Convertible top
Introduction
The convertible top opens automatically at the press of a button. When open, the convertible top is stored in a compartment.
The multi-layer construction of the convertible top helps to insulate the vehicle interior from tempera-ture and vibration and is also wind- and waterproof under normal operating conditions. Some water could enter between the convertible top and body under extreme conditions such as torrential rain or washing the vehicle in a car wash. This is normal and no cause for concern.
Supplementary information and warnings:
x Vehicle overview
x Volkswagen Information System
x Technical data
x Power locking and closing system
x Airbag system
x Climate control system
x Exterior care and cleaning
x Emergency closing and opening
x Jump-starting
x Towing
WARNING
Accidents and serious injury may result while driving when the convertible top is not secure-ly latched or when the opening or closing process is incomplete. Even at low speeds, air resistance can twist or deform the convertible top or tear it off completely, endangering vehi-cle occupants and others.
x Even though it is possible, it is not recommended to drive when the convertible top is not completely open or not completely closed and securely latched.
x If you must move the vehicle to another location for safety reasons and the top is not completely open or not completely closed and securely latched, we recommend that you do not drive any faster than a slow walk.
x When opening and closing the convertible top, always make sure no one will be injured by the supports and other moving parts.
NOTICE
x To help prevent damage, remove ice and snow from the convertible top before opening it in winter weather.
NOTICE
Objects with sharp edges or that cause scratches or dirty components can damage the con-vertible top or the rear window.
x Never remove snow and ice with sharp objects or objects that can cause scratches.

x Only open and close the convertible top when it is clean.
NOTICE
If the convertible top is opened frequently when it is damp or it is left open for several weeks at a time, it may develop creases and pressure marks and could be damaged.
x Do not leave the convertible top open for long periods of time.
x Only open the convertible top when it is completely dry.
When parking the vehicle with the convertible top open, the vehicle interior is not protected against unauthorized access.
x Always close the convertible top and lock the doors and luggage compartment before leaving the vehicle.
x Always store objects left in the vehicle in the locked luggage compartment.
The convertible top will only open or close when the luggage compartment lid is completely closed. Do not open the luggage compartment lid when the convertible top is opening or closing.
Indicator light

Lights up Possible cause Proper response
Convertible top is opening or closing. Wait until the convertible top has fully opened or fully closed.


Flashes Possible cause Proper response
The convertible top opening or closing process is not finished or there is a con-vertible top malfunction.
Check if the opening or closing process has finished. If necessary, end the process using the convertible top button
Check if all technical requirements are met. If not, take the necessary steps to meet the technical requirements
Check if there is a convertible top malfunc-tion. If necessary, correct the malfunction or have the system checked by your authorized Volkswagen dealer or authorized Volkswagen Service Facility

Messages in the instrument cluster display
When the ignition is switched on, the indicator lights come on briefly for a function check. They go out after a few seconds.

Display text Proper response
Speed too high!
Reduce your speed. You can only operate the convertible top at speeds up to about 30 mph (50 km/h). If the convertible top has already begun opening or closing, it will stop if you drive faster. You can only continue opening or closing the convertible top once the vehicle speed drops below about 30 mph (50 km/h).
Decrease speed! Reduce your speed. At 28 mph (45 km/h), the system warns the driver not to exceed the maximum speed for opening or closing. If the opening or closing process has already started, it will not stop.
Convert. top: Release cover! Convertible top cover (boot) is still installed. Roof operation is not possi-ble. Remove the convertible top cover.
Error: Convertible top Service!
See an authorized Volkswagen dealer or authorized Volkswagen Service Facility. You cannot operate the convertible top if a system component malfunctions. Use the emergency procedure to close the open converti-ble top if necessary.
Error: Open convertible top!
Open the convertible top.
Error: Close convertible top!
Have the system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. There is a malfunction in a control module. It is not possible to open or close the convertible top. Use the emergency procedure to close the convertible top.
Low voltage: Please start en-gine!
The vehicle battery is drained to the point that it cannot provide the power needed to completely open or close the convertible top. Start the engine by jump-starting if necessary. Open or close the convertible top while the engine is running. Volkswagen recommends taking a longer drive afterward to help recharge the vehicle battery.
Convertible top open This message and a chime confirm that the convertible top is completely open or closed.
Convertible top closed
Convertible top not functional. Owner's manual!
Outside temperature too low. You can still close the convertible top, if necessary.
Have the system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. There is a malfunction in a control module. It is not possible to open or close the convertible top. Use the emergency procedure to close an open convertible top if neces-sary
Continue convertible top operation
The opening or closing process was interrupted. Press the button
⇒ fig. 35 again until the opening or closing process has finished.

Display text Proper response
Convertible top operation
This text message indicates the convertible top is currently opening or
closing. Press and hold the button ⇒ fig. 35 again until the opening or closing process has finished.

