mirror controls VAUXHALL ZAFIRA TOURER 2016 Owner's Manual

In brief111Power windows .....................31
2 Exterior mirrors .....................28
3 Cruise control .....................179
Speed limiter ....................... 180
Adaptive cruise control .......181
Forward collision alert .........188
4 Side air vents ...................... 156
5 Windscreen wiper,
windscreen washer
system, headlight washer
system, rear wiper, rear
washer system ......................98
6 Instruments ........................ 104
7 Steering wheel controls .......97
8 Driver Information Centre .... 116
9 Turn and lane-change
signals, headlight flash,
low beam and high beam,
high beam assist .................145
Exit lighting ......................... 149
Parking lights ...................... 146
Buttons for Driver
Information Centre ..............11610Central locking system ..........21
Hazard warning flashers ....145
Sport mode ........................ 177
Tour mode .......................... 177
Fuel selector ....................... 105
Control indicator for airbag
deactivation ........................ 111
Control indicator for front
passenger seat belt ...........110
11 Info-Display ........................ 120
12 Centre air vents .................. 156
13 Anti-theft alarm system
status LED ........................... 26
14 Glovebox .............................. 66
Fuse box ............................. 242
15 Climate control system ........ 150
16 AUX input, USB input, SD
card slot ................................ 10
Power outlet ........................ 102
17 Selector lever, manual
transmission ....................... 172
Automatic transmission ......16918Traction Control system .....175
Electronic Stability Control . 176
Lane departure warning .....207
19 Electric parking brake .........173
20 Parking assist systems .......194
Stop-start button .................161
21 Ignition switch with
steering wheel lock ............160
22 Horn ..................................... 98
Driver airbag ........................ 57
23 Bonnet release lever ..........224
24 Storage compartment ..........68
25 Steering wheel adjustment ..97
26 Light switch ........................ 138
Headlight range
adjustment ......................... 141
Front fog lights ...................146
Rear fog light ...................... 146
Instrument illumination .......147

134Instruments and controls● OnStar smartphone application
● OnStar remote services, e.g. location of the vehicle, activation
of horn and lights, control of
central locking system
● Stolen vehicle assistance
● Vehicle health check
● Destination download
Notice
All functions requiring data
connection to the vehicle are no
longer available if the vehicle ignition
has not been turned on for ten days.
OnStar buttonsNotice
Depending on the equipment, the
OnStar buttons can also be
integrated in the rear view mirror.
Privacy button
Press and hold j until an audio
message is heard to activate or
deactivate the transmission of the
vehicle location.
Press j to answer a call or to end a
call to an OnStar advisor.
Press j to access the Wi-Fi settings.
OnStar button
Press Z to establish a connection to
an OnStar advisor.
SOS button
Press [ to establish a priority
emergency connection to a specially trained emergency advisor.
Status light
Green: The system is ready.
Green flashing: The system is on a
call.
Red: A problem arose.
Off: System is off.Red / green flashing for a short period of time: Transmission of the vehicle
location has been deactivated.
OnStar services
OnStar emergency services
OnStar emergency provides a service with specially trained emergency
advisors for contact, assistance and
information during an emergency.
In the case of an emergency situation
including vehicle breakdown, a flat
tyre or empty fuel tank, press [ and
talk to the advisor. The advisor then
contacts emergency or assistance
service providers and directs them to
your vehicle.
In the case of an accident with
activation of airbags or belt
tensioners, an automatic emergency
call is established. The advisor is
immediately connected to your
vehicle to see whether help is
needed.
OnStar Wi-Fi hotspot
The Wi-Fi hotspot of the vehicle
provides internet connectivity through
the 4G/LTE mobile network.

299Child restraint systems ................60
Cigarette lighter .........................103
Climate control ............................. 15
Climate control systems .............150
Clock........................................... 101
Code ........................................... 122
Control indicators........................ 107
Control of the vehicle .................159
Controls ........................................ 97
Convex shape .............................. 28
Coolant and antifreeze ...............270
Cruise control ....................116, 179
Cupholders .................................. 67
Curtain airbag system .................. 58
Curve lighting.............................. 142
D Danger, Warnings and Cautions ...4
Daytime running lights ...............142
Declaration of conformity ............292
DEF ............................................ 165
Diesel exhaust fluid ....................165
Diesel fuel system bleeding .......230
Diesel particle filter .............114, 164
Door open .................................. 116
Door panel storage .......................68
Doors ............................................ 25
Driver assistance systems ..........179
Driver Information Centre ...........116Driving characteristics and
towing tips .............................. 218
Driving hints ................................ 159
E Electric adjustment ......................28
Electrical system......................... 239
Electric parking brake .........112, 173
Electric parking brake fault .........112
Electronic climate control system 152
Electronic driving programmes ..170
Electronic Stability Control.......... 176
Electronic Stability Control and Traction Control system ..........113
Electronic Stability Control off..... 113
End-of-life vehicle recovery .......223
Engine compartment fuse box ...240
Engine coolant ........................... 226
Engine coolant temperature gauge ..................................... 106
Engine data ............................... 277
Engine exhaust .......................... 164
Engine identification ...................273
Engine oil ................... 225, 270, 274
Engine oil pressure ....................114
Entry lighting .............................. 148
Event data recorders ..................296
Exit lighting ................................ 149
Exterior care .............................. 264
Exterior light ............................... 115Exterior lighting ....................12, 138
Exterior mirrors ............................. 28
F
Fault ........................................... 171
First aid kit ................................... 92
Fixed air vents ........................... 157
Flex-Fix system ............................ 70
Fog light ..................................... 116
Fog lights ................................... 234
Folding mirrors ............................. 29
Folding tray .................................. 92
Following distance indication ......192
Forward collision alert................. 188
Front airbag system .....................57
Front fog lights ........................... 146
Front seats.................................... 38
Front storage ................................ 68
Fuel............................................. 208
Fuel consumption - CO 2-
Emissions ............................... 216
Fuel for diesel engines ..............208
Fuel for liquid gas operation .......209
Fuel for natural gas operation ...209
Fuel for petrol engines ...............208
Fuel gauge ................................. 105
Fuel selector .............................. 105
Fuses ......................................... 239
