In brief9
Exterior mirrors
Manual adjustment
Swivel mirror in required direction.
The lower mirrors are not adjustable.
Exterior mirrors 3 35.
Electric adjustment
Select the relevant exterior mirror and
adjust it.
Convex exterior mirrors 3 35,
Electric adjustment 3 35, Folding
exterior mirrors 3 36, Heated
exterior mirrors 3 36.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage the lever and
ensure it is fully locked.
Do not adjust the steering wheel
unless vehicle is stationary and the steering wheel lock has been
released.
Airbag system 3 50, Ignition
positions 3 109.
Page 12 of 189
10In briefInstrument panel overview
Page 13 of 189
In brief11
1Side air vents ...................... 106
2 Ashtray .................................. 76
Cupholder ............................ 65
3 Light switch .......................... 91
Rear fog light ......................... 93
Front fog lights .....................93
Exit lighting ............................ 96
Turn and lane-change
signals ................................... 93
Sidelights .............................. 91
Headlight flash, low beam
and high beam ......................92
4 Instruments .......................... 76
5 Horn ...................................... 72
Driver airbag ......................... 53
6 Windscreen wiper,
windscreen washer system ..72
Rear window wiper, rear
window washer system ........73
Trip computer ....................... 887Card reader for electronic
key system ............................ 21
8 Steering column controls ......72
9 Centre air vents ................... 106
10 Power outlet .......................... 75
Cigarette lighter ..................... 75
Coin tray, USB slot ................ 64
11 Driver Information Centre ...... 86
Trip computer ....................... 88
12 Storage tray ......................... 64
13 Front passenger airbag .........53
14 Glovebox .............................. 64
15 Idle speed control ...............112
16 Heated exterior mirrors .........36
Heated rear window ..............38
17 Power outlet .......................... 75
Cigarette lighter ..................... 75
18 Climate control system .......... 97
Electronic climate control
system ................................... 9919 Ashtray .................................. 76
Cupholder ............................ 65
20 Central locking system ..........23
21 Hazard warning flashers .......93
22 Gear lever, Manual
transmission ........................ 116
23 Eco button for fuel
economy mode ...................108
24 Power button for electronic
key system .......................... 110
25 Stop-start system ................113
26 Cruise control and speed
limiter ................................. 120
27 Ignition switch with
steering wheel lock .............109
28 Steering wheel adjustment ...71
29 Remote control on
steering wheel ......................71
Cruise control .....................120
30 Storage compartment ...........64
31 Bonnet release lever ...........132
32 Fuse box ............................. 145
Page 14 of 189
12In brief
33Ultrasonic parking assist ....124
Electronic Stability
Program ............................. 119
Traction Control system ......118
Headlight range
adjustment ........................... 92
Instrument panel
illumination control ................94
34 Auxiliary heater ...................102Exterior lighting
Turn outer switch:
7=off8=sidelights9P=headlights
Vehicles with automatic light control:
AUTO=automatic light control:
exterior lighting is switched
on and off automatically
depending on external
lighting conditions.
Lighting 3 91, Automatic light
control 3 91, Headlight warning
device 3 87.
Page 15 of 189
In brief13
Front and rear fog lights
Turn inner switch
>=front fog lightsr=rear fog light
Front fog lights 3 93, Rear fog light
3 93.
Headlight flash, high beam and
low beamheadlight flash=pull leverhigh beam=push leverlow beam=push or pull lever
Automatic light control 3 91, High
beam 3 92, Headlight flash 3 92.
Turn and lane-change signalslever up=right turn signallever down=left turn signal
Turn and lane-change signals
3 93.
Page 16 of 189
14In brief
Hazard warning flashers
Operated with the ¨ button.
Hazard warning flashers 3 93.
Horn
Press j.
Washer and wiper systems
Windscreen wiper7=offK=interval wiping or automatic
wiping with rain sensor1=slow2=fast
Windscreen wiper 3 72, Wiper
blade replacement 3 139.
Page 17 of 189
In brief15
Windscreen and headlight
washer systems
Pull lever.
Windscreen and headlight washer
system 3 72, Washer fluid 3 136.
Rear window wiper and washer
system
Turn lever:
7=offe=wiperf=washer
Rear window wiper/washer 3 73,
Washer fluid 3 136.
Climate control
Heated rear window, heatedexterior mirrors
Heating is operated by pressing the
Ü button.
Heated exterior mirrors 3 36,
Heated rear window 3 38.
Page 18 of 189
16In brief
Demisting and defrosting the
windows
■ Air distribution to V.
■ Set temperature control to warmest
level.
■ Set fan speed to highest level.
■ Cooling AC on.
■ Heated rear window Ü on.
Climate control system 3 97,
Electronic climate control system 3 99.
Transmission
Manual transmission
Reverse: with the vehicle stationary,
wait 3 seconds after depressing
clutch pedal and then pull up the
collar on the selector lever and
engage the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then repeat
gear selection.
Manual transmission 3 116.
Starting off
Check before starting off ■ Tyre pressure and condition 3 149,
3 178.
■ Engine oil level and fluid levels 3 133.
■ All windows, mirrors, exterior lighting and number plates are free
from dirt, snow and ice and are
operational.
■ Proper position of mirrors, seats and seat belts 3 35, 3 41,
3 48.
■ Brake function at low speed, particularly if the brakes are wet.
Page 19 of 189
In brief17
Starting the engine with key
■ Turn key to position A
■ move the steering wheel slightly to release the steering wheel lock
■ operate clutch and brake pedal
■ do not operate accelerator pedal
■ diesel engines: turn the key to position M for preheating and wait
until control indicator !
extinguishes in the Driver
Information Centre.
■ turn key to position D and release
Starting the engine 3 111.
Starting the engine with the
power button
Electronic key must be inside the
vehicle, either in the card reader or
the front passenger compartment.
■ Move the steering wheel slightly to release the steering wheel lock
■ operate clutch and brake pedal
■ do not operate accelerator pedal
■ press Start/Stop button and release
■ engine starts after a short delay
Power button 3 110.
Stop-start system
If the vehicle is at low speed or in
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
■ Depress the clutch pedal
■ Move the selector lever to neutral
■ Release the clutch pedal
An Autostop is indicated when Ï
illuminates in the instrument cluster
3 85.
To restart the engine, depress the
clutch pedal again.
Stop-start system 3 113.
Page 20 of 189
18In briefParking■ Always apply parking brake without
pushing the release button. Apply
as firmly as possible on a downhill
or uphill slope. Depress foot brake
at the same time to reduce
operating force.
■ Switch off the engine. Turn the ignition key to position St and
remove it. Turn the steering wheel
until the steering wheel lock is felt
to engage.
■ If the vehicle is on a level surface or
uphill slope, engage first gear
before switching off the ignition. On
an uphill slope, turn the front
wheels away from the kerb.
If the vehicle is on a downhill slope, engage reverse gear before
switching off the ignition. Turn the
front wheels towards the kerb.
■ Lock the vehicle with button e on
the remote control.
Activate the anti-theft alarm system
3 33.■ Do not park the vehicle on an easily
ignitable surface. The high
temperature of the exhaust system
could ignite the surface.
■ Close the windows.
■ The engine cooling fans may run after the engine has been switchedoff 3 132.
■ After running at high engine speeds
or with high engine loads, operate the engine briefly at a low load or
run in neutral for approx.
30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 19, Laying the vehicle
up for a long period of time 3 131.
