Page 171 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Tread wear indicator (TWI) in the tire
The 1/16 in. (1.6 mm) high wear indicators are molded into the bottom of the tread grooves of the
original tires running across the treads ⇒ fig. 104. Seve

Page 172 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
steering and suspension systems. Have all wheels rebalanced. A wheel must always be rebalanced if a new tire has been mounted.
Wheel alignment – Incorrect wheel alignment causes excessive and une

Page 173 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Removing the spare wheel or compact spare wheel
�x Open the rear hatch, lift up the floor covering, and hook it in the stops on either side of the luggage
compartment ⇒ Storage.
�x If applicabl

Page 174 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
  WARNING
Improper use of a spare wheel or a compact spare wheel can cause loss of vehicle control, a crash or other accident, and serious personal injury.
�x Never use a spare wheel or compact sp

Page 175 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Tire labeling

Fig. 107 International tire labeling.
�

Page 176 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Tire labeling (example)   Meaning
XL   Indicates “reinforced” tire (heavy-duty)
M+S or M/S  Indicates Mud and Snow capability (also M/S) ⇒ Winter tires.
RADIAL TUBELESS   Tubeless radial

Page 177 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Tire labeling (example)   Meaning
TRACTION A   Traction rating under wet conditions (AA, A, B or C).
TEMPERATURE A  Temperature stability of the tire at increased test bench speeds (A, B or C).

Page 178 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Z   over 149 mph (240 km/h)
W   up to 168 mph (270 km/h)
Y   up to 186 mph (300 km/h)
Some tire manufacturers label tires with a maximum permissible road speed above 149 mph (240 km/h) with the l

Page 179 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
In appropriately equipped vehicles, the speed warning can be set and changed in the Infotainment
system by pressing the �#�!�2 button followed by the �

Page 180 of 400

VOLKSWAGEN GOLF PLUS 2015  Owner´s Manual
Compact spare wheel
For technical reasons, snow chains cannot be used on the compact spare ⇒ Spare wheel or compact spare wheel.
If you must use snow chains and have a compact spare wheel mounte
