VOLKSWAGEN EOS 2010 Owners Manual

Luggage compartment cover

Fig. 97 Lifting up the inside luggage compartment cover.

Fig. 98 Removing the inside luggage compartment cover.

Lowering the luggage compartment cover
x Using handle (A), pull back slightly on the luggage compartment cover to release the hooks from the tabs.
x Lower the cover and push it completely into its latches (magnified view), so that these engage.
Removing the luggage compartment cover
x Lift the cover up.
x Pull the latch ⇒ fig. 98 (magnified view) in the direction of the arrow to release the hinge.
x Raise the left side of the luggage compartment cover until the left locking pin lifts out of the attachment.
x Pull the luggage compartment cover slightly to the left to pull the right locking pin out of its attachment.
x Remove the luggage compartment cover. It is now impossible to open and close the CSC roof.
Installing the luggage compartment cover
To install the luggage compartment cover, perform the steps for removal in reverse order.
In order to open or close the CSC roof, the luggage compartment cover must be down and
locked in place in its latches ⇒ fig. 97 (inset).
Driving with an open luggage compartment lid

WARNING
Driving with an open luggage compartment lid can cause poisonous carbon monoxide in the engine exhaust to get into the passenger compartment.
x Carbon monoxide causes drowsiness, inattentiveness, poisoning, and loss of consciousness. It can lead to accidents and severe personal injuries.
x Always keep the luggage compartment lid closed while driving to help keep poisonous exhaust fumes from being drawn into the vehicle.
x Never transport objects that are too large to fit completely into the luggage area, because then the luggage compartment lid cannot be fully closed.
x If you absolutely must drive with the CSC roof closed and an open luggage compartment lid, do the following to reduce the risk of carbon monoxide poisoning:
– Close all windows, the CSC roof, and the sunroof.
– Switch off the climate control system's air recirculation feature.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.
NOTICE
The open luggage compartment lid changes the vehicle height.
Driving a loaded vehicle

WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
x Always tie down heavy items securely with suitable straps.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Weights and axle weights

WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as little as possible.

Luggage compartment

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal injury during hard braking or sharp steering or in an accident. Loose items can also be struck and thrown through the passenger compartment by the front airbags if they inflate. To help reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that they cannot move into the deployment zone of a side or front airbag during sudden braking, in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle interior and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and increases braking distances. Heavy loads which are not properly stowed or secured in the vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the rear axle as possible and secure them with appropriate straps.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings, which are printed on the Safety Compliance Certification Label located on the door jamb of the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave differently.
x Always adapt your speed and driving style to accommodate your payload and its weight distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid sudden braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
The defroster heating wires in the rear window can be damaged by objects that rub against them.

Luggage compartment pass-through

Fig. 99 In the rear backrest: Opening the luggage compartment pass-through cover.

Fig. 100 From the passenger compartment: Opening the pass-through panel into the luggage compartment.

x Hook the bottom of the pass-through cover into position, then push up to close, making sure that it latches into place.
The pass-through can be locked and unlocked using the vehicle key.

Roof rack
Important information about roof racks
For technical reasons, the vehicle body is not designed to carry a roof rack. Never mount a roof rack
on your vehicle. Mounting a roof rack will do considerable damage to the vehicle ⇒ .
WARNING
Mounting a roof rack on the vehicle can cause an accident and serious personal injuries.
x Never mount a roof rack on the vehicle.
x A roof rack could come loose while driving and fall off the roof of the vehicle.
NOTICE
Installing a roof rack or carrier of any kind will cause expensive damage to your vehicle that will not be covered by any Volkswagen Limited Warranty.
