VOLKSWAGEN BEETLE 2013 3.G Service Manual

Doors

Rear hatch

x If the vehicle must be pushed, do not push against the rear spoiler. The rear spoiler and the
rear hatch could be damaged.
Warning light

Fig. 26 Opening rear hatch from the outside.

Closing the rear hatch

Fig. 27 Opened rear hatch: Recessed grips for closing.

Power windows

Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch.
Stopping automatic
movement:
Press/pull the respective switch again.

You can still use the power windows for several minutes after the ignition is switched off as long as the
driver or passenger door has not been opened. When the vehicle key has been removed from the
ignition and the driver door has been opened, the power windows cannot be opened or closed.
Power windows – features

Convenience closing
The convenience closing feature lets you close the windows and the power sunroof from outside the
vehicle as follows:
x Manual locking: lock the vehicle with the vehicle key bit in the driver door and keep the key turned
in the locking position to close all windows and the power sunroof..
x Vehicles with Keyless Access: hold your finger on the lock sensor surface on the outside of the
door handle for a few seconds until the windows and power sunroof close.
Convenience closing first closes the windows and then the power sunroof.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-
dows for several minutes after the ignition is switched off as long as the driver or passenger
door has not been opened.
NOTICE
The windows must go down slightly when you unlock the vehicle. Otherwise the windows and
seals could be damaged when opening the doors.
If the power windows malfunction, the one-touch feature, as well as pinch protection may not
work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right
away.
If convenience closing of the power windows from the outside requires removing the cover cap of
the lock cylinder on the driver door, the cover cap must be reinstalled after the vehicle is locked..

Power sunroof

Opening and closing the power sunroof

Fig. 29 In the headliner: Rotary switch for the power sunroof. A: Turn the rotary switch to slide the sunroof
open or closed. B: Press or pull the switch to tilt open or to close.