The instrument cluster displays and their arrangement may vary depending on the vehicle model and engine. For displays without warning and information messages, malfunctions are only signaled with indicator lights.
General information
Checklist
Perform the following preliminary requirements each time before opening or closing the con-vertible top:
1. Park the vehicle a safe distance from moving traffic.
2. Park the vehicle so that it is as level as possible. The vehicle must not be on a hoist, it must not have one side parked on a curb, and it must not be raised on a vehicle jack.
3. Remove all objects from the convertible top.
4. Remove all objects from the area of the convertible top compartment.
5. Remove ice and snow from the convertible top before opening.
6. Do not operate the convertible top in temperatures below 15 °F (-10 °C).
7. Allow the convertible top to dry completely before opening.
Checklist
The following technical requirements must be met to open or close the convertible top:
d The ignition must be switched on ⇒  Starting and stopping the engine.
d The vehicle speed must be no more than 30 mph (50 km/h).
d The outside temperature must be above +15 °F (-10 °C).
d The battery must have enough charge.
If any changes have been made in the operation of the convertible top compared with its original factory condition, Volkswagen strongly urges you to take the vehicle to an authorized Volkswagen dealer or other authorized Volkswagen Service Facility to have the top restored to its original condi-tion. Mechanical changes and changes to the vehicle software must be entered in the
⇒ Booklet Warranty and Maintenance.
WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.

On vehicles with Climatronic, you can set different heating and air conditioning temperatures for
operation with the convertible top up and down ⇒  Climatronic controls
Opening or closing the convertible top

Fig. 35 In the roof console: convertible top button.
You can open or close the convertible top at speeds up to 30 mph (50 km/h). If the convertible top has already begun opening or closing, it will stop if you exceed that speed. You can only continue opening or closing the convertible top once the vehicle speed drops below about 30 mph (50 km/h).
For safety reasons, Volkswagen recommends opening or closing the convertible top only when the
vehicle is stationary and parked at a safe distance from moving traffic ⇒ .
Opening the convertible top
x Please note and follow the steps described in the checklists ⇒ page 74, General information.
x Switch on the ignition, if necessary ⇒  Starting and stopping the engine.
x Press and hold the button ⇒ fig. 35 in the roof console until all windows go down and the con-
vertible top is completely open ⇒ . A chime sounds and the indicator light in the instrument cluster goes out when the process is complete. A message may also appear in the instrument cluster display.
x Secure the convertible top cover (boot), if necessary ⇒  Installing and removing the convertible top cover (boot).
Closing the convertible top
x Please note and follow the steps described in the checklists ⇒  General information.
x Switch on the ignition, if necessary ⇒  Starting and stopping the engine.
x Remove the convertible top cover (boot), if necessary ⇒Installing and removing the convertible top cover (boot).
x Pull and hold the button ⇒ fig. 35 until the convertible top and all windows close completely
⇒ : a chime sounds and the indicator light in the instrument cluster goes out. A message may also appear in the instrument cluster display.
Interrupting convertible top operation
Releasing the button interrupts convertible top operation ⇒ .

WARNING
Uncontrolled or unintentional opening and closing of the convertible top can cause accidents and serious injuries.
x Never open or close the convertible top unless the vehicle is parked and at a safe distance from traffic.
x Do not open or close the convertible top unless you have made sure that nobody is in the way of the luggage compartment lid, the convertible top supports, and other moving parts.
x Make sure the closed convertible top is latched securely.
x If convertible top operation is interrupted:
– The convertible top may not stop moving immediately. Gravity may cause the converti-ble top to continue moving.
– If you cannot close the convertible top “normally,” use the emergency closing proce-dure to latch it, if necessary.
– Note the messages in the instrument cluster that indicate if the convertible top has closed and latched correctly.
NOTICE
Frequent opening and closing of the convertible top drains the vehicle battery. To help prevent the battery from draining, leave the engine running if opening and closing the roof frequently.
NOTICE
Always close the convertible top before leaving the vehicle and when it may rain or snow. If the convertible top is open, rain or snow can damage the vehicle interior and can cause extensive damage to the electrical system.
NOTICE
The height of the vehicle changes when the convertible top is opening or closing. When there is not enough room above the vehicle, for example in a garage, the convertible could hit some-thing and be damaged.
x Only open or close the convertible top when there is enough room above the vehicle to do so.
If you park the vehicle with the convertible top open, the passenger compartment can be dam-aged by rain or snow, and it is also open to unauthorized persons.
x Always close the convertible top before you leave the vehicle.
x If you must leave things in the vehicle when the top is down, you should lock them in the luggage compartment.

