properly in accordance with applicable environmental laws and regu-
lations.
Warning and indicator lights

For vehicles with the 3.6 liter engine, the engine oil temperature can
be displayed in the Volkswagen Information System MFI menu ⇒  MFI
menu (Multi-Function Indicator).
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Engine oil specifications

Your engine was factory-filled with a high-quality, “synthetic” all-
season engine oil that meets strict Volkswagen oil quality standards
and has a viscosity grade of SAE 5W-40 or SAE 5W-30. You can use
this oil for normal driving in all temperatures.
If you need to add oil between oil changes, use only a high quality oil
that expressly complies with the Volkswagen oil quality standard
specified for your vehicle's engine:

Engines Engine oil specification
200 hp (147 kW), 2.0L
VW 502 00
VW 503 00
VW 504 00
280 hp (206 kW), 3.6L
VW 501 01
VW 502 00
VW 503 00

At the time this Manual was printed, the engine oils available in the
U.S. that meet these Volkswagen standards are “synthetic” oils. This
does not mean, however, that any “synthetic” engine oil will meet
Volkswagen standards. Always use an approved oil that expressly
complies with the Volkswagen oil quality standard that applies to your
vehicle's engine.
General recommendations:
If “synthetic” oil that meets the applicable Volkswagen oil quality
standard with viscosity grade SAE 5W-40 or SAE 5W-30 is not avail-
able in your area, be sure to use a viscosity grade suitable for the
climate, season, and operating conditions that exist where the vehicle
is used. Make sure the oil meets the quality standard.
Engine oils are constantly being improved. Authorized Volkswagen
dealers and authorized Volkswagen Service Facilities are always up-
to-date regarding new developments and changes. Volkswagen
therefore recommends that you have the engine oil changed by an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.

NOTICE
If you need to add oil and there is none available that meets
the Volkswagen oil quality standard your engine requires, you
may add a total of no more than 1/2 quart (0.5 liter) of a high-
quality “synthetic” oil that meets ACEA A3 specifications and
has a viscosity grade of SAE 5W-40 or SAE 5W-30.
Use only a high quality engine oil that expressly complies with
the Volkswagen oil quality standard specified for your vehicle's
engine. Using any other oil can cause serious engine damage
that will not be covered by any Volkswagen Limited Warranty.
Do not mix any lubricants or other additives into the engine
oil. Doing so can cause engine damage! Damage caused by the-
se kinds of additives are not covered by any Volkswagen Limited
Warranty.
Engine oil capacities

Checking the engine oil level and adding oil

Fig. 165 Oil dipstick with engine oil level marks.

Fig. 166 In the engine compartment: Engine oil filler cap.

dipstick are located, see your authorized Volkswagen dealer or au-
thorized Volkswagen Service Facility for assistance.
5. Remove the dipstick from the guide tube and wipe the dipstick off
using a clean cloth.
6. Reinsert the dipstick into the guide tube and push it all the way in. If
there is an alignment tab on the engine oil dipstick, make sure it
lines up with the notch in the guide tube, and that the dipstick goes
all the way in.
7. Remove the dipstick again and read the oil level on the dipstick
⇒ fig. 165 as described below:
(A): Do not add any oil ⇒ . Continue with step 15.
(B): Oil may be added (about 1 pint / 0.5 liter). Continue with step 8
or step 15.
(C): You must add oil (about 1 quart / 1.0 liter). Continue with step
8.
8. After reading the oil level, reinsert the dipstick back into the guide
tube and push it all the way in.
9. Remove the cap on the engine oil filler opening ⇒ fig. 166.
10. Only add engine oil that Volkswagen has approved for that
engine. Add the oil gradually in small quantities (no more than
1 pint / 0.5 liter).
11. To help prevent overfilling, you must wait about 1 minute each
time you add oil so that the oil can flow into the oil pan up to the
marking on the dipstick.
12. Read the oil level on the dipstick again before adding another
small amount, if necessary. Never add too much oil ⇒ .
13. After adding oil, the level must at least be in the center of the
⇒ fig. 165 (B) area, but never above (A) ⇒ .
14. After adding oil, securely install the cap on the engine oil filler
opening. Otherwise, oil could leak out while the engine is running.
15. Insert the oil dipstick back in the guide tube and push it all the
way in.
16. Close the hood ⇒ 
Engine oil level ranges

fig. 165 Required action according to the respective en-
gine oil level:
Range (A) Do not refill oil ⇒ .
Range (B) You may add oil (about 1 pint / 0.5 liter). The oil level
may go into the (A) range, but not above the (A)
range.
Range (C) You must add oil (about 1 quart / 1.0 liter). After add-
ing oil, make sure that the oil level is about in the
middle of the (B) range.

WARNING
Engine oil can ignite when it touches hot engine parts. This can
cause fires, burns, and other severe injuries.
Never spill oil on the engine. Oil spilled on a cold engine can
also cause a fire when the engine warms up.
Always make certain that you screw the cap of the engine oil
filler opening back on tightly after adding oil and that the dip-
stick has been pushed all the way back into the in the guide
tube. This helps prevent engine oil from leaking onto the hot
engine when the engine is running.
NOTICE
Do not start the engine if the engine oil level is above range
(A). Contact an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility. Otherwise the catalytic converter
and engine can be damaged!
When changing or topping off fluids, make sure that you pour
the fluids into the correct reservoirs. Adding the wrong type of
operating fluids will cause serious malfunctions and engine
damage.
The engine oil level should never be above range (A). Otherwise
oil can be drawn in by the crankcase ventilation system and enter the
atmosphere via the exhaust system.

Engine oil consumption

(0.5 liter per 1000 km). Consumption may be higher for new vehicles
during the first 3000 miles (5000 km).
Changing engine oil

WARNING
If you must change the engine oil yourself, be sure to take the
following precautions:
Always wear eye protection.
To reduce the risk of burns from hot engine oil, let the engine
cool down completely before beginning.
When removing the oil drain plug with your fingers, stay as
far away as possible. Always keep your forearm parallel to the
ground to help prevent hot oil from running down your arm.
Drain the oil into a container designed for this purpose, one
large enough to hold at least the total amount of oil in your en-
gine.
To reduce the risk of poisoning, never drain the oil into emp-
ty food or beverage containers that might mislead someone in-
to drinking from them.
Engine oil is poisonous and must be stored out of the reach
of children.
Continuous contact with used engine oil is harmful to your
skin. Always protect your skin by washing thoroughly with
soap and water.
Before changing the oil, first make sure you know where you can
properly dispose of the old oil.
Dispose of the old oil an environmentally-responsible manner.
Never dump the old oil on garden soil, in wooded areas, in the street,
into streams, rivers, or bodies of water, or down sewage drains.
Recycle used oil by taking it to a collection facility for used engine
oil in your area, or contact an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
Volkswagen recommends that you always have your oil and oil
filter changed by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility. They have the required expertise and
special tools and will dispose of the old oil properly.
