Vehicle care151Tyre pressure 3 182.
The tyre pressure information label
on the driver's door frame indicates the original equipment tyres and the
correspondent tyre pressures.
The tyre pressure data refers to cold
tyres. It applies to summer and winter
tyres.
The ECO tyre pressure serves to
achieve the smallest amount of fuel
consumption possible.
Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.
Tyre pressures differ depending on
various options.
For the correct tyre pressure value,
follow the procedure below:
● Identify the engine identifier code. Engine data 3 177.
● Identify the respective tyre.
For the tyres approved for your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.The driver is responsible for correct
adjustment of tyre pressure.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
9 Warning
For specific tyres the
recommended tyre pressure as
shown in the tyre pressure table may exceed the maximum tyre
pressure as indicated on the tyre.
Never exceed the maximum tyre
pressure as indicated on the tyre.
If the tyre pressure must be reduced
or increased, switch off ignition. After
adjusting tyre pressure switch on
ignition and select the relevant setting on the page Tyre Load in the Driver
Information Centre 3 73.
Temperature dependency
The tyre pressure depends on the temperature of the tyre. During
driving, tyre temperature and
pressure increase. Tyre pressure
values provided on the tyre
information label and tyre pressure
chart are valid for cold tyres, which
means at 20 °C.
The pressure increases by nearly
1.5 psi for a 10 °C temperature
increase. This must be considered
when warm tyres are checked.
The tyre pressure value displayed in
the Driver Information Centre shows
the real tyre pressure. A cooled down tyre will show a decreased value,
which does not indicate an air leak.
Tyre pressure monitoringsystem
The tyre pressure monitoring system
checks the pressure of all four tyres
once a minute when vehicle speed
exceeds a certain limit.

152Vehicle careCaution
Tyre pressure monitoring system
warns only about low tyre pressure condition and does not replace
regular tyre maintenance by the
driver.
All wheels must be equipped with pressure sensors and the tyres must
have the prescribed pressure.
Notice
In countries where the tyre pressure
monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle type approval.
The current tyre pressures can be
shown in the Vehicle Information
Menu in the Driver Information
Centre.
The menu can be selected by
pressing the buttons on the turn
signal lever.
Press MENU to select the Vehicle
Information Menu X.
Turn the adjuster wheel to select the
tyre pressure monitoring system.
System status and pressure warnings
are displayed by a message with the
corresponding tyre flashing in the
Driver Information Centre.
The system considers the tyre
temperature for the warnings.
Temperature dependency 3 150.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 71.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 182.

Vehicle care153If w flashes for 60-90 seconds then
illuminates continuously, there is a fault in the system. Consult a
workshop.
After inflating, some driving may be
required to update the tyre pressure
values in the Driver Information
Centre. During this time w may
illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for
approaching a low tyre pressure
condition. Check tyre pressure.
Vehicle messages 3 79.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A temporary spare wheel is not
equipped with pressure sensors. The
tyre pressure monitoring system is
not operational for these tyres.
Control indicator w illuminates. For
the further three tyres, the system
remains operational.The use of commercially-available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Operating electronic devices or being
close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
Each time the tyres are replaced, tyre pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor; replace
valve core and sealing ring. For the
clipped sensor; replace complete
valve stem.
Vehicle loading status
Adjust tyre pressure to load condition according to the tyre information label
or tyre pressure chart 3 182, and
select the appropriate setting in the
menu Tyre Load in the Driver
Information Centre, Vehicle
Information Menu 3 73 . This setting is
the reference for the tyre pressure
warnings.The Tyre Load menu only appears if
the vehicle is in a standstill and the
parking brake is applied. On vehicles
with automatic transmission the
selector lever has to be in P.
Select:
● Lo for comfort pressure up to
3 people.
● Eco for Eco pressure up to
3 people.
● Hi for full loading.

