WARNING
Improper use of high beams can distract and blind others, causing accidents and serious injuries.
The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off ⇒ In an emergency.
The indicator light flashes twice as fast if a turn signal bulb is burned out.
High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 76 Headlight switch next to the steering wheel.

Fig. 77 Headlight switch next to the steering wheel (with fog lights and automatic headlights).

Adjust the light switch to the desired position ⇒ fig. 76 or ⇒ fig. 77:
Symbol When the ignition is switched off When the ignition is switched on
!54/ Orientation lighting may be switched on. Automatic headlights active; DRL on.
 Low beams switched off. The DRL may stay on. The length of time they stay on depends on the vehicle battery charge.
Low beams switched on.
\b Parking lights switched on. Parking lights switched on.
Fog lights switched off. The DRL may stay on for some time. Headlights and fog lights switched on.

Fog lights
The indicator light in the headlight switch shows that the fog lights are switched on.
x To switch on the fog lights : first turn the light switch to position , then pull the light switch out to the detent.
x To switch off the fog lights, push the switch back in from the first detent. To then turn off the headlights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the key out of the ignition and open the driver door. This is to remind you that lights are still on.
x Light switch in position \b.
WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be seen by others when it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright enough and will not let you see far enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on, a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlights (!54/) are switched on, the low-beam headlights may still not come on by themselves in fog or heavy rain. You have to switch on the low-beam headlights manually.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.

Applicable only in the United States
Lights and vision features

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for example when driving through a tunnel. If sufficient brightness is registered.
If the rain sensor recognizes rain and switches the windshield wipers on. If the windshield wipers have not moved for several minutes.

You can adjust the level of darkness the vehicle must register before automatically switching on the headlights in the Infotainment system by pressing the #!2 button followed by the function keys

Coming Home Action
Switch on: – Switch off the ignition The Coming Home feature is switched on when the headlight switch is in the !54/ position and the low-light sensor registers darkness The delay period starts once the last vehicle door or the rear hatch is closed.
Switch off: – Automatically after delay period is over. – Automatically, if a vehicle door or the rear hatch is still open about 30 seconds after activation. – Turn light switch to the / position. – Switch the ignition on.


Leaving Home Action
Switch on: – Unlock the vehicle if the light switch is in the !54/ position and the low-light sensor registers darkness.
Switch off: – Automatically after preset delay period is over. – Lock the vehicle. – Turn the light switch to the / position. – Switch the ignition on.

The length of time the lights stay on can be adjusted or the feature can be activated and deactivated in the Infotainment system by pressing the #!2 button followed by the

Instrument cluster and switch brightness
Depending on vehicle equipment, you can either adjust the brightness of the instrument cluster and
switch lighting by turning the thumbwheel ⇒ fig. 78 (1), or by pressing the #!2 button followed by the

Button Function
* Reading light on or off.


Glove and luggage compartment lights
The glove and luggage compartments may have lights that come on automatically when they are opened and go off when they are closed.
Ambient (background) lighting
When the ignition and headlights are switched on, the ambient lighting in the roof console lights up.
There may also be footwell lighting.
On appropriately equipped vehicles, you can adjust the brightness of the ambient lighting in the
Infotainment system by pressing the #!2 button followed by the

Sun protection

Windshield made of heat-insulating glass

Fig. 80 Heat-reflective windshield with communications window (blue shaded area).

Windshield wipers and washer
