turn signal VAUXHALL MOVANO_B 2018 Owner's Manual

In brief111Fixed air vents .................... 129
2 Headlight range
adjustment ......................... 109
Ultrasonic parking assist .....162
Traction control system ......155
Electronic Stability
Program ............................. 156
3 Side air vents .....................128
4 Light switch ........................ 107
Turn and lane-change
signals ................................ 110
High beam and low beam,
headlight flash ....................108
Sidelights ............................ 107
Automatic light control .......107
Exit lighting ......................... 114
Front fog lights ...................111
Rear fog light ...................... 111
High beam assist ................108
5 Instruments .......................... 88
Transmission display ............92Driver Information Centre .... 101
Trip computer ...................... 103
6 Horn ..................................... 83
Driver airbag ........................ 58
7 Remote control on
steering wheel .......................83
Cruise control .....................158
8 Windscreen wiper,
windscreen washer system ..84
Trip computer ...................... 103
9 Coin tray ............................... 71
10 Power outlet, USB slot ..........86
11 Centre air vents .................. 128
12 Storage compartment ...........71
13 Info-display .......................... 101
14 Front passenger airbag .........58
15 Storage compartment ..........71
16 Glovebox .............................. 72
17 Seat belt reminder ................. 95
Front passenger airbag
deactivation ........................... 59
18 Cupholders ........................... 7219Climate control system ....... 115
Electronic climate control
system ................................. 117
20 Cigarette lighter .................... 88
Power outlet ......................... 86
21 Gear lever, Manual
transmission ........................ 149
Manual transmission
automated ........................... 149
22 Cruise control and speed
limiter ................................. 158
Manual transmission
automated,
Winter and Laden modes ....151
Idle speed control ...............135
Stop-start system ................135
ECO mode .......................... 132
23 Ignition switch with
steering wheel lock ............133
24 Steering column controls .....83
25 Steering wheel adjustment ..83
26 Bonnet release lever ..........175
27 Auxiliary heater ...................122

In brief13Headlight flash, high beam and
low beam
Pull lever.
High beam 3 108, Headlight flash
3 109.
Turn and lane-change signalslever up:right turn signallever down:left turn signal
Turn and lane-change signals
3 110.
Hazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 110.

34Keys, doors and windowsAlarmWhen triggered, the alarm sounds via a separate battery-backed power
sounder, and the hazard warning
lights flash simultaneously. The
number and duration of alarm signals
are stipulated by legislation.
If the vehicle battery is disconnected
or its power supply is interrupted, the
alarm siren will be triggered. First
deactivate the anti-theft alarm system if the vehicle battery must be
disconnected.
To silence the alarm siren (if
triggered) and therefore deactivate
the anti-theft alarm system, reconnect
vehicle battery and unlock vehicle
with remote control button c (or
switch on the ignition).
Immobiliser
The system is part of the ignition
switch and checks whether the
vehicle is allowed to be started with
the key being used.The immobiliser is activated
automatically after the key has been removed from the ignition switch and
also if the key is left in the ignition
switch when the engine is turned off.
If the engine cannot be started, switch off the ignition and remove key, wait
approx. two seconds and then repeat
the start attempt. If start attempt is
unsuccessful, attempt to start the
engine using the spare key and seek
the assistance of a workshop.
Notice
Radio Frequency Identification
(RFID) tags may cause interference
with the key. Do not have it placed near the key when starting the
vehicle.
Notice
The immobiliser does not lock the doors. You should always lock the
vehicle after leaving it and switch on the anti-theft alarm system 3 22,
3 32.Exterior mirrors
Convex shape
The convex exterior mirror contains
an aspherical area and reduces blind spots. The shape of the mirror makes
objects appear smaller, which will
affect the ability to estimate
distances.
Manual adjustment
Adjust mirrors by swivelling in
required direction.
The lower mirrors are not adjustable.