154Vehicle careTyre pressure sensor matching
process
Each tyre pressure sensor has a
unique identification code. The
identification code must be matched
to a new tyre/wheel position after
rotating the tyres or exchanging the
complete wheel set and if one or more
tyre pressure sensors were replaced. The tyre pressure sensor matching
process should also be performed
after replacing a spare tyre with a
road tyre containing the tyre pressure sensor.
The malfunction light w and the
warning message or code should go
off at the next ignition cycle. The
sensors are matched to the wheel
positions, using a relearn tool, in the
following order: left side front wheel,
right side front wheel, right side rear
wheel and left side rear wheel. The
turn signal light at the current active
position is illuminated until sensor is
matched.
Consult a workshop for service or
purchase a relearn tool. There are
two minutes to match the first wheel
position, and five minutes overall tomatch all four wheel positions. If it
takes longer, the matching process stops and must be restarted.
The tyre pressure sensor matching
process is:
1. Apply the parking brake.
2. Turn the ignition on.
3. On vehicles with manual transmission automated: Press
and hold brake pedal. Move and
hold the selector lever for five
seconds in position N until P is
displayed in the Driver Information Centre. P indicates
that the sensor matching process can be started.
On vehicles with manual
transmission: select neutral.
4. Use MENU on the turn signal
lever to select the Vehicle
Information Menu in the Driver
Information Centre.
5. Turn the adjuster wheel to scroll to
the tyre pressure menu.6. Press SET/CLR to begin the
sensor matching process. A
message requesting acceptance
of the process should be
displayed.
7. Press SET/CLR again to confirm
the selection. The horn sounds
twice to indicate that the receiver
is in relearn mode.
8. Start with the left side front wheel.
9. Place the relearn tool against the tyre sidewall, near the valve stem.Then press the button to activate
the tyre pressure sensor. A horn
chirp confirms that the sensor
identification code has been
matched to this wheel position.
10. Proceed to the right side front wheel, and repeat the procedure
in Step 9.
11. Proceed to the right side rear wheel, and repeat the procedure
in Step 9.
12. Proceed to the left side rear wheel, and repeat the procedure
in Step 9. The horn sounds twice
to indicate that the sensor
identification code has been

168Vehicle careLiquid gas system9Danger
Liquid gas is heavier than air and
can collect in sink points.
Take care when performing work
at the underbody in a pit.
For painting work and when using a
drying booth at a temperature above
60 °C, the liquid gas tank must be
removed.
Do not make any modifications to the
liquid gas system.
Interior care
Interior and upholstery
Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light- coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

Service and maintenance169Service and
maintenanceGeneral information ...................169
Service information ..................169
Recommended fluids, lubricants and parts .................................... 170
Recommended fluids and lubricants ................................ 170General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 64.
European service intervals
Maintenance of your vehicle is
required every 20,000 miles or after
one year, whichever occurs first, unless otherwise indicated in theservice display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 64.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
one year, whichever occurs first, unless otherwise indicated in the
service display.
The international service intervals are valid for the countries which are notlisted in the European service
intervals.
Service display 3 64.

170Service and maintenanceConfirmations
Confirmation of service is recorded in the Service and Warranty Booklet.The date and mileage is completed
with the stamp and signature of the servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 64.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for petrol engines. If it is unavailable,
engine oils of other listed qualities
have to be used. Recommendations
for petrol engines are also valid for
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 174.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 174.

