VOLKSWAGEN CC 2011 Owners Manual

Fig. 181 Hexagonal head screw for closing the power sunroof.

Emergency release for the selector lever lock

Fig. 182 Removing the selector gate cover.

Fig. 183 Releasing the selector lever lock (Versions A and B).

Preparations
Set the electronic parking brake. If the electronic parking brake
cannot be set, you must find another way to help prevent the vehicle
from moving.
Switch off the ignition.
Removing the selector gate cover
Pull upward on the cover around the selector lever sleeve
⇒ fig. 182.
Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever (Version A)
With the screwdriver from the vehicle tool kit, carefully push the
release lever ⇒ fig. 183 A in the direction of the arrow and hold it in
this position.
Press the release button in the selector lever handle and shift the
selector lever to Neutral (N).
Carefully press the selector gate cover back in place, making sure
that the electrical wiring stays in the correct position and is not
pinched or damaged.
Emergency release for the selector lever (Version B)
Push the release lever ⇒ fig. 183 B in the direction of the arrow and
hold it in this position.
Press the release button in the selector lever handle and shift the
selector lever to Neutral (N).
Carefully press the selector gate cover back in place, making sure
that the electrical wiring stays in the correct position and is not
pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first setting
the electronic parking brake. Otherwise, the vehicle can start to
roll unexpectedly, especially on hills or inclines, and cause an
accident and serious injuries.

NOTICE
Even with the selector lever is in Neutral (N), the automatic
transmission will be damaged if the vehicle is towed (or you let it
coast) for an extended period or at high speed with the engine
shut off.

Vehicle tool kit

Storage

Fig. 184 In the luggage compartment underneath the floor panel 1:
Spare tire and cover 3 for vehicle tool kit.

Contents

Fig. 185 Contents of the vehicle tool kit.

Wheel trim

Hubcaps

Fig. 186 Pulling the hubcap off.

Fig. 187 Twisting the hubcap off.