82Instruments and controlsInstruments and
controlsControls ....................................... 83
Steering wheel adjustment ........83
Steering wheel controls .............83
Horn ........................................... 83
Steering column controls ...........83
Windscreen wiper/washer .........84
Outside temperature ..................85
Clock ......................................... 86
Power outlets ............................. 86
Cigarette lighter ......................... 88
Ashtrays .................................... 88
Warning lights, gauges and indi‐ cators ........................................... 88
Instrument cluster ......................88
Speedometer ............................. 88
Odometer .................................. 89
Trip odometer ............................ 89
Tachometer ............................... 89
Fuel gauge ................................ 90
AdBlue gauge ............................ 90
Engine coolant temperature gauge ....................................... 90
Engine oil level monitor .............91
Service display .......................... 91Transmission display .................92
Control indicators ......................92
Turn signal ................................. 95
Seat belt reminder .....................95
Airbag and belt tensioners .........95
Airbag deactivation ....................95
Charging system .......................96
Malfunction indicator light ..........96
Service vehicle soon .................96
Stop engine ............................... 97
Brake system ............................. 97
Antilock brake system (ABS) .....97
Upshift ....................................... 97
Lane departure warning ............97
Electronic Stability Program ......98
Electronic Stability Program off ............................................. 98
Engine coolant temperature ......98
Preheating ................................. 98
AdBlue ....................................... 98
Tyre pressure monitoring system ...................................... 98
Engine oil pressure ....................99
Low fuel ..................................... 99
Stop-start system ......................99
Exterior light ............................ 100
High beam ............................... 100
High beam assist .....................100
Fog light ................................... 100
Rear fog light ........................... 100Cruise control.......................... 100
Tachograph ............................. 100
Door open ................................ 100
Information displays ...................101
Driver Information Centre ........101
Info display .............................. 101
Vehicle messages ......................102
Warning chimes .......................102
Trip computer ............................. 103
Tachograph ................................ 105

94Instruments and controlsControl indicators in the
instrument panel
Control indicators in the roof
console
OverviewOTurn signal 3 95XSeat belt reminder 3 95vAirbag and belt tensioners
3 95WAirbag deactivation 3 95pCharging system 3 96ZMalfunction indicator light
3 96AService vehicle soon 3 96oService display 3 96CStop engine 3 97RBrake system 3 97uAntilock brake system (ABS)
3 97kjUpshift, downshift 3 97ìLane departure warning 3 97RElectronic Stability Program
3 98ØElectronic Stability Program off
3 98WEngine coolant temperature
3 98!Preheating 3 98YAdBlue 3 98wTyre pressure monitoring
system 3 98IEngine oil pressure 3 99YLow fuel 3 99DAutostop (Stop-start system)
3 99\Autostop inhibited (Stop-start
system) 3 999Exterior light 3 100CHigh beam 3 100íHigh beam assist 3 100>Fog light 3 100øRear fog light 3 100mCruise control 3 100

Instruments and controls95UCruise control speed limiter
3 100&Tachograph 3 100yDoor open 3 100
Turn signal
O flashes green.
Flashes if a turn signal or the hazard
warning flashers are activated.
Rapid flashing: failure of a turn signal
light or associated fuse.
An audible warning can be heard
when the turn signals are on. When
towing a trailer, the pitch of the
audible warning changes.
Bulb replacement 3 184.
Fuses 3 193.
Turn signals 3 110.
Seat belt reminder X illuminates or flashes red.
If the seat belt is unfastened, control
indicator X will flash when vehicle
speed exceeds approx. 10 mph. A warning chime also sounds for
approx. 90 seconds.
If the seat belt is fastened, the
indicator light extinguishes.9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Three-point seat belts 3 52.
Airbag and belt tensioners
v illuminates yellow.
When the ignition is switched on, the control indicator illuminates briefly. If
it does not illuminate or illuminates
whilst driving, there is a fault in the
airbag system. Seek the assistance
of a workshop. The airbags and belt
pretensioners may fail to trigger in the event of an accident.
Deployment of the belt pretensioners
or airbags is indicated by continuous
illumination of v.9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
Belt pretensioners, airbag system
3 51, 3 55.
Airbag deactivation
W illuminates yellow when the
ignition is switched on and remains
illuminated when the front passenger
airbag has been deactivated 3 59.

