Opening the rear hatch from inside the luggage compartment

Fig. 173 Inside the luggage compartment: Opening the rear hatch.

Fig. 175 Hexagonal head screw for closing the power sunroof.

Emergency release for the selector lever

Fig. 176 Removing the selector gate cover.

Fig. 177 Releasing the selector lever lock.

WARNING
Never shift the transmission out of Park (P) without first firmly applying the parking brake.
Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause
an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the
vehicle is towed (or you let it coast) for an extended period or at high speed with the engine
shut off.

Vehicle tool kit

Storage

Fig. 178 In the luggage compartment: Floor covering raised and 1 secured.

Contents of the vehicle tool kit ⇒ fig. 179
(1) Screwdriver with a hexagonal socket in the handle for removing or inserting previously
loosened wheel bolts. The screwdriver blade is reversible. The screwdriver may be stored
under the lug wrench.
(2) Adapter for anti-theft wheel bolts. Volkswagen recommends that you always carry the adapter
for the wheel bolts in the vehicle along with the vehicle tool kit. The code number of the wheel
bolt lock is imprinted on the front of the adapter. If lost, a replacement adapter can be ordered
using this number. Record the code number of the wheel bolt lock and store it separate from
the vehicle.
(3) Screw-in towing eye.
(4) Hubcap puller clips for removing hubcaps, wheel covers, or wheel bolt caps.
(5) Jack. Before putting the jack back in the tool box, make sure to completely crank the jack down
to its original position. The crank must then be locked against the side of the jack; otherwise,
the jack will not fit and cannot be securely stowed.
(6) Lug wrench.

Wheel covers

Hubcaps

Fig. 180 Pulling off hubcap.

Fig. 181 Twisting off the hubcap.

Wheel covers

Fig. 182 Pulling the wheel cover off.
