After adjusting the tire inflation pressures, make sure to screw the
valve caps back on; replace missing valve caps immediately. Please
read and heed the information on resetting the Tire Pressure Monitor-
ing System, if necessary ⇒  Tire Pressure Monitoring System (TPMS).
Remember that the vehicle manufacturer, not the tire manufacturer,
determines the correct tire pressure for the tires on your vehicle.
Never exceed the maximum inflation pressure listed on the tire side-
wall for any reason.
Inflate a spare wheel to the pressure specified for the vehicle's road
wheels on the tire pressure label; inflate a compact spare wheel to
the pressure specified for the compact spare on the tire pressure la-
bel or on a separate label for the compact spare, if there is one.
WARNING
Incorrect tire pressure can cause a sudden tire failure or blow-
out, loss of control, collision, serious personal injury, and even
death.
Always inflate tires to the recommended and correct cold tire
pressure before driving off.
Low tire pressure can cause tires to get too hot, resulting in
tread separation, sudden loss of pressure, and blowouts. Tires
with excessively low pressure flex (bend) more, which can
cause the tire to overheat and fail suddenly without warning.
Excessive speed and/or overloading can cause heat build-up,
sudden tire failure including a blowout and sudden deflation
and loss of control.
If the tire pressure is too low or too high, the tires will wear
prematurely and the vehicle will not handle well.
Regularly check tire inflation pressure, at least once a month,
and also especially before a long trip.
Check the pressure in all 4 tires when the tires are still cold.
Never reduce air pressure in warm tires to match cold tire infla-
tion pressure.
NOTICE
Make sure not to jam the tire pressure gauge into the valve
stem. Otherwise you can damage both the tire valves and the tire

Engine Tire dimensions Tire pressure
bar psi kPa
3.6 L / 280 hp (206 kW)
4MOTION
235/45 R 17 2.3 34 230
235/40 R 18 xl 2.6 38 260
xl = reinforced sidewall.
The Tire Pressure Monitoring System is configured at the factory
with the correct tire inflation pressure applicable for the vehicle
model, engine and factory-installed tires. The tire inflation pressure
is listed on the tire inflation pressure label on the driver door jamb⇒ ,
Tire inflation pressure. The tire inflation pressures for the road tires
are listed on this label. The inflation pressure for the compact spare
is as specified on the tire pressure label or on a separate label for
the compact spare, if there is one. In the event of a discrepancy be-
tween the above figures and the tire pressures listed on the tire infla-
tion pressure label, the pressures listed on the label are the ones
you should use. The listed pressure applies to all road tires. If differ-
ent tires are installed that do not have the same cold tire inflation
pressure as the tires originally installed on your vehicle, the Tire
Pressure Monitoring System cannot properly monitor tire inflation
pressures unless the TPMS is reset to the new tire pressures
⇒ page 295. Authorized Volkswagen dealers and authorized
Volkswagen Service Facilities have the necessary special tools and
can reset the TPMS for the new tires on your vehicle.

After changing a wheel, have the wheel bolt tightening torque
checked with an accurate torque wrench.
After changing a wheel or tire, reset the Tire Pressure Moni-
toring System ⇒  Tire Pressure Monitoring System (TPMS).
Preparations for changing a wheel
