VOLKSWAGEN E GOLF 2015 5G / 7.G Owners Manual

Immediate charging

Fig. 139 In the high-voltage battery charge port: Immediate charging button 1.

Cruise control

Indicator lights

Fig. 140 In the instrument cluster display: Cruise control status indications.

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
If the cruise control is switched on when the ignition is switched off, it may be switched on auto-matically the next time the ignition is switched on, depending on vehicle equipment. No speed is stored for the cruise control.
The displays may vary depending on vehicle equipment.
Cruise control operation

Fig. 141 On the turn signal lever: Cruise control buttons and switches.

In order to: You must: ⇒ fig. 141 Result:
Temporarily
deactivate
cruise con-
trol.
Move switch (1) on the turn signal
lever to the #!.#%, position.
OR: Depress the brake pedal.
Cruise control is tem-
porarily deactivated.
The speed is still
stored in the memory.
Resume
speed stored
in cruise con-
trol.
Press button (2) on the turn signal
lever in the area marked 2%3

x If the brake or clutch pedal is depressed.
x If regulation related to driving dynamics is taking place, for example, though ESC.
x If an airbag deploys.
x Automatic transmission: If the selector lever is shifted from D/S to another position.

Rear View Camera system

WARNING
The Rear View Camera system technology cannot overcome the laws of physics and the limits of the system. Careless or unintentional use of the Rear View Camera system may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility condi-tions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the Rear View Camera system may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use the Rear View Camera system only when the rear hatch is completely closed.
NOTICE
x The Rear View Camera system shows only two-dimensional images on the screen. Due to the lack of depth of field, it may be difficult or impossible to identify protruding objects or recesses in the road, for example.
x Things like thin rods, fences, posts, and trees may not be detected by the Rear View Cam-era system and could damage the vehicle.
Special considerations

x Apply the parking brake to help prevent the vehicle from moving ⇒ page 244, Electronic parking brake.
x Switch on the ignition.
x Switch on the Infotainment system (if not already on) ⇒ page 24, Infotainment system.
x Shift into Reverse (R).
x Tap the function key.
x Adjust the desired settings in the menu.
It is not possible to open the rear hatch if the Volkswagen emblem is folded out.
Camera

Fig. 142 In the rear hatch: Location of the camera.

Cleaning the camera lens
Keep the camera lens clean and free of snow and ice:
x Park the vehicle in a safe place on a firm, level surface.
x Switch on the ignition (but do not start the electric motor).
x Apply the parking brake to help prevent the vehicle from moving ⇒  Electronic parking brake.
x Shift into Reverse (R).
x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
x Shift the vehicle out of Reverse (R).
x Switch off the ignition.
NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the camera lens.
Operation

Fig. 143 In the Infotainment system: Rear View Camera system display (display may vary depending on vehicle equipment).
