Driving and operating137Fault
If a fault occurs in the stop-start
system, the LED in Î illuminates,
and a corresponding message
appears in the Driver Information
Centre 3 100 . Seek the assistance of
a workshop.
Vehicle messages 3 101.
Warning chimes 3 102.
Parking9 Warning
● Do not park the vehicle on an
easily ignitable surface. The
high temperature of the
exhaust system could ignite the
surface.
● Always apply parking brake without pressing release
button. Apply as firmly as
possible on a downhill slope or
uphill slope. Depress brake
pedal at the same time to
reduce operating force.
● Switch off the engine.
● If the vehicle is on a level surface or uphill slope, engage
first gear. On an uphill slope,
turn the front wheels away from
the kerb.
If the vehicle is on a downhill
slope, engage reverse gear.
Turn the front wheels towards the kerb.
● Close the windows.
● Remove the ignition key from the ignition switch. Turn the
steering wheel until the
steering wheel lock is felt to
engage.
● Lock the vehicle by pressing e on
the remote control 3 24.
Activate the anti-theft alarm
system 3 36.
● The engine cooling fans may run
after the engine has been
switched off 3 164.
Caution
After running at high engine
speeds or with high engine loads,
operate the engine briefly at a low load or run in neutral for approx.30 seconds before switching off, in
order to protect the turbocharger.
Vehicle storage 3 163.

Customer information223● vehicle reactions in particulardriving situations (e.g. inflation ofan airbag, activation of the
stability regulation system)
● environmental conditions (e.g. temperature)
These data are exclusively technical
and help identifying and correcting
errors as well as optimising vehicle
functions.
Motion profiles indicating travelled
routes cannot be created with these
data.
If services are used (e.g. repair
works, service processes, warranty
cases, quality assurance),
employees of the service network
(manufacturer included) are able to
read out this technical information
from the event and error data storage
modules applying special diagnostic
devices. If required, you will receive
further information at these
workshops. After an error has been
corrected, the data are deleted from
the error storage module or they are
constantly overwritten.When using the vehicle, situations
may occur in which these technical
data related to other information
(accident report, damages on the
vehicle, witness statements etc.) may
be associated with a specific person - possibly, with the assistance of an
expert.
Additional functions contractually
agreed upon with the client (e.g.
vehicle location in emergency cases)
allow the transmission of particular vehicle data from the vehicle.
Radio Frequency
Identification (RFID)
RFID technology is used in some vehicles for functions such as tyre
pressure monitoring and ignition
system security. It is also used in
connection with conveniences such
as radio remote controls for door
locking/unlocking and starting, and in-
vehicle transmitters for garage door
openers. RFID technology in
Vauxhall vehicles does not use or
record personal information or link with any other Vauxhall system
containing personal information.

