244Vehicle care
Turn the adjuster wheel to select the
tyre pressure monitoring system.
System status and pressure warnings are displayed by a message with the
corresponding tyre flashing in the
Driver Information Centre.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 111.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 279.
After inflating, driving may be
required to update the tyre pressure
values in the DIC. During this time w
may illuminate.
If w illuminates up at lower
temperatures and extinguishes after
some driving, this could be an
indicator for getting low pressure.
Check tyre pressure.
Vehicle messages 3 120.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operational
for these wheels. Control indicator w
illuminates. For the further three
wheels the system remains
operational.The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.
Each time the tyres are replaced, tyre pressure monitoring system sensors
must be dismounted and serviced. For the screwed sensor, replace
valve core and sealing ring. For
clipped sensor, replace complete
valve stem.
Vehicle loading status Adjust tyre pressure to load condition according to the tyre information labelor tyre pressure chart 3 279, and
select the appropriate setting in the menu Tire Load in the Driver
Information Centre, Vehicle
Information Menu 3 114.

Vehicle care245
Select:■ Light for comfort pressure up to
3 people
■ Eco for Eco pressure up to
3 people
■ Max for full loading
Auto learn function
After changing wheels, the vehicle
must be stationary for approx.
20 minutes, before the system
recalculates. The following relearn process takes up to 10 minutes of
driving with a minimum speed of
12 mph. In this case $ can be
displayed or pressure values can
swap in the Driver Information Centre.
If problems occur during the relearn
process, a warning message is
displayed in the Driver Information
Centre.
Temperature dependency Tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase.
The tyre pressure value displayed in
the Driver Information Centre shows
the actual tyre pressure. Therefore it
is important to check tyre pressure
with cold tyres.
Tread depth Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).For safety reasons, it is
recommended that the tread depth of
the tyres on one axle should not vary
by more than 2 mm.
The legally permissible minimum
tread depth (1.6 mm) has been
reached when the tread has worn
down as far as one of the tread wear
indicators (TWI). Their position is
indicated by markings on the
sidewall.
If there is more wear at the front than
the rear, swap round front wheels and
rear wheels periodically. Ensure that
the direction of rotation of the wheels
remains the same.

Vehicle care261
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.
Paintwork damage Rectify minor paintwork damage with
a touch-up pen before rust forms.
Have more extensive damage or rust
areas repaired by a workshop.
Underbody
Some areas of the vehicle underbody
have a PVC undercoating while other critical areas have a durable
protective wax coating.
After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.Liquid gas system9 Danger
Liquid gas is heavier than air and
can collect in sink points.
Take care when performing work
at the underbody in a pit.
For painting work and when using a
drying booth at a temperature above
60 °C, the liquid gas tank must be
removed.
Do not make any modifications to the
liquid gas system.
Towing equipment Do not clean the coupling ball bar with
a steam-jet or high-pressure jet
cleaner.
Rear carrier system Clean the rear carrier system with a
steam-jet or high-pressure jet cleaner
at least once a year.
Operate the rear carrier system
periodically if not in regular use, in
particular during winter.
Air shutter
Clean the shutter system in the front
bumper to maintain correct
functionality.
Interior care Interior and upholsteryOnly clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.

Service and maintenance263Service and
maintenanceGeneral information ...................263
Recommended fluids, lubricants and parts .................................... 264General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 104.
European service intervals
Maintenance of your vehicle is
required every 20000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The European service intervals are
valid for the following countries:
Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Macedonia,
Malta, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
Serbia, Slovakia, Slovenia, Spain,
Sweden, Switzerland, United
Kingdom.
Service display 3 104.
International service intervals Maintenance of your vehicle is
required every 10000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not listed in the European service
intervals.
Service display 3 104.
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.

264Service and maintenance
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining
engine oil life duration The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 104.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 268.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.

288
GGauges ....................................... 101
General information ...................212
Glass panel .................................. 33
Glovebox ..................................... 62
Graphic-Info-Display, Colour- Info-Display ............................ 118
H Halogen headlights ....................226
Hand brake ......................... 167, 168
Hazard warning flashers ............139
Headlight flash ........................... 134
Headlight range adjustment ......134
Headlights................................... 132
Headlights when driving abroad 135
Head restraint adjustment .............8
Head restraints ............................ 35
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heated steering wheel .................94
Heating ........................................ 42
Heating and ventilation system . 144
High beam ......................... 113, 133
High beam assist ................113, 133
Hill start assist ........................... 169
Horn ....................................... 14, 94I
Identification plate .....................266
Ignition switch positions .............154
Immobiliser .......................... 27, 112
Indicators .................................... 101
Information displays.................... 114
Instrument cluster ......................101
Instrument panel fuse box .........238
Instrument panel illumination .....234
Instrument panel illumination control .................................... 141
Instrument panel overview ........... 10
Instrument panel storage ..............62
Interactive driving system ...........171
Interior care ............................... 261
Interior lighting ............................ 141
Interior lights ...................... 141, 234
Interior mirrors .............................. 29
Interruption of power supply ......165
Introduction .................................... 3
ISOFIX child restraint systems ....61
J Jump starting ............................. 256
K Keys ............................................. 19
Keys, locks ................................... 19L
Lane departure warning .....110, 201
Lashing eyes ............................... 85
Lighting features .........................142
Light switch ................................ 132
Load compartment ................24, 75
Load compartment cover .............78
Load compartment fuse box ......239
Loading information .....................91
Load rails and hooks ...................85
Low fuel ..................................... 112
Low washer fluid ........................113
M Malfunction indicator light ..........108
Manual anti-dazzle ......................29
Manual mode ............................. 164
Manual transmission .................. 166
Manual windows ..........................30
Memorised settings ......................21
Mirror adjustment ........................... 9
Misted light covers .....................140
N New vehicle running-in ..............154
Number plate light .....................233
O
Object detection systems ...189, 191
Odometer ................................... 101

