Instruments and controls95Instruments and
controlsControls ....................................... 96
Steering wheel adjustment ........96
Steering wheel controls .............96
Heated steering wheel ...............96
Horn ........................................... 97
Windscreen wiper and washer ..97
Rear window wiper and washer ...................................... 98
Outside temperature ..................99
Clock ......................................... 99
Power outlets ........................... 100
Cigarette lighter .......................101
Ashtrays .................................. 101
Warning lights, gauges and indi‐ cators ......................................... 102
Instrument cluster ....................102
Speedometer ........................... 102
Odometer ................................ 102
Trip odometer .......................... 102
Tachometer ............................. 103
Fuel gauge .............................. 103
Fuel selector ............................ 104
Engine coolant temperature gauge ..................................... 106Service display........................ 106
Control indicators ....................107
Turn lights ................................ 109
Seat belt reminder ...................110
Airbag and belt tensioners .......110
Airbag deactivation ..................111
Charging system .....................111
Malfunction indicator light ........111
Brake and clutch system .........111
Operate pedal .......................... 112
Electric parking brake ..............112
Electric parking brake fault ......112
Antilock brake system (ABS) ...112
Gear shifting ............................ 113
Power steering ........................ 113
Following distance ...................113
Lane departure warning ..........113
Electronic Stability Control off . 113
Electronic Stability Control and Traction Control system .........113
Traction Control system off .....113
Preheating ............................... 114
Exhaust filter ............................ 114
AdBlue ..................................... 114
Tyre pressure monitoring system .................................... 114
Engine oil pressure ..................114
Low fuel ................................... 115
Immobiliser .............................. 115
Exterior light ............................ 115High beam............................... 115
High beam assist .....................115
LED headlights ........................ 115
Fog light ................................... 115
Rear fog light ........................... 115
Cruise control .......................... 115
Adaptive cruise control ............116
Vehicle detected ahead ...........116
Speed limiter ........................... 116
Traffic sign assistant ................116
Door open ................................ 116
Displays ..................................... 116
Driver Information Centre ........116
Info Display .............................. 121
Vehicle messages ......................122
Warning chimes .......................122
Battery voltage ........................ 123
Vehicle personalisation ..............123
Telematics service .....................125
OnStar ..................................... 125

106Instruments and controlsSeek the assistance of a workshop in
the event of all other faults.Caution
Repairs and adjustments may only be made by trained specialists in
order to maintain the safety and
warranty on the LPG system.
Liquid gas is given a particular odour
(odorised) so that any leaks can be
detected easily.
9 Warning
If you smell gas in the vehicle or in
the immediate vicinity, switch to petrol mode immediately. No
smoking. No naked flames or
ignition sources.
If the gas odour persists, do not start
the engine. Have the cause of the
fault remedied by a workshop.
When using underground car parks,
follow the instructions of the operator
and local laws.
Notice
In the event of an accident, switch off
the ignition.
Fuel for liquid gas operation 3 246.
Engine coolant temperature gauge
Number of LEDs displayed shows the coolant temperature.
up to 3 LEDs:engine operating
temperature not
yet reached4 to 6 LEDs:normal operating
temperaturemore than 6
LEDs:temperature too
highCaution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
The engine oil life system informs
when to change the engine oil and
filter. Based on driving conditions, the interval at which an engine oil and
filter change will be indicated can vary
considerably.
When the system has calculated that
engine oil life has been diminished,
Change Engine Oil Soon appears in
the Driver Information Centre. Have engine oil and filter changed by a
workshop within one week or
300 miles, whichever occurs first.

Instruments and controls109OverviewOTurn signal 3 109XSeat belt reminder 3 110vAirbag and belt tensioners
3 110VAirbag deactivation 3 111pCharging system 3 111ZMalfunction indicator light
3 111RBrake and clutch system 3 111mElectric parking brake 3 112jElectric parking brake fault
3 112-Operate pedal 3 112uAntilock brake system (ABS)
3 112RGear shifting 3 113EFollowing distance 3 113cPower steering 3 113)Lane departure warning 3 113nElectronic Stability Control off
3 113bElectronic Stability Control and
Traction Control system 3 113kTraction Control system off
3 113!Preheating 3 114%Exhaust filter 3 114YAdBlue 3 114wTyre pressure monitoring
system 3 114IEngine oil pressure 3 114YLow fuel 3 115dImmobiliser 3 1158Exterior light 3 115CHigh beam 3 115fHigh beam assist 3 115fLED headlights 3 133>Fog light 3 115rRear fog light 3 115mCruise control 3 115 / Adaptive
cruise control 3 116CAdaptive cruise control 3 116AVehicle detected ahead 3 116LSpeed limiter 3 116LTraffic sign assistant 3 116hDoor open 3 116
Turn lights
O illuminates or flashes green.
Illuminates briefly The parking lights are switched on.
Flashes
A turn signal or the hazard warning
flashers are activated.
Rapid flashing: failure of a turn signal
light or associated fuse, failure of turn signal light on trailer.
Bulb replacement 3 266, Fuses
3 273.
Turn signals 3 134.

