VOLKSWAGEN EOS 2015 1.G Repair Manual

Closing the luggage compartment lid

Fig. 29 Opened luggage compartment lid: Recessed grip for closing.

Power windows

Switches in the driver door
Key to fig. 30:
(1) To open or close all windows at the same time.
(2) For the windows in the doors.
(3) For the rear side windows.
Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch.
Open all windows: Press the - switch.
Close all windows: Pull the - switch.
Stopping automatic movement: Press/pull the respective switch again.

You can still use the power windows for several minutes after the ignition is switched off as long as the driver or passenger door has not been opened. When the vehicle key has been removed from the ignition and the driver door has been opened, the power windows cannot be opened or closed.
A separate button for controlling the window is located in the front passenger door.
Power windows – features

One-touch opening and closing
The one-touch feature automatically opens/closes a power window all the way. The window switch does not have to be held down/up.
For one-touch opening: Press the switch for the window down briefly as far as it goes.
For one-touch closing: Pull the switch for the window up briefly as far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not completely closed, the one-touch feature will not work and must be reactivated:
x Close all windows and doors.
x Insert the vehicle key into the door lock and turn and hold the key for more than 2 seconds in the direction of locking. See, Manually unlocking and locking the driver door.
x Release the key and then again turn and hold it in locking direction for more than 2 seconds. The one-touch feature is now reactivated.
The one-touch feature can be reactivated for one or more windows at the same time.
Convenience closing
The convenience closing feature lets you close the windows and the power sunroof from outside the vehicle as follows:
x Manual locking: lock the vehicle with the vehicle key bit in the driver door and keep the key turned in the locking position to close all windows and the power sunroof, Manually unlocking and locking the driver door.
Convenience closing first closes the windows and then the power sunroof.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children, remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power windows for several minutes after the ignition is switched off as long as the driver or passenger door has not been opened.
NOTICE
The windows must go down slightly when you unlock the vehicle. Otherwise the windows and seals could be damaged when opening the doors.
If the power windows malfunction, the one-touch feature, as well as pinch protection may not work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.
If convenience closing of the power windows requires removing the cover cap of the lock cylinder on the driver door, the cover cap must be reinstalled after the vehicle is locked, Manually unlocking and locking the driver door.

Power window pinch protection

CSC roof

WARNING
Accidents and serious injury may result from driving when the CSC roof has not properly locked into place or when the process of opening or closing the roof is incomplete. Even at low speeds, air resistance can twist or deform the roof or tear it off completely, endangering vehicle occupants and others.
x Never drive when the CSC roof is not completely open or not completely closed and securely latched unless you must move the vehicle to a safe place away from traffic.
x If you must move the vehicle to another location for safety reasons and the CSC roof is not completely open or not completely closed and securely latched, we recommend that you do not drive any faster than a slow walk.
x When opening and closing the CSC roof, always make sure no one will be injured by the supports and other moving parts.
NOTICE
x To help prevent damage, remove ice and snow from the CSC roof before opening it in winter weather.
NOTICE
x Volkswagen advises against all unauthorized changes to the CSC roof controls or to the way the roof opens and closes.
x Damage to the CSC roof system caused by changes to the CSC roof system controls will not be covered by any Volkswagen Limited Warranty. The terms and conditions of your
Volkswagen Limited Warranties are in the ⇒ Booklet Warranty and Maintenance.
x The CSC roof has been designed to be opened and closed only when the vehicle is stopped. As your vehicle was manufactured, the roof cannot be opened or closed when the vehicle is being driven, for example, at low speeds. Roof operation even at low speeds can cause the roof to be deformed and damaged because of the increased forces from wind resistance. Wind resistance can also cause parts of the linkages and the hydraulic system to wear prematurely, and could even cause parts of the roof to separate and fall into the vehicle or onto the roadway or onto another vehicle.
x The CSC roof has been designed to open and close only when the lever on the center
console ⇒ fig. 32 is pushed or pulled and held in that position until the roof has opened / closed completely. Releasing the lever stops roof movement. A chime sounds when the roof is moving. As your vehicle was manufactured, the roof cannot be operated in a one-touch up or down mode. The roof was designed this way for your safety and that of your passengers. One-touch operation would make it possible for the driver to leave the vehicle unsupervised while the roof, rear lid, and windows move into position. This would increase the risk of vehicle damage and personal injury to bystanders, especially to children.
x If the way the CSC roof works on your vehicle has been changed from the way it was manufactured, we urge you to have your authorized Volkswagen dealer or authorized Volkswagen Service Facility change it back so that it will only open and close as originally manufactured. Mechanical changes and changes to the vehicle software must be entered in the
⇒ Booklet Warranty and Maintenance.
Indicator light

Lights up Possible cause Proper response
CSC roof is opening or closing. Wait until the CSC roof has fully opened or fully closed.


Flashes Possible cause Proper response
The CSC roof opening or closing process is not finished or there is a CSC roof malfunction.
Check if the opening or closing process has finished. If necessary, end the process using the convertible top button
Check if all technical requirements are met. If not, take the necessary steps to meet the technical requirements
Check if there is a malfunction in the CSC roof. If necessary, correct the malfunction or have the system checked by your authorized Volkswagen dealer or authorized Volkswagen Service Facility

Messages in the instrument cluster display
When the ignition is switched on, the indicator lights come on briefly for a function check. They go out after a few seconds.

Display text Proper response
Trailer: No convert. top operation!
Unhitch trailer.
Close luggage compartment cover! Flip down the inside luggage compartment cover. Make sure that it has locked into place.
Speed too high! Stop the vehicle at an appropriate spot. The CSC roof can only be operated when the vehicle is not moving
Close trunk lid! Close the luggage compartment lid. The CSC roof can only be operated when the luggage compartment lid is closed. Use emergency procedure to close the open CSC roof if necessary
Obstacle in rear area! Remove any obstacles behind the vehicle or move the vehicle forward so as to have enough room for the luggage compartment lid to swing out.
Close sliding roof! Close the power sunroof. While doing so, make sure that it is working properly. If necessary, see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Display text Proper response
Close side windows! Close the windows. Make sure the power windows are operating properly. If necessary, see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Error: convertible top Service!
See an authorized Volkswagen dealer or authorized Volkswagen Service Facility. The CSC roof will not go up or down if a system component malfunctions.
Error: Open convertible top! Open the CSC roof
Error: Close convertible top! Close the CSC roof
Low voltage: Please start engine! The vehicle battery is drained to the point that it cannot provide the power needed to completely open or close the CSC roof. Start the engine, by jump-starting if necessary. Open or close the CSC roof while the engine is running. Volkswagen recommends taking a longer drive afterwards to recharge the vehicle battery.
Temperature too high Sliding roof! or Temperature too high Convertible top!
Wait for a short time until the hydraulic and electrical unit cool down; they may have overheated. Opening and closing the CSC roof with great frequency may cause the hydraulic and electrical unit to overheat. Overload protection disables the roof until the unit cools down.
Convertible top open The message and an acoustic signal confirm that the CSC roof is completely open or closed.
Convertible top closed
Convertible top not functional. Owners Manual!
Check the outside temperature shown in the instrument cluster display. At temperatures below +5 °F (-15 °C) you can close the CSC roof, but not open it.
Have the system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. There is a malfunction in an ECU. It is not possible to open or close the roof. Use emergency procedure to close an open CSC roof if necessary

The instrument cluster displays and their arrangement may vary depending on the vehicle model and engine. For displays without warning and information messages, malfunctions are only signaled with indicator lights.

General information

Fig. 31 The CSC roof folds down into the luggage compartment when you open the roof (put the roof down).
