VAUXHALL MERIVA 2015 Owner's Manual

Technical data219Technical dataVehicle identification..................219
Vehicle data ............................... 221Vehicle identification
Vehicle Identification
Number
The Vehicle Identification Number is
stamped on the identification plate
and on the floor pan, under the floor
covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel visible through the windscreen.

220Technical dataIdentification plate
The identification plate is located on
the rear right-hand door frame.
Information on identification label:1=Manufacturer2=Type approval number3=Vehicle Identification Number4=Permissible gross vehicle weight
rating in kg5=Permissible gross train weight in
kg6=Maximum permissible front axle
load in kg7=Maximum permissible rear axle
load in kg8=Vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification The technical data tables show the
engine identifier code. Engine data
3 224.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data221Vehicle dataRecommended fluids and lubricantsEuropean service scheduleRequired engine oil qualityAll European countries
(except Belarus, Moldova, Russia, Turkey)
Only Israel
Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos 1––✔–dexos 2✔✔–✔
In case dexos quality is unavailable you may use max. 1 litre engine oil quality ACEA C3 for topping up once between each oil change.
Engine oil viscosity grades
All European countries and Israel
(except Belarus, Moldova, Russia, Turkey)Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40

222Technical data
International service scheduleRequired engine oil qualityAll countries outside Europe except Israel
Only Belarus, Moldova, Russia, Turkey
Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos 1✔–––dexos 2–✔✔✔
In case dexos quality is unavailable you may use the oil qualities listed below:
All countries outside Europe except Israel
Only Belarus, Moldova, Russia, Turkey
Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesPetrol engines
(including CNG, LPG, E85)Diesel enginesGM-LL-A-025✔–✔–GM-LL-B-025–✔–✔

Technical data223
All countries outside Europeexcept Israel
Only Belarus, Moldova, Russia, Turkey
Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B3✔–✔–ACEA A3/B4✔✔✔✔ACEA C3✔✔✔✔API SM✔–✔–API SN resource conserving✔–✔–
Engine oil viscosity grades
All countries outside Europe (except Israel),
including Belarus, Moldova, Russia, TurkeyAmbient temperaturePetrol and diesel enginesdown to -25 °CSAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but use of SAE 5W-30 or SAE 5W-40 with dexos quality is recommended.

224Technical dataEngine dataSales designation1.41.41.4 LPG1.4Engine identifier codeB14XERB14NELB14NELB14NETNumber of cylinders4444Piston displacement [cm3
]1398136413641364Engine power [kW]748888103at rpm60004200-60004800-60004900-6000Torque [Nm]130175/200 2)175200/220 3)at rpm40001750-48001750-48001850-4900Fuel typePetrolPetrolPetrol/LPGPetrolOctane rating RONrecommended95959595possible98989898possible91919191Oil consumption [l/1000 km]0.60.60.60.62)
With six-speed transmission.
3) With overboost function.

Technical data225
Sales designation1.61.61.61.61.6Engine identifier codeB16DTCB16DTLB16DTNB16DTHB16DTENumber of cylinders44444Piston displacement [cm3
]15981598159815981598Engine power [kW]70818110081at rpm3500350035003500-40003500Torque [Nm]280300300320300at rpm1500-17501750-20001750-200020001750-2000Fuel typeDieselDieselDieselDieselDieselOil consumption [l/1000 km]0.60.60.60.60.6Sales designation1.31.31.7Engine identifier codeA13DTCA13DTEA17DTINumber of cylinders444Piston displacement [cm 3
]124812481686Engine power [kW]557081at rpm400040003600

226Technical data
Sales designation1.31.31.7Engine identifier codeA13DTCA13DTEA17DTITorque [Nm]180180280at rpm1750-25001750-35002300Fuel typeDieselDieselDieselOil consumption [l/1000 km]0.60.60.6

Technical data227PerformanceEngineB14XERB14NELB14NEL LPGB14NETMaximum speed4)
[mph]Manual transmission110117117122Automatic transmission–115–1204) The maximum speed indicated is achievable at kerb weight (without driver) plus 200 kg payload. Optional equipment could reduce the specified maximum
speed of the vehicle.EngineB16DTCB16DTLB16DTNB16DTHB16DTEMaximum speed 4)
[mph]Manual transmission108115113122115Automatic transmission–––––4) The maximum speed indicated is achievable at kerb weight (without driver) plus 200 kg payload. Optional equipment could reduce the specified maximum
speed of the vehicle.

228Technical data
EngineA13DTCA13DTEA17DTIMaximum speed4)
[mph]Manual transmission99104–Automatic transmission––1114) The maximum speed indicated is achievable at kerb weight (without driver) plus 200 kg payload. Optional equipment could reduce the specified maximum
speed of the vehicle.