Driving and operating203Caution
After running at high enginespeeds or with high engine loads,
operate the engine briefly at a low load or run in neutral for
approx. 30 seconds before
switching off, in order to protect
the turbocharger.
Notice
In the event of an accident with
airbag deployment, the engine is
turned off automatically if the vehicle
comes to a standstill within a certain time.
Engine exhaust9 Danger
Engine exhaust gases contain
poisonous carbon monoxide,
which is colourless and odourless and could be fatal if inhaled.
If exhaust gases enter the interior
of the vehicle, open the windows.
Have the cause of the fault
rectified by a workshop.
Avoid driving with an open load
compartment, otherwise exhaust
gases could enter the vehicle.
Exhaust filter
The exhaust filter is a particle filter for diesel and gasoline engines.
Automatic cleaning process
The exhaust filter system filters
harmful soot particles out of the
exhaust gases. The system includes
a self-cleaning function that runs
automatically during driving without
any notification. The filter is cleaned
by periodically burning off the soot
particles at high temperature. This
process takes place automatically
under set driving conditions and may
take up to 25 minutes. Typically it
needs between seven and twelve
minutes. Autostop is not available
and fuel consumption may be higher
during this period. The emission of
smells and smoke during this process is normal.
System requires cleaning
Under certain conditions, e.g. driving
short distances, the system cannot
clean itself automatically.
If cleaning of the filter is required and if previous driving conditions did not
enable automatic cleaning, it will be
indicated by illumination of % and a
warning message in the Driver Information Centre.

204Driving and operating% illuminates along with a warning
message when exhaust filter is full.
Start cleaning process as soon as possible.
% flashes along with a warning
message when exhaust filter has
reached the maximum filling level.
Start cleaning process immediately to avoid damage to the engine.
Activate self-cleaning process
To activate cleaning process,
continue driving, keep engine speed
above 2000 rpm. Shift down if
necessary. Exhaust filter cleaning is
then started.
Cleaning process is completed more quickly at high engine speeds and
loads.
Control indicator % extinguishes as
soon as the self-cleaning operation is
complete. Keep on driving until self-
cleaning operation is complete.Caution
If possible, do not interrupt
cleaning process. Drive until
cleaning is completed to avoid the need for service or repair by a
workshop.
Cleaning process not possible
If cleaning is not possible for anyreason, control indicator Z
illuminates and a warning message
appears in the Driver Information
Centre. Engine power may be
reduced. Seek the assistance of a
workshop immediately.
Catalytic converter
The catalytic converter reduces the
amount of harmful substances in the
exhaust gases.
Caution
Fuel grades other than those listed on pages 3 244, 3 310 could
damage the catalytic converter or
electronic components.
Unburnt petrol will overheat and
damage the catalytic converter.
Therefore avoid excessive use of the starter, running the fuel tank
dry and starting the engine by
pushing or towing.
In the event of misfiring, uneven
engine running, a reduction in engine performance or other unusual
problems, have the cause of the fault
rectified by a workshop as soon as
possible. In an emergency, driving
can be continued for a short period,
keeping vehicle speed and engine
speed low.

