VOLKSWAGEN GOLF GTI 2013 5G / 7.G Service Manual

Unlocking or locking the vehicle from the inside

Fig. 25 In the driver and front passenger doors: Power locking button.

Unlocking or locking vehicles with Keyless Access

Fig. 26 Ranges of the Keyless Access locking and starting system. Outside the vehicle: Unlocking range.
Inside the vehicle: Starting range.

Fig. 27 Keyless Access locking and starting system: Sensor for unlocking A on the inside of the front door
handles. Sensor for locking B on the outside of the front door handles.

All turn signals flash twice to confirm that the vehicle has been unlocked and once to confirm that it
has been locked.
If the vehicle was unlocked and within the next few seconds neither a door nor the rear hatch has
been opened, the vehicle is automatically locked again.
Unlocking and opening doors (Keyless Entry)
x Grasp the door handle of the driver or front passenger door so that you touch the unlocking sensor
surface (A).
x Open the door.
Closing and locking doors (Keyless Exit)
x Switch the ignition off.
x Close the driver door.
x Touch the sensor surface in the door handle on the driver or front passenger door (B). The vehicle
is locked. The door being locked must be closed.
Unlocking and locking the rear hatch
If the vehicle is locked and a valid remote control vehicle key is within range ⇒ fig. 26 of the rear hatch,
it unlocks automatically when opened.
x Open and close the rear hatch as you would a standard rear hatch
The rear hatch locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized remote control vehicle key is inside the vehicle.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from
the outside only if a second valid remote control vehicle key is within range.
When the vehicle is locked from the outside, the keyless go (starting) function of any keys left in the
passenger compartment will be deactivated. All other functions (remote central locking and unlocking
as well as emergency starting) remain active and unchanged.
A key that was inside the vehicle when it was locked from the outside is reactivated:
x by pressing a button on the deactivated key.
x by pressing a door handle sensor when the deactivated key is outside of the vehicle, but within
range.
x by starting the engine with the starter button.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the
passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or
hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are
switched off for a short time.
The door handle sensors become active again if one of the following events occurs:
x A short time has passed.
x OR: The vehicle is unlocked using the 1 button in the remote control vehicle key.
x OR: The rear hatch is opened.
x OR: The vehicle is mechanically unlocked with the vehicle key.

Convenience features
To use the convenience closing feature to close all power windows, hold your finger on the lock sensor
surface on the outside of the door handle for a few seconds until the windows close.
Remove your finger from the lock sensor surface ⇒ fig. 27 (B) to stop the function. If you touch the
unlock sensor surface (A) on the inside of the door handle immediately after releasing the lock sensor
surface (B) (arrow), all of the windows will open (safety function).
Pinch protection is active during convenience closing of the windows.
The settings in the Settings – Convenience menu .21 determine which doors open when the
door handle unlocking surface is grasped.
NOTICE
The door handle sensor surfaces can be activated by a strong stream of water or steam if a
valid vehicle key is within range of the vehicle.
x All windows may open if you turn the spray of water or steam away from and then back onto
the door handle sensor surface in quick succession. If at least one power window is opened
and the sensor is continuously activated, convenience closing is started.
The door may not open if the outside and inside door handles are used at the same time.
If the vehicle battery or the battery in the remote control vehicle key is weak or dead, it might not
be possible to unlock and lock the vehicle using Keyless Access. The vehicle can still be manually
locked or unlocked with the key bit
The driver message Key not in range appears in the instrument cluster display if there is no
remote control vehicle key inside the vehicle or if the system does not recognize the remote control
vehicle key. The key may not be recognized, for example, if it is covered by something that interferes
with the signal (such as a briefcase), or if the remote control vehicle key battery is weak. Electronic
devices such as cell phones can also interfere with the signal.
Dirt on the door handles that contains a lot of salt (especially in winter) can affect the way the
door handle sensors work. Cleaning the door handles can help with this problem
If the automatic transmission is not in Park (P) position, the electronic steering column lock will
not lock and the vehicle will not lock via sensors in the front door handles or the remote control vehicle
key.
Anti-theft alarm system

