256Vehicle careClean the leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

Service and maintenance257Service and
maintenanceGeneral information ...................257
Service information ..................257
Recommended fluids, lubricants and parts .................................... 258
Recommended fluids and lubricants ................................ 258General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 106.
European service intervals Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 106.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold starting, stop and go operation, trailer
operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

258Service and maintenancedriving at high altitude and large
variations of temperature. Under
these severe operating conditions,
certain service work may be required more frequently than the regular
service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 106.
Confirmations Confirmation of service is recorded inthe Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 106.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

286GGauges ....................................... 103
Gear shifting ............................... 113
General information ...................207
Glass panel .................................. 33
Glovebox ..................................... 65
H Halogen headlights ....................221
Hand brake ................................. 165
Hazard warning flashers ............136
Headlight flash ........................... 133
Headlight range adjustment ......133
Headlights................................... 131 Headlights when driving abroad 134
Head restraint adjustment .............8
Head restraints ............................ 35
Heated mirrors ............................. 29
Heated rear window ..................... 33
Heated steering wheel .................96
Heating ........................................ 42
Heating and ventilation system . 141
High beam ......................... 115, 132
High beam assist ................115, 132
Hill start assist ........................... 167
Horn ....................................... 13, 97
I
Identification plate .....................261
Ignition switch positions .............150
Immobiliser .......................... 28, 115Indicators.................................... 103
Info display ................................. 121
Information displays.................... 116
Instrument cluster ......................103
Instrument panel fuse box .........232
Instrument panel illumination .....228
Instrument panel illumination control .................................... 138
Instrument panel overview ........... 10
Interactive driving system ...........170
Interior care ............................... 255
Interior lighting ............................ 138
Interior lights ...................... 138, 228
Interior mirrors .............................. 29
Interruption of power supply ......163
Introduction .................................... 3
J
Jump starting ............................. 250
K Keys ............................................. 19
Keys, locks ................................... 19
L Lane departure warning .....113, 196
Lashing eyes ............................... 87
LED headlights ...........115, 135, 223
Lighting features .........................139
Light switch ................................ 131
Load compartment ................24, 78Load compartment cover .............80
Load compartment fuse box ......233
Loading information .....................93
Load rails and hooks ...................87
Low fuel ..................................... 115
M Malfunction indicator light ..........111
Manual anti-dazzle ......................29
Manual mode ............................. 162
Manual seat adjustment ...............38
Manual transmission .................. 164
Manual windows ..........................30
Memorised settings ......................21
Mirror adjustment ........................... 8
Misted light covers .....................137
N
New vehicle running-in ..............150
Number plate light .....................227
O Object detection systems ...........187
Odometer ................................... 103
Oil, engine .................. 215, 258, 263
OnStar ........................................ 127
Operate pedal ............................. 112
Outside temperature ....................99
Overhead console .......................67
Overrun cut-off ........................... 152

287PParking ................................ 18, 155
Parking assist ............................ 187
Parking brake ............................ 165
Parking lights ............................. 137
Particulate filter ........................... 156
Performance .............................. 268
Performing work ........................214
Pollen filter ................................. 148
Power outlets ............................. 101
Power seat adjustment ................40
Power steering............................ 113
Power steering fluid ....................217
Power windows ............................ 31
Preheating ................................. 114
Puncture ..................................... 244
Q Quickheat ................................... 147
R
Radio Frequency Identification (RFID) ..................................... 282
Radio remote control ...................20
Reading lights ............................ 139
Rear carrier system ......................69
Rear floor storage cover ..............82
Rear fog light .....................115, 137
Rear seats .................................... 43
Rear storage ................................. 80
Rear view camera ...................... 191Rear window wiper/washer .......... 99
Recommended fluids and lubricants ........................ 258, 263
Refuelling ................................... 201
Registered trademarks ...............281
Retained power off .....................151
Reversing lights .........................137
Ride control system ....................168
Roller blinds ................................. 33
Roof .............................................. 33
Roof load ...................................... 93
Roof rack ..................................... 92
S Safety net .................................... 89
Seat adjustment ............................. 6
Seat belt ........................................ 8
Seat belt reminder .....................110
Seat belts ..................................... 49
Seat heating ................................. 42
Seat position ................................ 37
Second row seats ........................43
Selective catalytic reduction .......158
Selector lever ............................. 161
Service ............................... 148, 257
Service display .......................... 106
Service information ....................257
Side airbag system ......................56
Side blind spot alert ....................189
Sidelights .................................... 131Side turn signal lights ................227
Software acknowledgement .......279
Spare wheel ............................... 247
Speed limiter....................... 116, 173
Speedometer ............................. 103
Starting and operating ................150
Starting off ................................... 16
Starting the engine ....................151
Steering ...................................... 150
Steering wheel adjustment ......9, 96
Steering wheel controls ...............96
Stop-start system........................ 153
Storage ......................................... 65
Storage compartments .................65
Sunvisor lights ........................... 139
Sun visors .................................... 33
Symbols ......................................... 4
T
Tachometer ............................... 104
Tail lights ................................... 224
Third row seats ............................ 47
Three-point seat belt .................... 50
Tools .......................................... 235
Tow bar....................................... 207
Towing ................................ 207, 251
Towing another vehicle .............252
Towing equipment .....................208
Towing the vehicle .....................251
Traction Control system ............. 168

288Traction Control system off......... 113
Traffic sign assistant ...........116, 193
Trailer coupling ........................... 207
Trailer stability assist .................211
Trailer towing ............................. 208
Transmission ............................... 15
Transmission display .................161
Tread depth ............................... 240
Trip odometer ............................ 103
Turn and lane-change signals ...136
Turn signal ................................. 109
Tyre chains ................................ 241
Tyre designations ......................235
Tyre pressure ............................ 236
Tyre pressure monitoring system ............................. 114, 237
Tyre pressures ........................... 273
Tyre repair kit ............................. 241
U
Ultrasonic parking assist............. 187
Underseat storage .......................67
Upholstery .................................. 255
Using this manual ..........................3
V Vehicle battery ........................... 218
Vehicle checks............................ 214
Vehicle data ................................ 263
Vehicle data recording and privacy ..................................... 281Vehicle detected ahead..............116
Vehicle dimensions .................... 270
Vehicle Identification Number ....261
Vehicle jack ................................ 235
Vehicle messages .....................122
Vehicle personalisation .............124
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 213
Vehicle tools ............................... 235
Vehicle unlocking ........................... 6
Vehicle weight ........................... 269
Ventilation ................................... 141
W
Warning chimes .........................123
Warning lights ............................. 103
Warning triangle .......................... 91
Washer and wiper systems .........13
Washer fluid ............................... 218
Wheel changing .........................244
Wheel covers ............................. 241
Wheels and tyres .......................235
Windows ....................................... 30
Windscreen................................... 30
Windscreen wiper/washer ...........97
Winter tyres ............................... 235
Wiper blade replacement ..........220
