140Vehicle careEngine air filterEngine air flow indicator
On certain models, an indicator is
located in the engine induction
system and indicates if the air-intake
to the engine is restricted.
Clear=No restrictionRed tell-tale=Restricted
If the red tell-tale is displayed when
the engine is running, consult a
workshop.
Engine coolant
The coolant provides freeze
protection down to approx. -28 °C.Caution
Only use approved antifreeze.
Coolant level
Caution
Too low a coolant level can cause engine damage.
If the cooling system is cold, the
coolant level should be just above the
MINI mark. Top up if the level is low.9Warning
Allow the engine to cool before
opening the cap. Carefully open
the cap, relieving the pressure
slowly.
Top up with antifreeze. If no
antifreeze is available, use clean tap
water or distilled water. Install the cap
tightly. Have the antifreeze
concentration checked and have the
cause of the coolant loss remedied by a workshop.
If a substantial amount of coolant is
required, it will be necessary to bleed
any trapped air from the cooling
system. Seek the assistance of a
workshop.
If the coolant temperature is too high, control indicator W 3 86 illuminates
red in the instrument cluster, together
with C 3 84. Consult a workshop if
coolant level is sufficient.

154Vehicle care
No.Circuit1Vehicle battery (with electronic
key system)2APC battery backup (with elec‐
tronic key system)3Heating and ventilation system4Adaptations5Adaptations6Heating and ventilation system7Additional heating and ventila‐
tion, air conditioning system8Supplementary heating and
ventilation system9Electric exterior mirrors, addi‐
tional adaptations10Heated exterior mirrors11Radio, multimedia, electric exte‐ rior mirrors, diagnostic socket12Multimedia, trailer hitchNo.Circuit13Courtesy lights, battery
discharge protection14Fuel injection system, tyre pres‐ sure monitoring system, elec‐
tronic key system15Hazard warning flashers, turn and lane-change signals16Central locking17Left-hand high beam, right-hand
low beam, tail lights, left-hand
daytime running light18Front fog lights, rear fog lights,
number plate lighting19Alarm, horn, lighting, wiper20Instrument cluster21Light switch22Rear window wiper, windscreen
washer pump, horn23APC general battery24Reversing lightsNo.Circuit25Brake switch26Fuel injection, starter27Airbag, steering column lock28Passenger power window29Power steering30Brake lights31APC battery backup (with elec‐
tronic key system)32Service display33Cigarette lighter, power outlet34Right-hand high beam, left-
hand low beam, sidelights,
right-hand daytime running light35Brake lights, ABS, immobiliser36Interior lighting, air conditioning37Starting with electronic key
system38Rear window wiper

Vehicle care157
Tyre pressures 3 190. Always inflate
tyres to the pressures shown on the label on the driver's door frame.
The tyre pressure data refers to cold
tyres. It applies to summer and winter tyres.
Always inflate the spare tyre to the
pressure specified for full load.
Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.
Tyre pressures differ depending on
various options. For the correct tyre
pressure value, follow the procedure
below:
1. Identify the engine identifier code.
Engine data 3 180.
2. Identify the respective tyre.
The tyre pressure tables show all
possible tyre combinations 3 190.
For the tyres approved for your
vehicle, refer to the EEC Certificate of
Conformity provided with your vehicle
or other national registration
documents.The driver is responsible for correct
adjustment of tyre pressure.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
Tyre pressure monitoring
system
The Tyre Pressure Monitoring
System (TPMS) uses radio and
sensor technology to check tyre
pressure levels.
Caution
Tyre pressure monitoring system
warns only about low tyre pressure condition and does not replace
regular tyre maintenance by the
driver.
All wheels must be equipped with pressure sensors and the tyres must
have the prescribed pressure.
Notice
In countries where the tyre pressure
monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle type approval.
The TPMS sensors monitor the air
pressure in the tyres and transmit tyre pressure readings to a receiver
located in the vehicle.
Tyre pressures in display The current tyre pressures can be
shown in the Driver Information
Centre 3 88.

