Driving and operating201
Once setting page is displayed, selectOff to deactivate pop-up function.
Reactivated by selecting On. When
switching on the ignition, pop-up function is deactivated.
Pop-up indication is displayed for approx. 8 seconds in the Driver
Information Centre.
Fault
The traffic sign assistant system may
not operate correctly when:
■ the area of the windscreen, where the front camera is located, is notclean
■ traffic signs are completely or partially covered or difficult to
discern
■ there are adverse environmental conditions, e.g. heavy rain, snow,direct sunlight or shadows. In this
case No Traffic Sign Detection due
to Weather is indicated on the
display
■ traffic signs are incorrectly mounted
or damaged
■ traffic signs do not comply with the Vienna Convention on traffic signs
(Wiener Übereinkommen über
Straßenverkehrszeichen)Caution
The system is intended to help the driver within a defined speed
range to discern certain traffic
signs. Do not ignore traffic signs
which are not displayed by the
system.
The system does not discern any other than the conventional traffic
signs that might give or end a
speed limit.
Do not let this special feature
tempt you into taking risks when
driving.
Always adapt speed to the road
conditions.
The driver assistance systems do not relieve the driver from full
responsibility for vehicle
operation.
Lane departure warning
The lane departure warning systemobserves the lane markings between
which the vehicle is driving via a front camera. The system detects lane
changes and warns the driver in the
event of an unintended lane change
via visual and acoustic signals.

244Vehicle care
Turn the adjuster wheel to select the
tyre pressure monitoring system.
System status and pressure warnings are displayed by a message with the
corresponding tyre flashing in the
DIC.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 111.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 282.
If w flashes for 60-90 seconds and
then illuminates continuously, there is
a fault in the system. Consult a
workshop.
After inflating, driving may be
required to update the tyre pressure
values in the DIC. During this time w
may illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for getting
low pressure. Check tyre pressure.
Vehicle messages 3 120.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A temporary spare wheel is not
equipped with pressure sensors. The
tyre pressure monitoring system is
not operational for these wheels.
Control indicator w illuminates. For
the further three wheels the system
remains operational.The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.
Each time the tyres are replaced, tyre pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor, replace
valve core and sealing ring. For
clipped sensor, replace complete
valve stem.
Vehicle loading status
Adjust tyre pressure to load condition according to the tyre information labelor tyre pressure chart 3 282, and
select the relevant setting in the menu
Tire Load in the DIC, Vehicle
Information Menu 3 114.

Vehicle care245
Select:■ Light for comfort pressure up to
3 people
■ Eco for Eco pressure up to
3 people
■ Max for full loading
TPMS Sensor Matching
Process
Each TPMS sensor has a unique
identification code. The identification
code must be matched to a new tyre/
wheel position after rotating the tyres
or exchanging the complete wheel set and if one or more TPMS sensors
were replaced. The TPMS sensor
matching process should also be
performed after replacing a spare tyre
with a road tyre containing the TPMS
sensor.
The malfunction light and the warning
message or code should go off at the
next ignition cycle. The sensors are
matched to the tyre/wheel positions,
using a TPMS relearn tool, in the
following order: left side front tyre,
right side front tyre, right side rear tyre and left side rear tyre. The turn signal
light at the current active position is
illuminated until sensor is matched.
Consult your workshop for service or
to purchase a relearn tool. There are
two minutes to match the first tyre/
wheel position, and five minutes
overall to match all four tyre/wheel
positions. If it takes longer, the
matching process stops and must be
restarted.The TPMS sensor matching process
is:
1. Apply the parking brake; on vehicles with automatic
transmission set the selector lever
to P.
2. Turn the ignition on.
3. Use the MENU button on the turn
signal lever to select the Vehicle
Information Menu in the Driver
Information Centre (DIC).
4. Turn the adjuster wheel to scroll to
the tyre pressure menu.
5. Press the SET/CLR button to
begin the sensor matching
process. A message requesting
acceptance of the process should
display.
6. Press the SET/CLR button again
to confirm the selection. The horn sounds twice to signal the
receiver is in relearn mode.
7. Start with the left side front tyre.
8. Place the relearn tool against the tyre sidewall, near the valve stem.Then press the button to activate
the TPMS sensor. A horn chirp