289
Oil, engine.................. 219, 264, 268
Operate pedal ............................. 109
Outside temperature ....................97
Overhead console .......................64
Overrun cut-off ........................... 155
P Parking ................................ 18, 158
Parking assist ............................ 189
Parking brake ............................ 168
Parking lights ............................. 140
Particulate filter ........................... 159
Performance .............................. 274
Performing work ........................218
Pollen filter ................................. 151
Power outlets ............................... 99
Power seat adjustment ................40
Power steering............................ 110
Power steering fluid ....................221
Power windows ............................ 30
Preheating ................................. 111
Puncture ..................................... 249
Q
Quickheat ................................... 150
R Radio Frequency Identification (RFID) ..................................... 285
Radio remote control ...................20Reading lights ............................ 142
Rear carrier system ......................67
Rear floor storage cover ..............80
Rear fog light ............................. 113
Rear fog lights ........................... 140
Rear seats .................................... 43
Rear storage ................................. 78
Rear view camera ...................... 196
Rear window wiper/washer .......... 97 Recommended fluids and lubricants ........................ 264, 268
Reduced engine power ..............112
Refuelling ................................... 206
Retained power off .....................154
Reversing lights .........................140
Ride control system ....................170
Roller blinds ................................. 32
Roof .............................................. 33
Roof load ...................................... 91
Roof rack ..................................... 90
S Safety net .................................... 87
Seat adjustment ....................... 6, 37
Seat belt ........................................ 8
Seat belt reminder .....................107
Seat belts ..................................... 49
Seat position ................................ 37
Second row seats ........................43
Selective catalytic reduction .......160Selector lever ............................. 163
Service ............................... 152, 263
Service display .......................... 104
Service information ....................263
Service vehicle soon .................. 109
Side airbag system ......................54
Side blind spot alert ....................195
Sidelights .................................... 132
Side turn signal lights ................233
Spare wheel ............................... 252
Speed limiter............................... 175
Speedometer ............................. 101
Starting and operating ................154
Starting off ................................... 17
Starting the engine ....................154
Steering ...................................... 153
Steering wheel adjustment ......9, 93
Steering wheel controls ...............93
Stop-start system........................ 156
Storage ......................................... 62
Storage compartment ...................62
Storage compartments .................62
Sunvisor lights ........................... 142
Sun visors .................................... 32
Symbols ......................................... 4
T
Tachometer ............................... 102
Tail lights ................................... 230
Third row seats ............................ 47

290
Three-point seat belt .................... 50
Tools .......................................... 241
Top-tether fastening eyes ............61
Tow bar....................................... 212
Towing ................................ 212, 257
Towing another vehicle .............258
Towing equipment .....................213
Towing the vehicle .....................257
Traction Control system ............. 170
Traction Control system off......... 111
Traffic sign assistant ...................198
Trailer coupling ........................... 212
Trailer stability assist .................216
Trailer towing ............................. 212
Transmission ............................... 16
Transmission display .................163
Tread depth ............................... 245
Trip computer ............................ 124
Trip odometer ............................ 101
Turn and lane-change signals ...139
Turn signal ................................. 107
Tyre chains ................................ 246
Tyre designations ......................242
Tyre pressure ............................ 242
Tyre pressure monitoring system ............................. 111, 243
Tyre pressures ........................... 279 Tyre repair kit ............................. 247U
Ultrasonic parking assist ...110, 189
Underseat storage .......................65
Upholstery .................................. 261
Upshift ........................................ 110
Using this manual ..........................3
V Vehicle battery ........................... 223
Vehicle checks............................ 218
Vehicle data ................................ 268
Vehicle data recording and privacy ..................................... 284
Vehicle detected ahead ..............113
Vehicle dimensions .................... 277
Vehicle Identification Number ....266
Vehicle jack ................................ 241
Vehicle messages .....................120
Vehicle personalisation .............127
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 217
Vehicle tools ............................... 241
Vehicle unlocking ........................... 6
Vehicle weight ........................... 276
Ventilation ................................... 144
W Warning chimes .........................123
Warning lights ............................. 101Warning triangle .......................... 89
Washer and wiper systems .........14
Washer fluid ............................... 222
Wheel changing .........................249
Wheel covers ............................. 246
Wheels and tyres .......................241
Windows ....................................... 30
Windscreen................................... 30
Windscreen wiper/washer ...........95
Winter tyres ............................... 241
Wiper blade replacement ..........225
