VOLKSWAGEN GOLF 2015 5G / 7.G Owner's Manual

take the vehicle to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Main menu

x Vehicles with a multi-function steering wheel: Use the arrow up and down buttons (* and +) on
the right side of the steering wheel ⇒ fig. 15.
Trip memories
The display has 3 automatic memories:
x Since start
x Since refuel
x Extend. period
The currently selected memory is shown in the display.
The trip memories are in addition to the trip odometer, which is displayed in the bottom part of the
instrument cluster and controlled using the /./ button ⇒ fig. 10 (4).

Press the /+

Display Function
Travel time Driving time in hours (h) and minutes corresponding to trip memories 1, 2, and 3 (toggle).
Conv. consumer Displays any convenience equipment in the vehicle that is currently affecting fuel consumption.
Range  -- mi Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the cur-rent fuel consumption, among other things. Range  -- km
Avg. consumption --.- mpg Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1, 2, and 3 (toggle). For the since start trip memory, the value is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every second. Avg. consumption --.- l/100 km
Consumption --.- mpg Current fuel consumption in miles per gallon (l/100 km) while driving. When units are set to miles, dashes appear instead of a number when the engine is running and the vehicle is standing still. When units are set to kilometers, the display shows liters consumed per hour when the engine is running and the vehicle is standing still. Consumption --.- l/100 km
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h
--- mph Digital display of the current vehicle speed.
--- km/h
Average speed -- mph Average speed on trips per trip memories 1, 2, and 3 (toggle). For the since start trip memory, the value is displayed once the vehicle has been driven about 300 feet (100 m). The value displayed is updated every 5 seconds. Average speed -- km/h
Distance --- mi Distance driven in miles (km) per trip memories 1, 2, and 3 (toggle).
Distance --- km

Storing speed for the speed warning
x Select the Speed warning display.
x Press the /+

x To deactivate, press the /+

Infotainment system
Menu and system settings (SETUP)

After starting the engine with a discharged vehicle battery, or after the battery has been changed, system settings (time, date, and programming) may have been changed or deleted. Check and correct the settings as necessary once the vehicle battery has been sufficiently charged.
Vehicle settings menu

Menu Submenu Setting options See
Lights Light Assist Turn the following systems on or off: – Adaptive front lighting (AFS) (if equipped) – Automatic headlights during rain (head-lights turn on with rain sensor) – Convenience indicating (lane change feature)

Adjust the following feature: – Switch-on time for automatic headlights (!54/)
Interior lighting Adjust the following features: – Door ambient lighting – Footwell lighting
Coming/Leaving home function Set the following: – Duration that the Coming Home feature is switched on – Duration that the Leaving Home feature is switched on
Mirrors and wipers Windshield wipers Turn the following features on or off: – Automatic wiping during rain (rain sensor) – Wipe rear window in reverse gear

Open and close Window operation Turn convenience opening feature for the power windows on or off (if applicable).
Central locking Set door unlocking.
Turn the following features on or off: – Lock automatically (Auto lock feature) – Acoustic confirmation (horn beep after the vehicle is locked from outside)
Multifunction display (MFD) – Display or hide the following data in the Multifunction display: – Current fuel consumption – Average fuel consumption – Convenience consumers – Eco tips – Travel time – Distance traveled – Average speed – Digital speed display – Speed warning

– Reset the following data in the Multifunction display: – Driving data for “Since start” trip memory – Driving data for “Extended period” trip memory

Menu Submenu Setting options See
Time and date – Select and set the following data: – Clock time source (manual, GPS) – Time – Daylight savings time – Time zone – Time format (12 hour, 24 hour) – Date – Date format
–
Units – Set the units for the following: – Distance – Speed – Temperature – Volume – Consumption – Pressure
–
Service – Display the following data: – Vehicle identification number (VIN) – Date of next inspection service – Date of next oil change service

Factory settings – Reset the following features: – All settings – Parking aids – Lights – Mirrors and wipers – Open and close – Multifunction display
–

Volkswagen Car-Net: Connecting you and your vehicle
Applicable only in the United States

WARNING
Driver distraction causes accidents, collisions and serious personal injury! Using application software and Volkswagen Car-Net services while driving can distract the driver from traffic.
x Always drive attentively and responsibly.
Applicable only in the United States
Volkswagen Car-Net service