246Vehicle care
confirms that the sensoridentification code has been
matched to this tyre and wheel
position.
9. Proceed to the right side front tyre,
and repeat the procedure in
Step 8.
10. Proceed to the right side rear tyre,
and repeat the procedure in
Step 8.
11. Proceed to the left side rear tyre, and repeat the procedure in
Step 8. The horn sounds twice to
indicate the sensor identification
code has been matched to the left side rear tyre, and the TPMS
sensor matching process is no
longer active.
12. Turn off the ignition.
13. Set all four tyres to the recommended air pressure level
as indicated on the tyre pressure
label.
14. Ensure the tyre loading status is set according selected pressure
3 114.Temperature dependency
Tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase.
The tyre pressure value displayed in
the DIC shows the actual tyre
pressure. Therefore it is important to
check tyre pressure with cold tyres.
Tread depth Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).
For safety reasons, it is
recommended that the tread depth of
the tyres on one axle should not vary
by more than 2 mm.
The legally permissible minimum
tread depth (1.6 mm) has been
reached when the tread has worn
down as far as one of the tread wear
indicators (TWI). Their position is
indicated by markings on the
sidewall.
If there is more wear at the front than
the rear, swap round front wheels and rear wheels periodically. Ensure that
the direction of rotation of the wheels
remains the same.
Tyres age, even if they are not used.
We recommend tyre replacement
every 6 years.

Vehicle care263
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

264Service and maintenanceService and
maintenanceGeneral information ...................264
Recommended fluids, lubricants and parts .................................... 265General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 104.
European service intervals
Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Macedonia,
Malta, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
Serbia, Slovakia, Slovenia, Spain,
Sweden, Switzerland, United
Kingdom.
Service display 3 104.
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 104.

Service and maintenance265
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining engine oil life duration The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 104.Recommended fluids,
lubricants and parts
Recommended fluids and
lubricants Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 269.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.

292
GGauges ....................................... 101
General information ...................212
Glass panel .................................. 33
Glovebox ..................................... 62
Graphic-Info-Display, Colour- Info-Display ............................ 118
H Halogen headlights ....................226
Hand brake ......................... 167, 168
Hazard warning flashers ............139
Headlight flash ........................... 134
Headlight range adjustment ......134
Headlights................................... 132
Headlights when driving abroad 135
Head restraint adjustment .............8
Head restraints ............................ 35
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heated steering wheel .................94
Heating ........................................ 42
Heating and ventilation system . 144
High beam ......................... 112, 133
High beam assist ................113, 133
Hill start assist ........................... 170
Horn ....................................... 14, 94I
Identification plate .....................267
Ignition switch positions .............154
Immobiliser .......................... 27, 112
Indicators .................................... 101
Information displays.................... 114
Instrument cluster ......................101
Instrument panel fuse box .........238
Instrument panel illumination .....234
Instrument panel illumination control .................................... 141
Instrument panel overview ........... 10
Instrument panel storage ..............62
Interactive driving system ...........171
Interior care ............................... 262
Interior lighting ............................ 141
Interior lights ...................... 141, 234
Interior mirrors .............................. 29
Interruption of power supply ......165
Introduction .................................... 3
ISOFIX child restraint systems ....61
J Jump starting ............................. 257
K Keys ............................................. 19
Keys, locks ................................... 19L
Lane departure warning .....110, 201
Lashing eyes ............................... 85
Lighting features .........................142
Light switch ................................ 132
Load compartment ................24, 75
Load compartment cover .............78
Load compartment fuse box ......239
Loading information .....................91
Load rails and hooks ...................85
Low fuel ..................................... 112
Low washer fluid ........................113
M Malfunction indicator light ..........108
Manual anti-dazzle ......................29
Manual mode ............................. 164
Manual transmission .................. 166
Manual windows ..........................30
Memorised settings ......................21
Mirror adjustment ........................... 9
Misted light covers .....................140
N New vehicle running-in ..............154
Number plate light .....................233
O
Object detection systems ...........189
Odometer ................................... 101

