Starting off with a trailer on hills
Depending on how steep the hill is and the combined towing weight, a
parked vehicle with trailer can roll backwards when you first start
moving.
When starting off with a trailer on a hill:
Depress and hold the brake pedal (and depress and hold the clutch
- manual transmission).
Press the G button once to deactivate the electronic parking brake
⇒  Braking and parking.
Press the G button again and hold it to use the electronic parking
brake to help prevent the vehicle and trailer from rolling backwards. If
applicable, follow the instructions for the Hill Hold feature ⇒ Starting
assistance systems.
Shift into first gear or Drive D ⇒  Shifting.
Release the brake pedal.
Drive ahead slowly at first. If your vehicle has manual transmission,
slowly let out the clutch.
Do not release the G button until the engine starts to move the
vehicle forward. If your vehicle has an automatic transmission, you
can also depress and hold the brake pedal for added braking and
then let up on the brake pedal when you feel that the vehicle “wants”
to move forward.
Drive ahead slowly.

The engine switches off automatically.
Engine restart feature
If no authorized remote control vehicle key is identified in the passen-
ger compartment after the engine has been switched off, the engine
can be restarted within about 5 seconds. A related message is shown
in the instrument cluster display.
After the 5 seconds have passed, the engine can no longer be started
without an authorized vehicle key in the passenger compartment.
WARNING
Unintended vehicle movement can cause serious personal inju-
ry.
Do not depress the brake or clutch pedals when switching on
the ignition, as the engine could otherwise start immediately.
WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle.
Children or unauthorized persons may use it to lock the vehi-
cle, start the engine, and operate vehicle systems such as the
power windows, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
using the remote control vehicle key. This could result in peo-
ple being trapped in the vehicle in an emergency. For example,
depending on the time of year, people trapped in the vehicle
can be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Whenever stalled or stopped for repair, move the vehicle a
safe distance off the road, turn on the emergency flashers, stop
the engine, and use other warning devices to warn approaching
traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Pedals

Fig. 136 Pedals in vehicles with manual transmission: 1 Accelerator
pedal, 2 Brake pedal, 3 Clutch pedal.

Shifting into reverse
Only shift to the reverse gear when the vehicle is not moving.
Depress the clutch pedal fully and hold ⇒ .
Move the gearshift lever to neutral and press down.
Move the shift lever to the left and then push forward into the re-
verse gear position ⇒ fig. 138 (R) or ⇒ fig. 139 (R).
Release the clutch pedal to engage the gear.
Downshifting
You should always downshift gear by gear when driving, meaning
always into the next lowest gear. Do not downshift when the engine
rpm (revolutions per minute) is too high ⇒ . At fast speeds or high
engine rpm, skipping over one or more gears when downshifting can
cause damage to the clutch and transmission, even if a gear is not
engaged ⇒ .
WARNING
Downshifting to a lower gear incorrectly can result in loss of
vehicle control and can cause accidents and serious personal
injuries.
WARNING
When the engine is running and a gear is engaged, the vehicle
will start to move as soon as the clutch pedal is released, even
when the parking brake is applied. This also applies when the
parking brake is engaged.
Never shift into reverse when the vehicle is moving.
NOTICE
Shifting down to a gear that is too low when driving at fast
speeds or high engine rpm can cause extensive damage to the
clutch and transmission. That is true even if the clutch pedal is
pressed so that the clutch is not engaged.

NOTICE
To help prevent damage and premature wear:
Do not rest your hand on the gearshift lever while driving.
Over time, the pressure will cause premature wear in the trans-
mission.
Make sure that the vehicle has come to a complete stop before
shifting into reverse.
Always depress the clutch pedal all the way when changing
gears.
Do not hold the vehicle on a hill using engine power with the
clutch pedal partially engaged and the engine running.
Automatic transmission: Selector lever

Fig. 140 Side view: Automatic transmission selector lever with shift
lever release button (arrow).

Flashes Possible cause Proper response
D
Steering system stiff. Turn the steering wheel back
and forth.
Steering column not
locked/unlocked.
Switch the ignition off and
then switch it on again. Heed
any messages shown in the
instrument cluster display, if
applicable.
On vehicles with Keyless Ac-
cess ,press the starter button
briefly twice in a row without
depressing the brake or
clutch pedal.
Do not drive any farther if
the steering column remains
locked after you switch on the
ignition. Contact your author-
ized Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