227JJack ............................................ 183
Journey record............................ 103
Jump starting ............................. 195
K
Keys ............................................. 19
Keys, locks ................................... 19
L
Lashing eyes ............................... 77
Lashing straps .............................. 77
Laying up the vehicle ..........163, 169
LED spotlights ............................ 110
Light covers, misted.................... 110
Lighting ....................................... 106
Lighting features .........................112
Light switch ................................ 106
Load compartment ................33, 76
Load compartment cover .............77
Load compartment grille ...............79
Load compartment lighting .........112
Loading information .....................80
Load-through feature ....................74
Low fuel ....................................... 99
Luggage floor net .........................77
M
Malfunction indicator light ............96
Manual adjustment ......................39
Manual anti-dazzle ......................40Manual transmission .................. 145
Maximum speed limiter............... 153
Messages ................................... 101
Mirror adjustment ........................... 8
Mirrors .................................... 39, 40
Misted light covers .....................110
N New vehicle running-in ..............130
Number plate light .....................177
O
Object detection systems ...........153
Odometer ..................................... 89
Oil ............................................... 165
Oil, engine .................. 165, 202, 206
Oil pressure .................................. 98
Outside temperature ....................85
Overcab storage ..........................76
Overrun cut-off ........................... 134
P Parking ................................ 18, 137
Parking assist ............................ 153
Parking brake ............................ 146
Particulate filter ........................... 138
Pedals......................................... 129
Performing work ........................164
Phone controls.............................. 83
Phone holder ................................ 71
Pollen filter ................................. 126Power button........................ 17, 130
Power outlets ............................... 86
Power steering fluid ....................167
Power windows ............................ 42
Preheating ........................... 98, 132
Puncture ..................................... 192
R
Radio Frequency Identification (RFID) ..................................... 223
Radio remote control ...................20
REACH ....................................... 222
Reading lights ............................ 112
Rear air conditioning system .....119
Rear courtesy lights ....................110
Rear door manual lock .................24
Rear doors .............................. 24, 31
Rear fog light ............................... 99
Rear fog lights ....................106, 110
Rear heating system .................. 118
Rear parcel shelf .......................... 77
Rear seats ................................... 49
2nd row seats ............................ 49
3rd row seats............................. 49
Folding ...................................... 49
Installing .................................... 49
Rear seat access ......................49
Removing .................................. 49
Seat cushion adjustment ...........49
Rear seats lights .........................110

228Rear view camera ...................... 155
Rear windows .............................. 42
Rear window wiper/washer .......... 85
Recommended fluids and lubricants ........................ 202, 206
Refuelling ................................... 158 Registered trademarks ...............222
Remote control ............................. 20
Restraining lattice .........................79
Reversing light ........................... 176
Reversing lights .........................110
Ride control systems ..................147
Roof load ...................................... 80
Roof rack ..................................... 80
S Safety belts ................................... 53
Safety net .................................... 78
Seat adjustment ....................... 7, 46
Seat belt ........................................ 8
Seat belt reminder .......................95
Seat belts ..................................... 53
Seat folding .................................. 48
Seat heating ................................. 48
Seat position ................................ 45
Seats ............................................ 74
Selective catalytic reduction .......139
Service ............................... 127, 201
Service display ............................ 91
Service information ....................201Service vehicle soon .................... 96
Side airbag system ......................61
Sidelights .................................... 106
Side turn signal lights ................175
Sliding door .................................. 31
Sliding side door ........................... 31
Spare wheel ............................... 193
Spare wheel security tool ...........183
Speed limiter......................... 89, 153
Speedometer ............................... 89
Starting and operating ................130
Starting off ................................... 17
Starting the engine ...............17, 132
Steering ...................................... 129
Steering column controls ..............83
Steering wheel adjustment ......9, 83
Steering wheel controls ...............83
Stop engine .................................. 96
Stop-start system............ 17, 99, 134
Storage ......................................... 71
Storage box .................................. 74
Storage compartment ...................73
Storage compartments .................71
Sun visors .................................... 43
Symbols ......................................... 4
T
Tablet holder................................. 71
Tachograph ........................ 100, 105
Tachometer ................................. 90Tailgate......................................... 33
Tailgate emergency release .........33
Tail lights ................................... 174
Technical data ............................ 207
Temporary spare wheel ..............193
Three-point seat belt .................... 54
Toll road stickers .......................... 41
Tools .......................................... 183
Top-Tether .................................... 63
Torx key ...................................... 183
Touchscreen ............................... 100
Tow bar....................................... 160
Towing ................................ 160, 196
Towing another vehicle .............197
Towing a trailer ........................... 161
Towing eye ......................... 183, 196
Towing the vehicle .....................196
Traction Control system ............. 147
Trailer coupling ........................... 160
Trailer stability assist .................161
Trailer towing ............................. 161
Transmission ............................... 16
Tread depth ............................... 188
Trip computer ............................ 103
Trip odometer .............................. 89
Turbo engine warm-up ...............132
Turn and lane-change signals ...109
Turn signal ................................... 94
Tyre chains ................................ 189
Tyre changing ............................. 192