158Vehicle care
With the vehicle stationary, press
button on end of wiper lever
repeatedly until the tyre pressure
menu is displayed.
Low tyre pressure condition
A detected low tyre pressure
condition is indicated by illumination
of control indicator w 3 86 and a
corresponding message appears in
the Driver Information Centre.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 190.
After inflating, some driving may be
required to update the tyre pressure
values in the Driver Information
Centre. During this time w may
illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for getting low pressure. Check tyre pressure.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w flashes for
several seconds then illuminates continuously together with control
indicator A 3 84 and a
corresponding message appears in
the Driver Information Centre.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. TPMS is not operational for these wheels. For the further three
wheels, TPMS remains operational.
Control indicator w and the
corresponding message appears at
each ignition cycle until the tyres are
inflated to the correct tyre pressure.
Driver Information Centre 3 88.
Vehicle messages 3 89.

Vehicle care159
Puncture
A puncture or severely under-inflated
tyre is indicated by illumination of
control indicator w together with C
3 84 and a corresponding message
appears in the Driver Information
Centre. Stop vehicle and switch off
engine.
Tyre pressure 3 190, Tyre repair kit
3 161, Spare wheel 3 165, Wheel
changing 3 164.
Temperature dependency Tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase.
The tyre pressure value displayed in
the Driver Information Centre shows
the actual tyre pressure. Therefore it
is important to check tyre pressure
with cold tyres.Relearn function
After changing the wheels, TPMS
needs to recalculate.
With the vehicle stationary, select the tyre pressure menu in the Driver
Information Centre by pressing button
on end of wiper lever. Press and hold button for approx. 3 seconds to
initialise recalculation. A
corresponding message appears in
the Driver Information Centre.
Several minutes of driving may be
required to complete the relearn
process.
If problems occur during the relearn
process, control indicator w remains
illuminated and a warning message is displayed in the Driver Information
Centre.
Driver Information Centre 3 88.
Vehicle messages 3 89.
General information
The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved tyre repair kits can be used.
Tyre repair kit 3 161.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.
Each time the tyres are replaced,
TPMS sensors must be dismounted
and serviced by a workshop.
Tread depth
Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).

Vehicle care171
Unpainted plastic body parts must notbe treated with wax or polishing
agents.
Matt filmed body parts or decor tapes
must not be polished, to avoid
gleaming. Do not use hot wax
programmes in automatic car washes if the vehicle is equipped with theseparts.
Matt painted decor parts, e.g. mirror housing cover, must not be polished.
Otherwise these parts would become agleam or the colour would be
dissolved.
Windows and windscreen wiper blades
Use a soft lint-free cloth or chamois
leather together with window cleaner
and insect remover.
When cleaning the rear window from
inside, always wipe in parallel to the
heating element to prevent damage.
For mechanical removal of ice, use a
sharp-edged ice scraper. Press the
scraper firmly against the glass so
that no dirt can get under it and
scratch the glass.Clean smearing wiper blades with a
soft cloth and window cleaner.
Wheels and tyres
Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.
Paintwork damageRectify minor paintwork damage witha touch-up pen before rust forms.
Have more extensive damage or rust
areas repaired by a workshop.
Underbody
Some areas of the vehicle underbody
have a PVC undercoating while other critical areas have a durable
protective wax coating.
After the underbody is washed, check
the underbody and have it waxed if
necessary.Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Towing equipment
Do not clean the coupling ball bar with a steam-jet or high-pressure jet
cleaner.
Interior care
Interior and upholstery Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean any leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.

Service and maintenance173Service and
maintenanceGeneral information ...................173
Recommended fluids, lubricants and parts .................................... 174General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for the vehicle is available at
the workshop.
Service display 3 80.
Engine identification 3 177.
European service intervals
Maintenance of your vehicle is
required every 25,000 miles or after
2 years, whichever occurs first,
unless otherwise indicated by the
service display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display
The service interval is based on
several parameters depending on
usage.
The service display, located in the
Driver Information Centre, indicates
when the next service is due. Seek
the assistance of a workshop.
Service display 3 80.

176Technical dataTechnical dataVehicle identification..................176
Vehicle data ............................... 179Vehicle identification
Vehicle Identification
Number
The Vehicle Identification Number is
visible through the windscreen.
The VIN is also displayed behind a
removable plastic cover on the right-
hand side door step.

