Side view

Fig. 1 Vehicle side overview.
Key to ⇒ fig. 1:
(1) Fuel filler flap
(2) Roof antenna
(3) Outside door handles
(4) Outside mirror:
– Additional turn signal light
– Background lighting
(5) Lift points for the jack

Upshifting early into the next higher gear saves fuel and reduces
engine noise.
Displays

Fig. 10 In the instrument cluster display: A: Open engine hood, B:
Open luggage compartment lid, C: Open front driver side door, D:
Open rear passenger side door.

The trip odometer (trip) shows the distance driven since the last time
the trip odometer was reset. The last digit indicates 1/10 mile
(100 meters).
Outside temperature display
At outside temperatures below about +39 °F (+4 °C), a “snowflake
symbol” (icy road warning) appears in the display. The symbol flashes
at first, then stays on until the outside temperature rises above +43 °F
(+6 °C) ⇒ .
When the vehicle is not moving or when you are driving at very low
speeds, the temperature displayed may be slightly higher than the
actual outside temperature.
The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C).
Compass display (if applicable)
On vehicles equipped with compass display, the current compass
direction is indicated in the instrument cluster display when the igni-
tion and navigation system are switched on ⇒  Compass.
Selector lever positions
The selector lever position is shown both on the side of the selector
lever and in the instrument cluster display. The respective gear may
also be shown in the instrument cluster display in Drive D and Sport
Drive S, as well as in Tiptronic® mode.
Gear recommendation (manual transmission)
When the vehicle is moving, a fuel economy gear recommendation
may appear in the instrument cluster display ⇒  Shifting.

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside
air temperature is above freezing.
If you use the outside temperature display to tell you about
frost conditions, remember that roads can even ice over at
temperatures above +39 °F (+4 °C). Always remember: even if
the “snowflake symbol” (icy road warning) is not displayed,
there could still be black ice on the road.
Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
The instrument cluster displays and their arrangement may vary
depending on the vehicle model and engine. For displays without
warning and information messages, malfunctions are only signaled
with indicator lights.
If there are multiple warning messages, the symbols are dis-
played for several seconds in order of importance. The symbols are
displayed until the cause has been corrected.

▪ Speed warning --- mph
Audio ⇒ Booklet Radio or ⇒ Booklet Navigation system
Navigation ⇒ Booklet Navigation system
Phone ⇒ Booklet Mobile Phone Package
Assistants
▪ AFS
Vehicle status
Settings
▪ Language
▪ MFI data
– Travel time
– Curr. consum. (current fuel consumption)
– Av. consum. (average fuel consumption)
– Route
– Av. speed (average speed)
– Digit. speed (digital speed display)
– Oil temperature (3.6 liter engine only)
– Speed warn. (speed warning)
– Back
▪ Convenience
– ATA confirm
– Easy Open (on/off)
– Central locking
Auto lock
Auto unlock
Unlock doors
Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror down (on/off)

1 Single trip
memory
The memory accumulates and stores infor-
mation about distance driven and fuel used from
the time the ignition was switched on until the
time it was switched off.
If the ignition stays off for 2 hours or more,
stored information is automatically deleted. If the
trip is continued within 2 hours after the ignition
was switched off, the new values are added.
2 Total trip
memory
The memory displays and stores the accumulat-
ed driving and fuel consumption data of any
number of single trips up to a total driving time
of 99 hours and 59 minutes, and up to a total
distance of 9,999 miles (9,999 km). If one of the
maximum values is exceeded, then the memory
is automatically cleared and starts again from 0.

Possible MFI menu displays
The following displays can be accessed in the MFI menu if enabled
under Settings > MFI data. Displays that are not enabled will not
appear.