Lighting107LightingExterior lighting.......................... 107
Light switch .............................. 107
Automatic light control .............107
High beam ............................... 108
High beam assist .....................108
Headlight flash ......................... 109
Headlight range adjustment ....109
Headlights when driving abroad .................................... 109
Daytime running lights .............109
Adaptive forward lighting .........110
Hazard warning flashers ..........110
Turn and lane-change signals . 110
Front fog lights ......................... 111
Rear fog lights ......................... 111
Reversing lights .......................111
Misted light covers ...................111
Interior lighting ........................... 112
Interior lights ............................ 112
Load compartment lighting ......112
Reading lights .......................... 113
Lighting features ........................114
Exit lighting .............................. 114
Battery discharge protection ....114Exterior lighting
Light switch
Turn outer light switch:
7:off0:sidelights9 P:headlightsAUTO:automatic light control:
headlights are switched on
and off automatically.
Turn inner light switch:
>:front fog lightsø:rear fog lights
High beam control indicator P
3 100.
Low beam control indicator 9 3 100.
Notice
If the headlights have been switched
on manually, a warning chime will
sound when the engine is switched
off and when the driver's door is
opened as a reminder that the lights are still on.
Tail lights
Tail lights are illuminated together with low beam and sidelights.
Automatic light control

108LightingWhen the automatic light control
function is switched on and the
engine is running, the system
switches between daytime running
lights (where fitted) and headlights,
depending on the lighting conditions.
For reasons of safety, the light switch
should always remain in the AUTO
position.
Daytime running lights 3 109.
Automatic headlight activation
During poor lighting conditions the
headlights are switched on.
Additionally, headlights are switched
on if the windscreen wipers have
been activated for several wipes.High beam
To change between low and high
beam, pull lever until a click is felt.
High beam assist This feature allows high beam to
function as the main driving light at
night and when vehicle speed is
faster than approx. 28 mph.
It switches to low beam when:
● The camera in the windscreen detects the lights of oncoming or
preceding vehicles.
● It is foggy or snowy.
● Driving in urban areas.
If there are no restrictions detected, the system switches back to high
beam.
Activation
Turn the outer light switch to AUTO
then pull the turn signal lever to activate high beam assist.
The control indicator í illuminates
continuously in the instrument cluster when the assist is activated, while the
blue control indicator 7 3 100
illuminates when high beam is on.
Control indicator í 3 100.

Lighting109Notice
Use of the system does not relieve
the driver from full responsibility for
vehicle operation.
Deactivation
Pull the turn signal lever again.
Control indicator í extinguishes.
High beam assist is also deactivated
when the outer light switch is moved
out of the AUTO position.
Notice
Depending on version, the system
can be also be deactivated via the
Infotainment system. Refer to
Infotainment manual for further
information.
General information
Performance of the system can be
affected due to the following:
● Extreme weather conditions, e.g.
heavy rain, fog or snow.
● The front camera or the windscreen is obstructed, e.g. bya portable navigation system.
● Oncoming or preceding vehicle lights are not detected.● Headlights are not adjustedcorrectly.
● Various reflective surfaces may also cause the system to fail to
detect other vehicles.
Headlight flash
To activate the headlight flash, pull
lever.
Headlight range adjustment
Manual headlight range
adjustment With low beam switched on, adapt the
headlight range to suit the vehicle
load to prevent dazzling of oncoming
traffic.
Turn knurled wheel to required
position:0:front seat occupied4:loaded up to permissible
maximum weight
Headlights when driving
abroad
The asymmetrical headlight beam
extends visibility at the edge of the
road at the passenger side.
However, when driving in countries
where traffic drives on the opposite
side of the road, adjust the headlights
to prevent dazzling of oncoming
traffic.
Have the headlights adjusted by a
workshop.
Daytime running lights
Daytime running lights increase
visibility of the vehicle during daylight.

110LightingThe lights operate automatically
when the ignition is switched on.
If the vehicle is equipped with the
automatic light control function, the
system switches between daytime
running lights and headlights
automatically depending on the
lighting conditions. Automatic light
control 3 107.
Adaptive forward lighting
Cornering light Depending on the steering angle,
vehicle speed and gear selected
when cornering, an additional light
will illuminate the corner of the road
on the respective side when the
headlights are switched on.
The cornering light is switched off
automatically after prolonged use and
at vehicle speeds above 25 mph.Hazard warning flashers
Operated by pressing ¨.
In the event of hard braking, the
hazard warning flashers may turn on automatically. Switch off by pressing
¨ .
Turn and lane-change
signalslever up:right turn signallever down:left turn signal
A resistance point can be felt when
moving the lever.
Constant flashing is activated when
the lever is moved beyond the
resistance point. It is deactivated
when the steering wheel is moved in
the opposite direction or lever is
manually moved back to its neutral
position.