332Entry lighting .............................. 137
Event data recorders ..................326
Exhaust filter ....................... 114, 203
Exit lighting ................................ 137
Exterior care .............................. 299
Exterior light ............................... 115
Exterior lighting ....................12, 129
Exterior mirrors ............................. 28
F Fault ........................................... 210
Favourite lists ............................. 154
Retrieving stations................... 154
Storing stations .......................154
Favourites ................................... 170
File formats Audio files................................ 158
Movie files ............................... 158
Picture files.............................. 158
First aid kit ................................... 91
Fixed air vents ........................... 195
Flex-Fix system ............................ 69
Fog light ..................................... 115
Fog lights ................................... 268
Folding mirrors ............................. 28
Folding tray .................................. 91
Following distance ......................113
Following distance indication ......231
Forward collision alert................. 228
Front airbag system .....................56Front fog lights ........................... 134
Front seats.................................... 37
Front storage ................................ 67
Fuel............................................. 244
Fuel for diesel engines ..............245
Fuel for liquid gas operation .......246
Fuel for natural gas operation ...246
Fuel for petrol engines ...............244
Fuel gauge ................................. 103
Fuel selector .............................. 104
Funnel......................................... 247
Fuses ......................................... 273
G Gauges ....................................... 102
Gear shifting ............................... 113
General information ...158, 164,
178, 179, 252
Bluetooth ................................. 158
DAB ......................................... 156
Infotainment system ................139
Navigation ............................... 164
Phone ...................................... 179
Smartphone applications ........158
USB ......................................... 158
Glass panel .................................. 33
Glovebox ..................................... 65
Guidance ................................... 175H
Halogen headlights ....................266
Hand brake ................................. 212
Hazard warning flashers ............134
Headlight flash ........................... 131
Headlight range adjustment ......131
Headlights................................... 129
Headlights when driving abroad 132
Head restraint adjustment .............8
Head restraints ............................ 35
Heated mirrors ............................. 29
Heated rear window ..................... 33
Heated steering wheel .................96
Heating ........................................ 42
Heating and ventilation system . 188
High beam ......................... 115, 130
High beam assist ................115, 130
Hill start assist ........................... 214
Home menu ................................ 146
Horn ....................................... 13, 97
I
Identification plate .....................305
Ignition switch positions .............197
Immobiliser .......................... 28, 115
Indicators .................................... 102
Info Display ................................. 121
Information displays.................... 116
Infotainment control panel ..........141
Instrument cluster ......................102

333Instrument panel fuse box .........277
Instrument panel illumination .....273
Instrument panel illumination control .................................... 136
Instrument panel overview ........... 10
Intellitext ..................................... 156
Interactive driving system ...........217
Interior care ............................... 301
Interior lighting ............................ 136
Interior lights ...................... 136, 273
Interior mirrors .............................. 29
Interruption of power supply ......210
Introduction .................................... 3
J
Jump starting ............................. 295
K Keys ............................................. 19
Keys, locks ................................... 19
L Lane departure warning .....113, 243
Lashing eyes ............................... 87
LED headlights ...........115, 133, 268
Lighting features .........................137
Light switch ................................ 129
Load compartment ................24, 78
Load compartment cover .............80
Load compartment fuse box ......278
Loading information .....................93Load rails and hooks ...................87
Low fuel ..................................... 115
LPG ............................ 104, 246, 307
M
Malfunction indicator light ..........111
Manual anti-dazzle ......................29
Manual mode ............................. 209
Manual seat adjustment ...............38
Manual transmission .................. 211
Manual windows ..........................30
Maps ........................................... 166
Maximum startup volume ...........149
Memorised settings ......................21
Menu operation .......................... 146
Mirror adjustment ........................... 8
Misted light covers .....................135
Mobile phones and CB radio equipment .............................. 187
Movie files................................... 158
Mute............................................ 144
N
Navigation Contacts .................................. 170
Current location .......................166
Destination input .....................170
Favourites ............................... 170
Map display ............................. 166
Map manipulation ....................166
Map update ............................. 164Recent destinations ................170
Route guidance .......................175
TMC stations ...................164, 175
Traffic incidents .......................175
Turn list ................................... 175
New vehicle running-in ..............197
Number plate light .....................272
O
Object detection systems ...........233
Odometer ................................... 102
Oil, engine .................. 260, 303, 307
OnStar ........................................ 125
Operate pedal ............................. 112
Operation .................................... 183
External devices ......................158
Menu ....................................... 146
Navigation system ...................166
Phone ...................................... 183
Radio ....................................... 152
Outside temperature ....................99
Overhead console .......................67
Overrun cut-off ........................... 199
P Pairing ........................................ 180
Parking ................................ 18, 202
Parking assist ............................ 233
Parking brake ............................ 212
Parking lights ............................. 135
Particulate filter ........................... 203
