHALL INSIGNIA 2020 User Guide

In brief9Exterior mirrors
Select the relevant exterior mirror by
pushing left or right mirror button.
LED in button indicates the selection.
Then swivel the control to adjust the
mirror.
Convex exterior mirrors 3 37.
Electric adjustment 3 37.
Folding exterior mirrors 3 38.
Heated exterior mirrors 3 39.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is fully locked. Do not adjust steering
wheel unless vehicle is stationary and steering wheel lock has been
released.
Airbag system 3 58.

10In briefInstrument panel overview

In brief111Power windows .....................40
2 Exterior mirrors .....................37
3 Central locking system ..........25
4 Side air vents ...................... 148
5 Cruise control .....................177
Speed limiter ....................... 179
Adaptive cruise control .......180
Forward collision alert .........189
6 Turn and lane-change
signals, headlight flash,
low/high beam, high beam
assist ................................... 134
Exit lighting ......................... 137
Parking lights ...................... 135
Buttons for Driver
Information Centre ..............110
7 Instruments ........................ 100
Driver Information Centre .... 110
8 Buttons for Driver
Information Centre ..............110
9 Head-up display ..................11710Windscreen wiper and
washer, headlight washer,
rear wiper and washer .........89
11 Centre air vents .................. 148
12 Hazard warning flashers ....133
13 Info Display ........................ 116
14 Anti-theft alarm system
status LED ........................... 34
15 Electronic Stability Control . 174
Traction Control system .....173
16 Glovebox .............................. 73
Fuse box ............................ 251
17 Controls for Info Display
operation ............................. 116
18 Climate control system ........ 139
19 Power outlet .......................... 93
20 Flexride controls .................. 175
Parking assist / advanced
parking assist .....................198
Lane keep assist ................217
Eco button for stop-start
system ................................. 15621 Manual transmission ..........168
Automatic transmission ......164
22 Electric parking brake .........170
23 Power switch ....................... 152
24 Steering wheel adjustment ..88
25 Horn ..................................... 89
26 Bonnet release lever ..........230
28 Light switch ........................ 128
Headlight range
adjustment ......................... 131
Front / rear fog lights ..........134
Instrument illumination .......135
29 Head-up display controls ....117

12In briefExterior lighting
Automatic light controlAUTO:automatic light control
switches automatically
between daytime running
light and headlight8:sidelights9:headlights
Automatic light control 3 129.
Front fog lights 3 134.
Rear fog light 3 134.
Headlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:push or pull lever
High beam 3 129.
Headlight flash 3 131.
LED headlights 3 132.
High beam assist 3 132.
Turn lightslever up:right turn lightslever down:left turn lights
Turn lights 3 134.
Parking lights 3 135.

In brief13Hazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 133.
Horn
Press j.
Washer and wiper systems
Windscreen wiperHI:fastLO:slowINT:interval wiping or automatic
wiping with rain sensorOFF:off
For a single wipe when the
windscreen wiper is off, press the
lever down to position 1x.
Windscreen wiper 3 89.
Wiper blade replacement 3 236.

14In briefWindscreen washer
Pull lever.
Windscreen and headlight washer
system 3 89.
Washer fluid 3 233.
Rear window wiperOFF:offINT:intermittent operationON:continuous operationRear window washer
Push lever.
Washer fluid is sprayed on the rear
window and the wiper wipes a few
times.
Rear window wiper and washer
3 91.

In brief15Climate control
Heated rear window
Operated by pressing b.
Heated rear window 3 42.
Heated windscreen
Operated by pressing ,.
Heated windscreen 3 43.
Heated exterior mirrors
Pressing b also operates the heated
exterior mirrors.
Heated exterior mirrors 3 39.
Demisting and defrosting the
windows, air conditioning system
● Press á: fan automatically
switches to higher speed, the air
distribution is directed towards
the windscreen.
● Set temperature control to warmest level.
● Switch on air conditioning A/C if
required.
● Switch on heated rear window b.
● Open side air vents as required and direct them towards the doorwindows.
Air conditioning system 3 139.

16In briefDemisting and defrosting the
windows, electronic climate
control
● Press à. Temperature and air
distribution are set automatically
and the fan runs at high speed.
● Activate air condition: Press CLIMATE to show climate control
menu in the Info Display, then
select A/C.
● Switch on heated rear window b.
Electronic climate control system 3 142.
Transmission
Manual transmission
Reverse: with the vehicle stationary,
depress clutch pedal, press the
release button on the selector lever
and engage the gear.
Manual transmission 3 168.
Automatic transmissionP:park positionR:reverseN:neutral modeD:automatic modeM:manual mode<:upshift]:downshift
The selector lever can only be moved
out of P when the ignition is on and
the brake pedal is applied. To engage
P or R, press the release button.
Automatic transmission 3 164.

In brief17Starting offCheck before starting off ● Tyre pressure 3 254 and
condition 3 291.
● Engine oil level and fluid levels 3 231.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors 3 37,
seats 3 47 and seat belts
3 57.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
Ignition switch
● Turn key to position 2.
● Move the steering wheel slightly to release the steering wheel
lock.
● Manual transmission: operate clutch and brake pedal.
Automatic transmission: operate
brake pedal and move selector
lever to P or N.
● Do not operate accelerator pedal.
● Diesel engines: wait until control
indicator ! for preheating
extinguishes.
● Turn key to position 3 and
release after engine has been
started.
Starting the engine 3 154.
To turn the key back from position 2
to 1 or 0, first push the key all the way
in towards the steering column.

18In briefPower button
● Manual transmission: operateclutch and brake pedal.
● Automatic transmission: operate brake pedal and move selector
lever to P or N.
● Do not operate accelerator pedal.
● Press Engine Start/Stop button.
● Release button after starting procedure begins.
Starting the engine 3 154.
Stop-start system
If the vehicle is at a low speed or at a
standstill and certain conditions are
fulfilled, an Autostop is activated.
An Autostop is indicated by the
needle at the AUTOSTOP position in
the tachometer.
Stop-start system 3 156.
Parking9 Warning
● Do not park the vehicle on an
easily ignitable surface. The
high temperature of the
exhaust system could ignite the
surface.
● Always apply the parking brake. Pull switch m for
approx. one second and check
if the control indicator m
illuminates.
The electric parking brake is applied when control indicator
m illuminates 3 106.
● Switch off the engine. ● If the vehicle is on a level surface or uphill slope, engage
first gear or set the selector
lever to position P before
removing the ignition key or
switching off ignition on
vehicles with power button. On
an uphill slope, turn the front
wheels away from the kerb.
