VOLKSWAGEN CC 2017 Owners Manual

Fig. 68 Proper safety belt positioning for expectant mothers.

Adjusting safety belt height
The safety belt position can be adjusted using the following features:
Safety belt height adjusters for the front seats.
Front seats with height adjustment.

WARNING
Improperly positioned safety belts can cause serious personal
injury in an accident or a sudden braking maneuver.
Always make sure that all vehicle occupants are correctly re-
strained and stay in a correct seating position whenever the
vehicle is being used.
Safety belts offer optimum protection only when the seat
backrest is upright and belts are correctly positioned on the
body.
A loose-fitting safety belt can cause serious injuries by shift-
ing its position on your body from the strong bones to more
vulnerable soft tissue and cause serious injury.
The shoulder belt portion of the safety belt must be posi-
tioned over the middle of the occupant's shoulder and never
across the neck or throat.
The safety belt must lie flat and snug on the occupant's up-
per body.
Never wear the shoulder part of the safety belt under your
arm or otherwise out of position.
The lap portion of the safety belt must be positioned as low
as possible across the pelvis and never over the abdomen.
Make sure the belt lies flat and snug against the pelvis. Pull on
the safety belt to tighten if necessary.
Expectant mothers must always wear the lap portion of the
safety belt as low as possible across the pelvis and below the
rounding of the abdomen.
Do not twist the belt when attaching it. If you cannot untwist
a twisted safety belt, wear it anyway, but make sure the twisted
part is not in contact with your body. Have the problem correct-
ed right away by an authorized Volkswagen dealer or author-
ized Volkswagen Service Facility.
Never hold the safety belt away from your body with your
hand.
Never wear belts over rigid or breakable objects, such as
eyeglasses, pens or keys.
Never modify the position of the belt using comfort clips,
loops or similar devices.

If you have a physical impairment or condition that prevents you
from sitting properly on the seat with the safety belt properly fastened,
special modifications to your vehicle may be necessary. Contact your
authorized Volkswagen dealer or authorized Volkswagen Service
Facility or call the Volkswagen Customer CARE Center at 1-800-822-
8987 for information about possible modifications to your vehicle.
Safety belt height adjusters

Fig. 69 Next to the front seats: Safety belt height adjuster.

Safety belt extender

Fig. 70 A safety belt extender properly attached to the factory-
installed safety belt.

Fig. 71 Positioning of the safety belt extender.

Key to fig. 70:
(1) Vehicle safety belt buckle.
(2) Buckle tongue on the safety belt extender.
(3) Safety belt buckle on the safety belt extender.
(4) Safety belt buckle tongue on the factory-installed safety belt.
Key to fig. 71:
(A) Safety belt buckle on the safety belt extender.
(B) Distance between the safety belt buckle on the safety belt ex-
tender and the centerline of the person using the safety belt ex-
tender. The distance must be more than 6 inches (15 cm)!
(C) Centerline of the person using the safety belt extender.
Using a safety belt extender
Adjust both the seat and the head restraint properly ⇒ Adjusting the
seating position.
Insert the buckle tongue on the safety belt extender ⇒ fig. 70 (2)
into the vehicle belt buckle for the seat where the safety belt extender
is being used (1).
Fastening or unfastening the vehicle safety belt ⇒ Fastening and
unfastening safety belts.
Pull the belt to make sure that the tongues are securely locked in
the buckles.
Make sure that the safety belt is positioned properly ⇒ Safety belt
position.
Properly using safety belt extenders:
Use a safety belt extender only when the factory installed safety
belt is too short when worn properly by a person in proper seating
position.
Only use 1 safety belt extender per seat and vehicle safety belt.
Always remove the safety belt extender when it is not needed.
Never leave a safety belt extender attached to the vehicle safety
belt buckle when the extender is not needed and being used with the
safety belt. Otherwise, the airbag control module will receive an incor-
rect signal from the safety belt buckle and this will prevent the airbag
from working properly for a person who is not using the safety belt.
Leaving the extender attached to the safety belt buckle when the front
seat is occupied and the safety belt is not being used will signal the
airbag control unit during a collision that the front passenger seat is

Lights

Indicator lights

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Whenever stalled or stopped for repair, move the vehicle a
safe distance off the road, stop the engine, turn on the emer-
gency flashers, and use other warning devices to warn ap-
proaching traffic.
Never park the vehicle in areas where the hot catalytic con-
verter and exhaust system can come into contact with dry
grass, brush, spilled fuel, oil, or other material that can catch
fire.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
High Intensity Discharge (HID) headlights provide bright, uniform
lighting to help you see and be seen. The light comes from an electric
arc between two electrodes in the gas-filled bulb. Over time, the elec-
trodes can wear down and the gap between them will get wider. The
HID lamp’s control unit then increases the voltage to keep the arc’s
brightness constant. However, the commonly called “Xenon” bulbs
will also ultimately burn out. Before they burn out, HID lamps can
flicker. A message will then appear in the MFI. This is your reminder
to see an authorized Volkswagen dealer or an authorized
Volkswagen Service facility to check the headlights.

Turn signal lever and high beam switch

Fig. 85 Turn signal lever and high beam switch.
