VOLKSWAGEN JETTA 2012 Owners Manual

The anti-theft alarm system, when installed, is not activated when the vehicle is locked manually with the key bit ,Anti-theft alarm system.
Manually locking the passenger doors

Fig. 150 On the front side of the right rear door: Emergency lock, covered by a rubber seal.

Fig. 151 On the front side of the right rear door: Locking the vehicle with the key bit in the vehicle key.

319
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
The vehicle doors can be unlocked and opened separately from inside the vehicle by pulling the door handle to open the door, Power locking and closing system.
Opening the luggage compartment lid from inside the luggage
compartment

Fig. 152 Behind the rear seat backrest: Release of the rear seat back.

Fig. 153 Opening the luggage compartment lid from inside the luggage compartment.

The release lever glows in the dark to help it be seen in low-light conditions.
Emergency release for the fuel filler flap

321
Before you try to use emergency closing procedures to close the power sunroof, please wait several minutes to make sure that the motor has not been temporarily turned off by the overheating protection feature.
If you must perform an emergency closing, please do so in the following order:
1. Remove the cover in direction of the arrow ⇒ fig. 154.
2. Insert a commercially available 1/6 in. (4 mm) Allen wrench6 into the hexagonal head screw
⇒ fig. 155 (1).
3. Turn the wrench counterclockwise to close the power sunroof.
4. Install the cover again.
5. Have the power sunroof checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Emergency closing may cause the power sunroof and its pinch protection to malfunction.
Emergency release for the selector lever lock

Fig. 156 Removing the selector gate cover.

Fig. 157 Releasing the selector lever lock.
6 Not included with the vehicle tool kit.

323
Vehicle tool kit

Storage

Fig. 158 In the luggage compartment under the floor panel: Compact spare wheel and vehicle tool kit.

325
Contents of the vehicle tool kit ⇒ fig. 159
(1) Screwdriver with a hexagonal socket in the handle for removing or inserting previously loosened wheel bolts. The screwdriver blade is reversible. The screwdriver may be stored under the lug wrench.
(2) Screw-in towing eye.
(3) Hubcap puller clip for removing hubcaps, wheel covers, or wheel bolt caps.
(4) Jack. Before putting the jack back in the foam insert, be sure to completely crank the jack down to its original position.
(5) Lug wrench.
(6) Crank.

Wheel trim

327
Hubcaps

Fig. 160 Pulling the hubcap off.

Fig. 161 Twisting the hubcap off.