Opening or closing the convertible top with the remote control vehicle
key

Fig. 36 Buttons in the remote control vehicle key.
In some vehicles equipped with the Keyless Access locking and starting system ⇒  Power locking system, the convertible can be opened or closed from outside the vehicle when the ignition is off using a valid remote control vehicle key. For this to work, the vehicle key must be within range of the Key-
less Access locking and starting system ⇒  Unlocking or locking the vehicle with Keyless Access. Volkswagen recommends having the vehicle key less than 1 meter from the door handle on the driver or passenger door.
Before opening or closing the convertible top with the vehicle key, note the following:
x The vehicle doors must be closed.
x Make sure there is enough room above the vehicle for the convertible top to open ⇒ .
Opening or closing the convertible top using the vehicle key
x Follow the checklists and perform the steps on ⇒  General information.
x Hold the remote control vehicle key outside the vehicle near the door handle on the driver or pas-senger door.
x To open: Briefly press the

WARNING
Uncontrolled or unintentional opening and closing of the convertible top can cause accidents and serious injuries.
x Never open or close the convertible top unless the vehicle is parked and at a safe distance from traffic.
x Do not open or close the convertible top unless you have made sure that nobody is in the way of the luggage compartment lid, the convertible top supports, and other moving parts.
x Make sure the closed convertible top is latched securely.
x If convertible top operation is interrupted:
– The convertible top may not stop moving immediately. Gravity may cause the converti-ble top to continue moving.
– If you cannot close the convertible top “normally,” use the emergency closing proce-dure to latch it, if necessary.
– Note the messages in the instrument cluster that indicate if the convertible top has closed and latched correctly.
WARNING
If interruption of the opening or closing process causes the convertible top to come to rest in its forward position, the roof will not be latched.
x If you are unable to get the convertible top to close “normally,” latch the roof using the
emergency closing procedure ⇒  Emergency closing and opening.
x Watch for a message in the instrument cluster display indicating whether the convertible top has been properly closed.
NOTICE
x Strong radio signals or interference can interfere with convertible top operation. Operation will then stop.
NOTICE
Frequent opening and closing of the convertible top drains the vehicle battery. To help prevent the battery from draining, leave the engine running if opening and closing the roof frequently.
NOTICE
Always close the convertible top before leaving the vehicle and when it may rain or snow. If the convertible top is open, rain or snow can damage the vehicle interior and can cause extensive damage to the electrical system.
NOTICE
The height of the vehicle changes when the convertible top is opening or closing. When there is not enough room above the vehicle, for example in a garage, the convertible could hit some-thing and be damaged.

x Only open or close the convertible top when there is enough room above the vehicle to do so.
If you park the vehicle with the convertible top open, the passenger compartment can be dam-aged by rain or snow, and it is also open to unauthorized persons.
x Always close the convertible top before you leave the vehicle.
x If you must leave things in the vehicle when the top is down, you should lock them in the luggage compartment.
Removing the wind blocker from the luggage compartment and storing

Fig. 37 A: Opening the storage compartment for the wind blocker. B: Removing the wind blocker from the storage compartment.
Your vehicle may be equipped with a wind blocker that can be used when the convertible top is down.
Removing the wind blocker from the luggage compartment
x Turn the quick-release fasteners ⇒ fig. 37 A (arrows) counterclockwise and gently guide the stor-age compartment (1) down.
x Raise the back of the wind blocker ⇒ fig. 37 B (2) and remove it from the storage compartment in the direction indicated by the arrow.
x Fold the storage compartment upward and turn the quick-release fasteners ⇒ fig. 37 A (arrows) clockwise to close.
Storing the wind blocker
x Turn the quick-release fasteners ⇒ fig. 37 A (arrows) counterclockwise and gently guide the stor-age compartment (1) down.
x Slide the wind blocker ⇒ fig. 37 B (2) opposite the direction of the arrow into the storage compart-ment (1).
x Fold the storage compartment upward and turn the quick-release fasteners ⇒ fig. 37 A (arrows) clockwise to close.
Removing and installing the storage compartment when it is not needed
To increase the size of the luggage compartment, you can remove a storage compartment if it is not needed.

To remove the storage compartment ⇒ fig. 37 B (1), pull it out of the brackets in the direction of the arrow.
To install the storage compartment ⇒ fig. 37 B (1), slide it into the brackets opposite the direction of the arrow.
WARNING
Installing or removing the wind blocker by the side of the road near moving traffic can cause accidents and serious personal injuries.
x Always park the vehicle a safe distance from moving traffic when installing or removing the wind blocker.
x Never install or remove the wind blocker while driving.
WARNING
Incorrect seating positions in the vehicle increase the risk of serious of fatal injuries in the event of an accident or sudden driving and braking maneuvers.
x Never let anyone sit on the rear seats when the wind blocker is installed.
WARNING
Unsecured or improperly secured objects can cause severe injuries during sudden braking maneuvers or if the vehicle is involved in an accident while driving.
x Never place unsecured objects underneath the wind blocker.
x Never use the wind blocker as a storage shelf. Items on the wind blocker can be thrown around inside the vehicle by the wind and cause injuries.
x Never use the wind blocker to secure objects.
WARNING
Always make sure that hands, fingers, and other parts of the body are out of the way when moving the wind blocker up or down, or when folding it together.
x Never fold the wind blocker upward while driving.
NOTICE
x Always store the wind blocker in its storage compartment when not in use.
x Do not store any other objects in the wind blocker storage compartment.