Display Function
Travel time Driving time in hours (h) and minutes (min) cor-
responding to trip memories 1 and 2 (toggle).
Consumption
--.- mpg
Current fuel consumption in miles per gallon
(l/100 km) while driving.
When units are set to miles, dashes appear in-
stead of a number when the engine is running
and the vehicle is standing still.
When units are set to kilometers, the display
shows liters consumed per hour when the en-
gine is running and the vehicle is standing still.
Consumption
--.- l/100 km
Av. consumption
--.- mpg
Average fuel consumption in miles per gallon
(l/100 km) on trips per trip memories 1 and 2

Display Function
Av. consumption
--.- l/100 km
(toggle) is displayed once the vehicle has been
driven about 330 feet (100 m). Until then, dash-
es appear instead of a number. The value dis-
played is updated every 5 seconds.
Range  -- mi Estimated distance in miles (km) that the vehicle
can go with the fuel left in the tank the way you
are currently driving. Takes account of the cur-
rent fuel consumption, among other things. Range  -- km
Route -- mi Distance driven in miles (km) per trip memories
1 and 2 (toggle).
Route -- km
Average speed
-- mph
Average speed on trips per trip memories 1 and
2 (toggle). Displayed once the vehicle has been
driven about 300 feet (100 m). Until then, dash-
es may appear instead of a number. The value
displayed is updated every 5 seconds.
Average speed
-- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature Current engine oil temperature (digital display;
3.6 liter engine only).
Speed warning
--- mph
When the set speed (from 20–155 mph or 30–
250 km/h) is exceeded, an acoustic warning
sounds and a visual message may also appear
in the instrument cluster display. Speed warning
--- km/h

Switching between the displays
Use the arrow up and down buttons (* and +) on the multi-
function steering wheel.

Settings
menu
Function
Lights &
Vision
Vehicle lighting settings
Time Set hours and minutes for the instrument cluster
clock, the Radio & Navigation System clock, and the
analog clock. The digital clocks can be set to show
the time in 12 or 24 hour format, and can also be set
to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-
installed navigation system. To calibrate, follow the
instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory
setting
Reset the functions in the Settings menu back to the
factory settings.

Lights & Vision submenu

WARNING
Vehicle health reports do not replace the information provided
by the vehicle warning and indicator lights. Failure to heed
warning lights and instrument cluster text messages can cause
the vehicle to break down in traffic and result in a collision and
serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
Before opening the engine hood, always switch off the en-
gine and let the engine cool down.
Always be very careful when working in the engine compart-
ment, which is a potentially dangerous area in any motor vehi-
cle and can cause serious personal injury.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Volkswagen collects, processes, transmits, uses and shares in-
formation about you and your vehicle in accordance with the
Volkswagen Car-Net Terms of Service and Privacy Policy. See the
Volkswagen Car-Net Terms of Service and Privacy Policy at
http://www.vw.com/carnet for more details.
Volkswagen Car-Net services use a system based on a wireless
communication network. If all technical and other conditions are met
and Volkswagen Car-Net still does not work properly, please try using
the service again later.

Remote Vehicle Access:
Feature Description
Remote
Status
Check
Current information about the vehicle can be viewed
through a computer or your Volkswagen Car-Net iPh-
one® or Android® app (text and data rates apply). You
can find out if the doors, luggage compartment and
engine hood are open or closed, whether the car lights
are on or off, the level of fuel in the tank, when the
vehicle needs to be serviced next and more.


Diagnostics & Maintenance:
Feature Description
Dealer
Scheduling
Press the • button in the 3-button module: The vehi-
cle will initiate a call to the Volkswagen Car-Net Re-
sponse Center where a Volkswagen Car-Net Custom-
er Specialist will connect you with an authorized
Volkswagen dealer to schedule your service appoint-
ment. The address of the dealer’s location can also be
sent by the Customer Specialist to your factory-
installed navigation system (if equipped).
Vehicle
Health
Report
View a vehicle health report to proactively manage
maintenance and other services and to receive up-to-
date diagnostics in a monthly email report or by im-
mediate request.
