Instruments and controls91and filter changed by a workshop
within one week or 300 miles
(whichever occurs first).
Driver Information Centre 3 100.
Service information 3 219.
Control indicators The control indicators described are
not present in all vehicles. The
description applies to all instrument
versions.
Depending on the equipment the
position of the control indicators may vary.
When the ignition is switched on,
most control indicators will illuminate
briefly as a functionality test.
The control indicator colours mean:red:danger, important reminderyellow:warning, information, faultgreen:confirmation of activationblue:confirmation of activationwhite:confirmation of activation

Instruments and controls99High beam
C illuminates blue.
Illuminated when high beam is on and during headlight flash 3 121.
Adaptive forward lighting f illuminates or flashes yellow.
Illuminates
Fault in system.
Seek the assistance of a workshop.
Flashes
System switched to symmetrical low
beam.
Control indicator f flashes for approx.
4 seconds after the ignition is
switched on as a reminder that the
system has been activated 3 121.
Automatic light control 3 120.
Fog light > illuminates green.
The front fog lights are on 3 123.Rear fog light
r illuminates yellow.
The rear fog light is on 3 124.
Cruise control
m illuminates white or green.
Illuminates white The system is on.
Illuminates green
A certain speed is stored.
Cruise control 3 153.
Door open
h illuminates red.
A door or the tailgate is open.
Automatic locking
^ illuminates amber.
Fault in the automatic locking system. The rear doors are possibly not
secured against opening.9 Warning
Stop your journey immediately!
Follow the instructions as
described in paragraph "Fault in
the automatic locking system"
before continuing your journey
3 24.
Consult a workshop.

128Climate controlClimate controlClimate control systems.............128
Heating and ventilation system 128
Air conditioning system ...........129
Electronic climate control system .................................... 131
Auxiliary heater ........................135
Air vents ..................................... 135
Adjustable air vents .................135
Fixed air vents ......................... 136
Maintenance .............................. 136
Air intake ................................. 136
Pollen filter ............................... 136
Air conditioning regular
operation ................................ 136
Service .................................... 136Climate control systems
Heating and ventilation system
Controls for: ● temperature
● air distribution
● fan speed
● demisting and defrosting
Heated rear window Ü 3 32.
Temperature
red:warmblue:coldHeating will not be fully effective until
the engine has reached normal
operating temperature.
Air distributions:to windscreen and front door
windowsM:to head area via adjustable air
ventsK:to foot well
All combinations are possible.
Fan speed
Adjust the air flow by switching the fan to the desired speed.
Demisting and defrosting ● Press V: fan automatically
switches to higher speed, the air
distribution is directed towards
the windscreen.
● Set temperature control to warmest level.
● Switch on heated rear window Ü.
● Open side air vents as required and direct them towards the doorwindows.
