VOLKSWAGEN CC 2014 Owners Manual

Lift points for the vehicle

Fig. 173 Front lift point for workshop hoist or floor jack.

Fig. 174 Rear lift point for workshop hoist or floor jack.
The vehicle may only be raised at the lift points shown in illustrations
⇒ fig. 173 and ⇒ fig. 174. If the vehicle is lifted at different points, ve-
hicle damage ⇒  and serious injuries may occur ⇒ .
Workshop hoists that use fluid cushions (receiving platforms) must
not be used for lifting the vehicle.
There are many precautions that have to be followed when lifting a
vehicle on a workshop hoist or floor jack. Do not try to lift a vehicle on
a workshop hoist or floor jack unless you have the training,
knowledge, and experience to be able to do so safely.
Information about lifting the vehicle with the vehicle jack ⇒  Lifting the
vehicle with the vehicle jack or ⇒  Lifting the vehicle with the vehicle
jack (CC R-Line), respectively.

WARNING
Improperly lifting your vehicle with a workshop hoist or a floor
jack can cause the vehicle to fall off and cause serious person-
al injury.
Always read and heed the operating instructions from the
floor jack manufacturer and legal regulations if necessary be-
fore using the floor jack to lift the vehicle.
Never let anyone stay in the vehicle when it is being lifted or
when it is off the ground.
Always lift your vehicle only at the designated lift points
shown in the illustrations ⇒ fig. 173 and ⇒ fig. 174. Not using the
designated lift points can cause the vehicle to fall off the floor
jack when heavy parts such as the engine or transmission are
removed.
Always make sure that the vehicle's lift points lie as flat as
possible and centered on the carrier plates of the floor jack.
Never start the engine when you have raised the vehicle on
the floor jack. The engine vibrations and vehicle movements
could knock the vehicle off the floor jack.
If you must work under a vehicle raised on a floor jack, al-
ways make sure that the vehicle is safely supported on safety
stands intended for that purpose that are strong enough to
support the weight of the vehicle.
Never use the floor jack as a ladder or step ladder.
Always make sure that the weight of the vehicle is not heavi-
er than the lifting capacity of the floor jack and safety stands
being used.
NOTICE
To help prevent serious vehicle damage, never lift the vehicle
by the engine oil pan, transmission housing, or by the front or
rear axles or suspension.
To help prevent damage to the underbody or chassis, always
insert a rubber pad between the hoist and the lifting points. In
addition make sure the lifting arms have enough clearance.
The lifting arms should not touch side sills or other parts of
the vehicle.

In an emergency

Protecting yourself and the vehicle

Fig. 175 In the center of the instrument panel: Button for the emer-
gency flashers.

8. Set up a warning triangle or other warning device in order to alert
other motorists and cyclists.
9. Let the engine cool down and get expert assistance if necessary.
If the emergency flashers are on, use the turn signal lever to indicate
a direction or lane change, for example when the vehicle is being
towed. This temporarily interrupts the emergency flashers.
Switch on the emergency flashers when:
Traffic suddenly slows down or stops in front of you to warn those
approaching from behind.
In any emergency situation.
If the vehicle breaks down.
When being towed.
Always obey traffic laws that govern the use of emergency flashers
where you are driving.
If the emergency flashers are not working, a different method – as
permitted by law – must be used to alert other motorists and cyclists
to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents
and serious personal injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
WARNING
The vehicle exhaust system and the catalytic converter get very
hot. They can cause fires and serious personal injury.
Never park where parts of the hot exhaust system or catalytic
converter could ignite flammable materials, such as dry grass,
brush, leaves, spilled fuel, etc.
The vehicle battery will be drained if the emergency flashers are
on for a long time – even if the ignition is switched off.

Emergency closing and opening

WARNING
Serious injuries can result if the emergency closing and open-
ing procedures are used carelessly.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency.
A closed vehicle can become very hot or very cold, depend-
ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.
WARNING
Careless opening and closing of the doors, the luggage com-
partment lid, and the power sunroof is dangerous and can
cause serious personal injury.
Open or close the doors, the luggage compartment lid, and
the power sunroof only when no one is in the way.
NOTICE
If the vehicle's battery fails or the power windows won't work,
the door windows are not lowered when the door is opened or
closed. Always close and open the door carefully to help prevent
damage to the window, the paint, or the rubber seal.
NOTICE
To help prevent vehicle damage, carefully remove and properly
reinstall parts after emergency locking or unlocking.

Manually unlocking and locking the driver door

Fig. 176 Door handle on driver door: Concealed lock cylinder.

Switch on the ignition. The electronic immobilizer recognizes a val-
id remote control vehicle key when the ignition is switched on and
deactivates the anti-theft alarm system.
The driver door can be unlocked separately from the inside the
vehicle by pulling the door handle to open the door ⇒ Unlocking or
locking the vehicle from the inside.
The anti-theft alarm system, when installed, is not activated when
the vehicle is locked manually with the emergency key ⇒ page 67,
Power locking and closing system.
Manually locking the passenger doors

Fig. 177 On the edge of the right rear door: Emergency lock, covered
by a rubber seal.

Fig. 178 Locking the vehicle using the emergency key.