196
Front door pockets........................ 66
Front fog lights ........................ 93, 96
Front seats.................................... 42 Front storage ................................ 66
Front turn signal lights ...............147
Fuel consumption - CO 2-
Emissions ............................... 133
Fuel cut-off system .....................115
Fuel economy gauge ....................80
Fuel economy mode .....................87
Fuel economy rating ...............89, 90
Fuel for diesel engines ..............132
Fuel gauge ................................... 80 Fuse box ..................................... 152
Fuses ......................................... 150
G Gauges ......................................... 78
General information ...................134
Glovebox ..................................... 65
Glovebox cooler ......................... 108
Glove box lighting .........................97
H Hand brake - see Parking brake. 121
Hazard warning flashers ..............95
Headlight flash ............................. 94
Headlight range adjustment ........94
Headlights ...................... 93, 94, 146
Headlights when driving abroad ..94Head restraint adjustment .............8
Head restraints ............................ 41
Heated exterior mirrors .................15
Heated mirrors ............................. 37
Heated rear window ...............15, 40
Heating ........................................ 45
Heating and ventilation system ...99
High beam ............................. 87, 94
Hill start assist ........................... 121
Horn ....................................... 14, 74
I
Identification plate .....................177
Idle speed control .......................114
Ignition switch positions .............112
Immobiliser .................................. 35
Indicators ...................................... 78
Info-display ................................... 88
Information displays...................... 88
Initial drive information.................... 6
Instrument cluster ........................78
Instrument panel fuse box .........152
Instrument panel illumination .....150
Instrument panel illumination control ...................................... 96
Instrument panel overview ........... 10
Instrument panel storage ..............65
Interior care ............................... 171
Interior lighting .............................. 96
Interior lights ........................ 97, 149Interior mirrors.............................. 37
Introduction .................................... 3
Isofix child restraint systems ........ 64
J Jack ............................................ 155
Journey record.............................. 90
Jump starting ............................. 167
K Keys ............................................. 19
Keys, locks ................................... 19
L
Lashing eyes ............................... 69
Light covers, misted...................... 96
Lighting ......................................... 93
Lighting features ........................... 98
Light switch .................................. 93
Load compartment ....................... 31
Load compartment cover .............68
Load compartment lighting ...........97
Loading information .....................71
Load-through feature ....................67
Low fuel ....................................... 87
M
Malfunction indicator light ............84
Manual adjustment ......................36
Manual anti-dazzle ......................37

197
Manual transmission .................. 119
Messages ..................................... 89
Mirror adjustment ........................... 8
Mirrors .................................... 36, 37
Misted light covers .......................96
N
New vehicle running-in ..............111
Number plate light .....................149
O Object detection systems ...........128
Octane rating .............................. 180
Odometer ..................................... 79
Oil ............................................... 138
Oil, engine .......................... 174, 179
Oil pressure .................................. 86
Outside temperature ....................76
Overcab storage ..........................68
Overrun cut-off ........................... 115
P Parking ................................ 18, 117
Parking assist ............................ 128
Parking brake ............................ 121
Particulate filter ........................... 118
Performing work ........................137
Pollen filter ................................. 109
Power button ........................ 17, 112
Power outlets ............................... 77Power steering fluid....................141
Power windows ............................ 38
Preheating ........................... 86, 114
Puncture ..................................... 164
R Radio Frequency Identification (RFID) ..................................... 192
Radio remote control ...................19
Rear air conditioning system .....103
Rear doors ................................... 29
Rear fog light ............................... 87
Rear fog lights ........................ 93, 96
Rear heating system .................. 103
Rear seats .................................... 45
Rear view camera ...................... 130
Rear windows .............................. 39
Rear window wiper/washer .......... 75 Recommended fluids and lubricants ........................ 174, 179
Refuelling ................................... 132
Remote control ............................. 19
Reversing light ........................... 148
Reversing lights ........................... 96
Ride control systems ..................122
Roof load ...................................... 71
Roof rack ..................................... 71S
Safety belts ................................... 48
Safety net .................................... 69
Seat adjustment ....................... 7, 43
Seat belt ........................................ 8
Seat belt reminder .......................83
Seat belts ..................................... 48
Seat folding .................................. 44
Seat heating ................................. 45
Seat position ................................ 42
Seats ............................................ 67
Service ............................... 109, 173
Service display ............................ 80
Service information ....................173
Service vehicle soon .................... 84
Side airbag system ......................55
Sidelights ...................................... 93
Side turn signal lights ................148
Sliding door .................................. 29
Spare wheel ............................... 165
Spare wheel security tool ...........155
Speed limiter......................... 78, 128
Speedometer ............................... 78
Starting and operating ................111
Starting off ................................... 17
Starting the engine ...............17, 114
Steering ...................................... 111
Steering column controls ..............74
Steering wheel adjustment ......9, 73