clutch pedal all the way down before you start driving so the system
recognizes that the parking brake should be released.
Emergency braking function
Only use the emergency braking function in an emergency, when you
cannot stop the vehicle using the brake pedal ⇒ !
Pull and hold the button ⇒ fig. 144 to brake the vehicle hard. An
audio warning signal will sound at the same time.
To stop the braking maneuver, release the button or press the ac-
celerator pedal.
WARNING
Improper use of the electronic parking brake can cause acci-
dents and severe injuries.
Never use the parking brake to slow down the vehicle when it
is moving, except in an emergency. Braking distance is much
longer, since only the rear wheels are braked. Always use the
foot brake.
Never press the accelerator pedal when a selector lever posi-
tion or gear is engaged and the engine is running. The vehicle
could begin moving, even if the electronic parking brake is set.
Never activate the throttle manually from the engine com-
partment when the engine is running and the automatic trans-
mission is in gear. The vehicle will start to move even if the
parking brake is engaged.
NOTICE
Even though the transmission is in Park (P), the vehicle may
move a couple of inches (a few centimeters) forwards or back-
wards if you take your foot off the brake pedal after stopping the
vehicle without first firmly setting the parking brake.
Vehicles with manual transmission: the electronic parking brake
releases automatically when you release the clutch pedal and press
the accelerator pedal at the same time.

Vehicles with gear recommendation aid in fuel efficient driving by in-
dicating the optimum time to shift gears.
Coasting
If you take your foot off the accelerator, fuel delivery to the engine is
interrupted, which lowers fuel consumption.
Therefore, when nearing a red stop light, for instance, allow the vehi-
cle to coast without using the accelerator. Press the clutch pedal and
release it only if the vehicle moving too slowly or the coasting dis-
tance is too long. The engine will then continue to run at idle.
In situations where the vehicle will be stopped for a longer period of
time, such as at a railroad crossing, physically switch off the engine.
Defensive driving and “flowing” with traffic
Frequent braking and acceleration increase fuel consumption signifi-
cantly. Just by driving defensively and keeping a sufficiently large
distance away from the vehicle in front of you can make up for the
speed fluctuations caused by taking your foot off the accelerator. Ac-
tive braking and accelerating is then not necessarily required.
Calm and smooth driving
Consistency is more important than speed. The more smoothly you
drive, the less fuel the vehicle consumes.
When driving on the highway or freeway, a constant, moderate speed
is more efficient and economical than constantly accelerating and
braking. Usually you can reach your destination just as quickly by
driving at a moderate, but steady speed.
The cruise control system can assist in maintaining a uniform driving
style.
Moderate use of extra electrical loads
Comfort inside the vehicle is nice and important, but it is important to
use them in an environmentally conscious manner.
Some devices can increase fuel consumption when activated (exam-
ples):
Climate control system (air conditioner): If the air conditioner has to
produce starkly contrasting temperatures, it requires a large amount
of energy, which is generated by the engine. The temperature in the
vehicle should therefore not be extremely different from that of the

Step Manual transmission Automatic transmission
1. Hold the stopped vehicle on an incline with the foot or parking
brake.
2. The engine must be running “smoothly.”
3. A manual transmission vehicle
must be in 1st gear (1) if
headed up a hill or in Reverse
(R) if backing up a hill; you
must hold the clutch down and
the foot brake must be de-
pressed to keep the vehicle
from moving.
An automatic transmission
vehicle must be in Reverse
(R), Drive (D), or Sport Drive
(S) and the foot brake must be
depressed to keep the vehicle
from moving.
4. To drive off, take your foot off
the brake pedal as you let the
clutch out and gently depress
the accelerator within
2 seconds.
To drive off, take your foot off
the brake pedal and gently
depress the accelerator within
2 seconds.

Hill Hold is immediately deactivated:
If any requirement listed in the table above is no longer met.
If the engine is not running smoothly or the engine malfunctions.
If the engine stalls or is switched off.
Automatic transmission vehicles: If the transmission is in Neutral
(N).
Automatic transmission vehicles: If a tire does not have enough
road contact (such as when the vehicle is tipped or at an angle).

In order to: You must ⇒ fig. 151 Result:
Push and hold the
lever in the 30%%$ – po-
sition (–) to reduce the
set speed until the
lower desired speed is
reached and the lever
is released.
memory.
Switch off cruise
control.
Push the lever to the
/&& position (2).
Pushing the lever briefly
to the first detent deac-
tivates the cruise control
and saves the stored
speed.
Pushing the lever to the
second detent turns off
the cruise control and
deletes the stored speed.

Driving downhill with cruise control
If cruise control cannot maintain constant speed while driving down-
hill, slow the vehicle with the foot brake and downshift if necessary.
Automatic deactivation
Cruise control speed regulation is automatically deactivated or tempo-
rarily interrupted:
If the system detects an error that could affect the function of the
cruise control.
If the vehicle has accelerated and goes faster than the stored
speed for a longer time.
If the brake or clutch pedal is depressed.
If the vehicle shifts gear (manual transmission).
If an airbag deploys.