When is the alarm triggered?
The anti-theft alarm system sounds for about 30 seconds and the turn signals flash for up to 5 minutes
if the following occurs with respect to the locked vehicle:
x Opening a door that has been mechanically unlocked.
x Forcibly opening a door.
x Forcibly opening the engine hood.
x Forcibly opening the rear hatch.
x Switching on the ignition with an invalid key.
x Disconnecting the vehicle battery.
Deactivating the alarm
Unlock the vehicle with the unlock button on the remote control vehicle key or switch on the ignition
with a valid vehicle key.
For vehicles with Keyless Access, the alarm can be deactivated by grasping one of the front door
handles when a valid vehicle key is in range or by holding the remote control vehicle key to the right of
the steering column trim and pressing the starter button
After the alarm has stopped and the vehicle is opened again in the same or a different area that
is protected by the alarm, the alarm is triggered again. For example, the alarm will sound again if the
rear hatch is opened after one of the doors has been opened.
The anti-theft alarm system is not activated when the vehicle is locked with the power lock
switch 1on the inside of the driver or front passenger doors.
If the driver door is mechanically unlocked using the vehicle key bit, only the driver door is
unlocked, but not the entire vehicle. Switching on the ignition deactivates the anti-theft alarm system
and activates the central locking button. To unlock the doors, use the central locking button or remote
control vehicle key.
If the vehicle battery is dead or weak, the anti-theft alarm system will not work properly.

Doors
Introduction
In this section you’ll find information about:
Warning light
Child safety lock
More information:
x Exterior views
x Vehicle key set
x Power locking and closing system
x Power windows
x Emergency closing and opening
WARNING
A door that is not closed properly may open suddenly when the vehicle is moving and cause
severe injuries.
x Stop immediately and close the door.
x Make sure that the door is safely and completely latched when closed. The closed door
must be flush with the surrounding auto body parts.
x Open or close doors only if no one is in the way.
WARNING
A door kept open with the door stop may close in strong winds or on inclines and cause
injuries.
x Always hold doors by the door handle while opening and closing.
Child safety lock

Fig. 28 In the left rear door: Child safety lock A deactivated, B activated.

Fig. 29 In the right rear door: Child safety lock A deactivated, B activated.

Rear hatch
Introduction
In this section you’ll find information about:
Warning light
Opening the rear hatch
Closing the rear hatch
More information:
x Exterior views
x Power locking system
x Transporting
x Emergency closing and opening
WARNING
Accidents and severe personal injuries can result if you unlock, open, or close the rear hatch
when someone is in the way.
x Only open or close the rear hatch if no one is in the way.
x Never close the rear hatch by pushing on the rear window with your hand. The rear
window could break and cause injuries.
x After closing the rear hatch, always make sure that it is properly closed and locked so that
it cannot open suddenly when the vehicle is moving. The closed rear hatch must be flush
with the surrounding auto body parts.
x Always keep the rear hatch closed while driving to help keep poisonous exhaust gas from
being drawn into the vehicle.
x Never open the rear hatch when a luggage rack is installed and loaded. If, for example,
there are bicycles on a carrier on the rear hatch, it is possible that the rear hatch will be
difficult to open. An open rear hatch may fall on its own because of the additional weight. If
necessary, prop open the rear hatch. Remove the weight from the luggage rack first.
x Close and lock the rear hatch and all doors when the vehicle is not in use. First, make sure
that no one is left inside the vehicle.
x Never leave your vehicle unattended or let children play around your vehicle, especially
when the rear hatch is open. A child could crawl into the vehicle and pull the rear hatch shut,
becoming trapped and unable to get out. A closed vehicle can become very hot or very cold,
depending on the season. Particularly in the summer, heat build-up in the passenger and
luggage compartment of a parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures. Temperatures can quickly reach levels that can
cause unconsciousness and death, particularly to small children.
x Never leave children or anyone who cannot help themselves behind in the vehicle. They
may lock the vehicle with the vehicle key or the power locking button and lock themselves in.
NOTICE
Before opening or closing the rear hatch, make sure there is enough room to do so, as for
example when the vehicle has a trailer or is in a garage.

Opening the rear hatch

Fig. 30 In the remote control vehicle key: button to unlock and open the rear hatch.

Fig. 31 Opening rear hatch from the outside.

At temperatures below +32 °F (0 °C), the rear hatch may be difficult to open after you unlock it.
Closing the rear hatch

Fig. 32 Opened rear hatch: Recessed grips for closing.