191Cupholders .................................. 49
Curtain airbag system .................. 41
D
Danger, Warnings and Cautions ...4
Daytime running lights .................89
Declaration of conformity ............183
Door open .................................... 73
Doors ............................................ 24
Driver assistance systems ..........119
Driver Information Centre .............73
Driving hints ................................ 103
E Electric adjustment ......................26
Electrical system......................... 144
Electronic climate control system 97
Electronic driving programmes ..113
Electronic Stability Control.......... 117
Electronic Stability Control and Traction Control system ............70
Electronic Stability Control off....... 70
End-of-life vehicle recovery .......132
Engine compartment fuse box ...146
Engine coolant ........................... 135
Engine coolant temperature ........71
Engine coolant temperature gauge ....................................... 64
Engine data ............................... 177
Engine exhaust .......................... 110
Engine identification ...................173Engine oil ................... 134, 170, 174
Engine oil pressure ......................71
Event data recorders ..................187
Exit lighting .................................. 93
Exterior care .............................. 166
Exterior light ................................. 72
Exterior lighting ......................12, 88
Exterior mirrors ............................. 26
F
Fault ........................................... 113
First aid ......................................... 54
First aid kit ................................... 54
Fixed air vents ........................... 101
Fog light ....................................... 72
Fog lights ................................... 140
Folding mirrors ............................. 26
Front airbag system .....................40
Front fog lights ............................. 90
Front seats.................................... 32
Front turn signal lights ...............141
Fuel............................................. 124
Fuel consumption - CO 2-
Emissions ............................... 130
Fuel for liquid gas operation .......125
Fuel for petrol engines ...............124
Fuel gauge ................................... 62 Fuel selector ................................ 63
Fuses ......................................... 144G
Gauges ......................................... 61
Gear shifting ................................. 70
Glovebox ..................................... 49
H Halogen headlights ....................139
Hand brake ......................... 114, 115
Hazard warning flashers ..............89
Headlight flash ............................. 88
Headlight range adjustment ........89
Headlights..................................... 88 Headlights when driving abroad ..89
Head restraint adjustment .............8
Head restraints ............................ 31
Heated mirrors ............................. 26
Heated rear window ..................... 29
Heated steering wheel .................57
Heating ........................................ 34
Heating and ventilation system ...94
High beam ............................. 72, 88
Hill start assist ........................... 115
Horn ....................................... 13, 58
I
Identification plate .....................173
Ignition switch positions .............104
Immobiliser ............................ 25, 72
Indicators ...................................... 61
Info display ................................... 78
Information displays...................... 73

193Seat heating................................. 34
Seat position ................................ 32
Selector lever ............................. 112
Service ....................................... 102
Service display ............................ 64
Service information ....................169
Service vehicle soon .................... 69
Side airbag system ......................41
Sidelights ...................................... 88
Side turn signal lights ................142
Software acknowledgement .......185
Spare wheel ............................... 161
Speed limiter......................... 72, 121
Speedometer ............................... 61
Starting and operating ................104
Starting off ................................... 16
Starting the engine ............105, 111
Steering ...................................... 104
Steering wheel adjustment ......9, 57
Steering wheel controls ...............57
Stop-start system........................ 106
Storage ......................................... 49
Storage compartments .................49
Sunroof ........................................ 29
Sun visors .................................... 29
Symbols ......................................... 4
T
Tachometer ................................. 62
Tail lights ................................... 141Three-point seat belt .................... 36
Tools .......................................... 149
Top-tether fastening eyes ............48
Towing ........................................ 165
Towing the vehicle .....................165
Traction Control system ............. 116
Traction Control system off........... 71
Transmission ............................... 15
Transmission display .................111
Tread depth ............................... 155
Trip odometer .............................. 62
Turn and lane-change signals .....90
Turn signal ................................... 67
Tyre chains ................................ 156
Tyre designations ......................150
Tyre pressure ............................ 150
Tyre pressure monitoring system ............................... 71, 151
Tyre pressures ........................... 182
Tyre repair kit ............................. 156
U Ultrasonic parking assist ...... 70, 122Upholstery .................................. 168
Using this manual ..........................3
V Valet mode ................................... 78
Vehicle battery ........................... 136
Vehicle checks............................ 133
Vehicle data ................................ 174Vehicle data recording and
privacy ..................................... 187
Vehicle dimensions .................... 180
Vehicle Identification Number ....172
Vehicle jack ................................ 149
Vehicle messages .......................79
Vehicle personalisation ...............82
Vehicle specific data ......................3
Vehicle storage ........................... 132
Vehicle tools ............................... 149
Vehicle unlocking ........................... 6 Vehicle weight ........................... 179
Ventilation ..................................... 94
W
Warning chimes ........................... 81
Warning lights ............................... 61
Warning triangle .......................... 53
Washer and wiper systems .........13
Washer fluid ............................... 135
Wheel changing .........................159
Wheel covers ............................. 155
Wheels and tyres .......................150
Windows ....................................... 27
Windscreen................................... 27
Windscreen wiper/washer ...........58
Winter tyres ............................... 150
Wiper blade replacement ..........138
