center console VOLKSWAGEN GOLF SPORTWAGEN 2015 5G / 7.G Owners Manual

Upper center console

Fig. 6 Overview of the upper center console.
Key to fig. 6:
(1) Button for the emergency flashers
(2) PASSENGER AIR BAG /&&  light (front airbag for front seat passenger)
(3) Infotainment system
– User information display
– Radio ⇒ Booklet Radio, Navigation System
– Navigation system ⇒ Booklet Radio, Navigation System
(4) Controls for:
– Manual air conditioning
– Climatronic
(5) Air vents  –

Lower center console

Fig. 7 Overview of the lower center console.
Key to fig. 7:
(1) Lever for:
– Manual transmission
– Automatic transmission
(2) Parking brake lever
(3) Storage compartment with cup holders
(4) Storage compartment
– With AUX-in jack

Storage compartment in the front center console

Fig. 114 In the front center console: Storage compartment.

Some cup holder inserts can be removed for cleaning.
Cup holders in the front center console

Fig. 121 In the front center console: Cup holders.

12 Volt sockets in the vehicle

Fig. 123 12 Volt socket with cover flap 1, 12 Volt socket with pull-out cover 2.

Fig. 124 In the lower center console: 12 Volt socket.

To help prevent damage from voltage fluctuations, switch off all electrical devices connected to a 12 Volt socket before switching the ignition on or off or starting the engine.
The vehicle may have 12 Volt sockets at the following places:
x In the lower center console ⇒ fig. 124.
x In the luggage compartment ⇒ fig. 125.
x In the front center armrest storage compartment ⇒  Storage compartment in the front center arm-rest.
NOTICE
x Follow the manufacturer's instructions for connected devices!
x Never exceed the maximum power consumption, or the entire vehicle electrical system may be damaged.
x 12 Volt socket:
– Only use equipment that has been tested for electromagnetic compatibility and complies with applicable guidelines.
– Never feed current into the socket, with a solar panel, for example.
Unshielded devices may interfere with radio reception or the vehicle's electrical system.
115 Volt outlet in the vehicle

Fig. 125 In the luggage compartment: Covers for the 115 Volt outlet 1 (if equipped) and 12 Volt socket 2.

Fig. 126 In the rear center console: 115 Volt outlet with LED display.

WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked with the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
x Never remove the key from the ignition switch while the vehicle is moving or rolling to a stop. The steering wheel will lock and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position other than Park (P) when the ignition is switched off can drain the vehicle battery.
On automatic transmission vehicles, the vehicle key can be removed from the ignition switch only when the transmission is in Park (P). You may have to press the release button on the transmis-sion selector lever to put the lever into Park (P).
Starter button

Fig. 128 In the lower center console: Starter button for the Keyless Access system.

x If you continue driving closer to an object that the Park Distance Control has already de-tected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The system will no longer sound warn-ings about these objects. Ignoring signals from the Park Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumpers can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers clean and free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for exam-ple, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control system in a location or park-ing space with no traffic in order to become familiar with the system and how it works.
Operation

Fig. 149 In the front and rear bumpers: Park Distance Control system sensors.

Fig. 150 In the center console: Button to switch the Park Distance Control system on or off.

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal con-venience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Manual controls

Fig. 157 In the center console: Manual air conditioning controls.