293
Oil, engine.................. 219, 265, 269
Operate pedal ............................. 109
Outside temperature ....................97
Overhead console .......................64
Overrun cut-off ........................... 155
P Parking ................................ 18, 158
Parking assist ............................ 189
Parking brake ............................ 168
Parking lights ............................. 140
Particulate filter ........................... 159
Performance .............................. 276
Performing work ........................218
Pollen filter ................................. 152
Power outlets ............................... 99
Power seat adjustment ................40
Power steering............................ 110
Power steering fluid ....................221
Power windows ............................ 30
Preheating ................................. 111
Puncture ..................................... 250
Q
Quickheat ................................... 150
R Radio Frequency Identification (RFID) ..................................... 289
Radio remote control ...................20Reading lights ............................ 142
Rear carrier system ......................67
Rear floor storage cover ..............80
Rear fog light ............................. 113
Rear fog lights ........................... 140
Rear seats .................................... 43
Rear storage ................................. 78
Rear view camera ...................... 197
Rear window wiper/washer .......... 97 Recommended fluids and lubricants ........................ 265, 269
Reduced engine power ..............112
Refuelling ................................... 206
Retained power off .....................154
Reversing lights .........................140
Ride control system ....................170
Roller blinds ................................. 32
Roof .............................................. 33
Roof load ...................................... 91
Roof rack ..................................... 90
S Safety net .................................... 87
Seat adjustment ....................... 6, 37
Seat belt ........................................ 8
Seat belt reminder .....................107
Seat belts ..................................... 49
Seat position ................................ 37
Second row seats ........................43
Selective catalytic reduction .......160Selector lever ............................. 163
Service ............................... 152, 264
Service display .......................... 104
Service information ....................264
Service vehicle soon .................. 109
Side airbag system ......................54
Side blind spot alert ....................195
Sidelights .................................... 132
Side turn signal lights ................233
Spare wheel ............................... 253
Speed limiter............................... 175
Speedometer ............................. 101
Starting and operating ................154
Starting off ................................... 17
Starting the engine ....................154
Steering ...................................... 153
Steering wheel adjustment ......9, 93
Steering wheel controls ...............93
Stop-start system........................ 156
Storage ......................................... 62
Storage compartment ...................62
Storage compartments .................62
Sunvisor lights ........................... 142
Sun visors .................................... 32
Symbols ......................................... 4
T
Tachometer ............................... 102
Tail lights ................................... 230
Third row seats ............................ 47

294
Three-point seat belt .................... 50
Tools .......................................... 241
Top-tether fastening eyes ............61
Tow bar....................................... 212
Towing ................................ 212, 258
Towing another vehicle .............259
Towing equipment .....................213
Towing the vehicle .....................258
Traction Control system ............. 170
Traction Control system off......... 111
Traffic sign assistant ...................198
Trailer coupling ........................... 212
Trailer stability assist .................216
Trailer towing ............................. 213
Transmission ............................... 16
Transmission display .................163
Tread depth ............................... 246
Trip computer ............................ 124
Trip odometer ............................ 101
Turn and lane-change signals ...139
Turn signal ................................. 107
Tyre chains ................................ 247
Tyre designations ......................242
Tyre pressure ............................ 242
Tyre pressure monitoring system ............................. 111, 243
Tyre pressures ........................... 282 Tyre repair kit ............................. 248U
Ultrasonic parking assist ...110, 189
Underseat storage .......................65
Upholstery .................................. 262
Upshift ........................................ 110
Using this manual ..........................3
V Vehicle battery ........................... 223
Vehicle checks............................ 218
Vehicle data ................................ 269
Vehicle data recording and privacy ..................................... 288
Vehicle detected ahead ..............113
Vehicle dimensions .................... 279
Vehicle Identification Number ....267
Vehicle jack ................................ 241
Vehicle messages .....................120
Vehicle personalisation .............126
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 217
Vehicle tools ............................... 241
Vehicle unlocking ........................... 6
Vehicle weight ........................... 278
Ventilation ................................... 144
W Warning chimes .........................122
Warning lights ............................. 101Warning triangle .......................... 89
Washer and wiper systems .........14
Washer fluid ............................... 222
Wheel changing .........................250
Wheel covers ............................. 247
Wheels and tyres .......................241
Windows ....................................... 30
Windscreen................................... 30
Windscreen wiper/washer ...........95
Winter tyres ............................... 241
Wiper blade replacement ..........225
