Page 13 of 173
In brief11
1Ashtray .................................. 65
Cupholders ........................... 56
Fuse box ............................. 129
2 Fixed air vents ....................... 91
3 Side air vents ........................ 90
4 Light switch .......................... 79
Rear fog light ......................... 82
Front fog lights .....................81
Exit lighting ............................ 83
Turn and lane-change
signals ................................... 81
Sidelights .............................. 79
Headlight flash, low beam
and high beam ......................80
5 Instruments .......................... 65
Driver Information Centre ..... 74
Transmission display ............68
6 Horn ...................................... 61
Driver airbag ......................... 45
7 Steering column controls ......618Windscreen wiper,
windscreen washer system ..61
Rear window wiper, rear
window washer system ........62
Trip computer ....................... 76
9 Centre air vents ..................... 90
10 Triple-Info-Display .................74
11 Tachograph ........................... 78
12 Front passenger airbag .........45
13 Storage tray ......................... 55
14 Coin tray ............................... 55
15 Storage tray ......................... 55
16 Glovebox .............................. 55
17 Utility hook ........................... 10
18 Climate control system .......... 84
19 Hazard warning flashers .......81
20 Central locking system ..........20
Heated exterior mirrors .........29
Heated rear window ..............31Manual transmission
automated,
Winter and Laden modes ......99
Cruise control and speed
limiter ................................. 104
21 Gear lever, Manual
transmission .......................... 96
Manual transmission
automated ............................. 97
22 Power outlet .......................... 64
Cigarette lighter ..................... 64
23 Ignition switch with
steering wheel lock ...............94
24 Steering wheel adjustment ...60
25 Remote control on
steering wheel ......................60
Cruise control .....................104
26 Ultrasonic parking assist ....108
Headlight range
adjustment ........................... 80
Electronic Stability
Program ............................. 103
Traction Control system ......102
Page 57 of 173
Storage55StorageStorage compartments................55
Load compartment .......................56
Roof rack system .........................58
Loading information .....................58Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Instrument panel storage
Storage compartments, pockets and
trays are located in the instrument
panel.
A coin holder and/or a phone holder
are located on the top of the
instrument panel.
Glovebox
The glovebox features a sunglasses
holder.
Close the glovebox while driving.
Page 129 of 173
Vehicle care127Fog tail light
1. Remove 2 screws (using the toolsupplied) and remove lamp
assembly.
2. Twist bulb housing to separate from lamp assembly.
3. Renew bulb.
4. Push to install the bulb holder into
the lamp assembly - then twist to
secure.
5. Install lamp assembly with 2 screws.
Interior lights
Front courtesy light
1. Remove lens using a flat blade screwdriver.
2. Renew bulb.
3. Reinstall lens assembly.
Load compartment light
1. Remove lamp assembly using a flat blade screwdriver.
2. Gain access to bulb by removing rear cover on lamp assembly.
3. Renew bulb and install rear cover.
4. Reinstall lamp assembly.
Rear courtesy lights
Have bulbs replaced by a workshop.
Glovebox light
Have bulbs replaced by a workshop.
Page 169 of 173
167
Coolant and antifreeze...............147
Coolant heater .............................. 87
Coupling ball bar ........................113
Cruise control ...................... 73, 104
Cupholders .................................. 56
Curtain airbag system .................. 46
D Danger, Warnings and Cautions ...3
Dashboard .................................... 10
Daytime running light ....................79
Declaration of conformity ............164
Diesel fuel filter .......................... 122
Diesel fuel system bleeding .......123
Diesel particle filter ......................95
Doors ............................................ 24
Driver Information Centre .............74
Driving characteristics and towing tips .............................. 112
Driving hints .................................. 93
E Electric adjustment ......................28
Electrical system......................... 128
Electronic driving programmes ....99
Electronic Stability Program 72, 103
End-of-life vehicle recovery .......116
Engine air filter ........................... 119
Engine air flow indicator .............119
Engine coolant ........................... 119Engine coolant temperature ........72
Engine data ............................... 154
Engine exhaust ............................ 95
Engine identification ...................150
Engine oil ................... 117, 147, 152
Engine oil level ............................ 76
Engine oil level monitor ................67
Engine oil pressure ......................73
Event data recorders ..................164
Exhaust gases .............................. 95
Exit lighting .................................. 83
Exterior care .............................. 143
Exterior light ................................. 73
Exterior lighting ......................12, 79
Exterior mirrors ............................. 28
F
Fault ........................................... 100
First aid kit ................................... 58
Fixed air vents ............................. 91
Fog light ....................................... 73
Fog lights .............................. 81, 124
Fog tail light ............................... 127
Folding mirrors ............................. 28
Front airbag system .....................45
Front fog lights ............................. 81
Front seats.................................... 33
Front storage ............................... 56
Front turn signal lights ...............125
Fuel............................................. 109Fuel consumption - CO 2-
Emissions ............................... 111
Fuel for diesel engines ..............110
Fuel for petrol engines ...............109
Fuel gauge ................................... 66
Fuse box ..................................... 129
Fuses ......................................... 128
G Gauges ......................................... 65
General information ...................112
Glovebox ..................................... 55
H Hand brake - see Parking brake. 102
Hazard warning flashers ..............81
Headlight flash ............................. 80
Headlight range adjustment ........80
Headlights ...................... 79, 80, 124
Headlights when driving abroad ..81
Head restraint adjustment .............8
Head restraints ............................ 32
Heated mirrors ............................. 29
Heated rear window ..................... 31
Heating ........................................ 35
Heating and ventilation system ...84
High beam ............................. 73, 80
Horn ....................................... 14, 61
