VOLKSWAGEN CC 2008 Owners Manual

Fig. 157 In the center console: Button to switch the Park Distance
Control system on or off.

In order to Operation
view camera dis-
play (if equipped): OR: Tap the function key Z or 26# on the dis-
play.

The indicator light in the button  ⇒ fig. 157 comes on and stays on
as long as the feature is active.
A chime sounds to tell you that the system is on. If the chime does
not sound, PDC is not working. Have the system inspected by an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
In some cases, the Park Distance Control interprets water and ice
on the sensors as an obstacle.
If the distance remains the same, the warning tone volume de-
creases after a few seconds. If a continuous tone sounds, its volume
remains the same.
If the vehicle moves away from the obstacle, the beeping sound
stops automatically. The beep turns on again automatically if the ve-
hicle approaches the obstacle again.
For vehicles with automatic transmissions, there is no beeping
when the transmission is in Park (P) and the electronic parking brake
is engaged.
The volume of the audible signals can be adjusted by an author-
ized Volkswagen dealer or an authorized Volkswagen Service Facili-
ty.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function
key on the Radio or Navigation system screen (if applicable). Tap the
function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off re-
activates the volume. System malfunction warning signals cannot be
switched off.
If you manually deactivate the display, PDC remains on and the
sound is reactivated.

WARNING
Never rely completely on the PDC for information about people
and objects that might be in the way of the vehicle and could be
struck by the vehicle causing serious personal injury.
The PDC sensors have blind spots where they cannot detect
people or objects.
Always watch for people, especially small children and ani-
mals, because the sensors may not always be able to detect
them.
If you hear a long beep lasting about 3 seconds when you first
turn PDC on or the indicator light in the button starts blinking, this
means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have
it immediately checked by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other acci-
dents that cause serious personal injuries.
Always make sure all windows are clear of ice, snow and
condensation for good visibility to the front, sides, and rear.
Maximum heating output and defrosting performance are not
possible until the engine has reached operating temperature.
Wait until you have good visibility before driving off.
Always make sure you know how to properly use the climate
control system as well as the rear window defroster that you
will need for good visibility.
Never use air recirculation for long periods of time. When the
air conditioner is off and recirculation mode is on, condensa-
tion can quickly form on the windows and greatly reduce visi-
bility.
Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness,
which can cause accidents, collisions and serious personal in-
jury.
Never switch off the fan for a long period of time and never
use air recirculation for a long period of time because no fresh
air will enter the passenger compartment.
NOTICE
If you think the air conditioner is not working properly or may
be damaged, switch it off to help prevent more damage. Have the
air conditioner checked by an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility.
Air conditioner repair requires specialized knowledge and
special tools. Volkswagen recommends that you see an author-
ized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Do not smoke when air recirculation is switched on. Smoke
drawn into the ventilation system can leave residue on the evap-

orator and on the dust and pollen active carbon filter, resulting
in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not
be dehumidified. To help keep the windows from fogging over,
Volkswagen recommends leaving the air conditioner (compressor)
switched on. Press the !

Button/Knob More information: Climatronic ⇒ fig. 158.
A, [ Buttons for seat heating
!

Operation

Air conditioner does not work
The air conditioner may not switch on for one of the following rea-
sons:
The engine is not running.
The fan is switched off.
The air conditioner fuse has blown.
The outside air temperature is colder than about +38 °F (+3 °C).
The air conditioner compressor has been temporarily switched off
due to excessive engine coolant temperature.
There is another malfunction in the vehicle. Have the air condition-
er checked by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility.
Special considerations
When it is very hot and humid outside, water condensation can drip
from the air conditioner evaporator and form a puddle under the vehi-
cle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment
temperature as fast as possible considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield
may fog up after the engine is started. Switch on the windshield de-
froster to help evaporate the condensation as quickly as possible.
The air coming out of the vents flows through the passenger
compartment and through the vents under the rear window. Do not
cover these slots with clothing or other things.
