VOLKSWAGEN JETTA 2015 1B / 6.G Owner's Manual

Displaying a submenu
x Press the /+ button ⇒ fig. 16 to display submenu items. For instance, after scrolling to MFI data in the Settings main menu, press the /+ button to display items available under the MFI data submenu.
Selecting a setting
x Windshield wiper lever: Use the rocker switch ⇒ fig. 15 (2) on the windshield wiper lever to scroll through the available options, then press the /+

Menu Function See
Settings Includes various submenus and settings such as time, speed warning for winter tires, language, and units.
Basic and MFI menus (Multi-Function Indicator)

Display Function
 --- mi Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank.
 --- km
-- mi Distance driven in miles (km) per trip memories 1 and 2 (toggle).
-- km
ø -- mph Average speed on trips per trip memories 1 and 2 (toggle).
ø -- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
c --- mph Speed warning feature. When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual mes-sage may also appear in the instrument cluster display.  --- km/h

Possible MFI menu displays (Premium version)
The following displays can be accessed in the MFI menu if enabled under Settings > MFI data. Displays that are not enabled will not appear.

Display Function
Travel time Driving time in hours (h) and minutes (min) corresponding to trip memo-ries 1 and 2 (toggle).
Consumption --.- mpg Current fuel consumption in miles per gallon (l/100 km) while driving. When units are set to miles, dashes appear instead of a number when the engine is running and the vehicle is standing still. When units are set to kilometers, the display shows liters consumed per hour when the engine is running and the vehicle is standing still. Consumption --.- l/100 km
Av. consumption --.- mpg Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1 and 2 (toggle) is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds. Av. consumption --.- l/100 km
Range  -- mi Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the cur-rent fuel consumption, among other things. Range  -- km
Range b Diesel engines only: Estimated distance in miles (km) that the vehicle can go with the AdBlue left in the tank. Visible only when the AdBlue range has fallen to less than 1500 mi or 2400 km.

Display Function
Route -- mi Distance driven in miles (km) per trip memories 1 and 2 (toggle).
Route -- km
Average speed -- mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been driven about 300 feet (100 m). Until then, dashes may appear instead of a number. The value displayed is updated every 5 seconds. Average speed -- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature ---°F Current engine oil temperature.
Oil temperature ---°C
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h

Switching between the displays
x Use the arrow up and down buttons (* and +) on the multi-function steering wheel or use the 42)0
rocker switch on the windshield wiper lever ⇒ fig. 15 (2).
Storing speed for the speed warning
x Select the Speed warning or c display.
x Press the /+ button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel or use the 42)0
rocker switch ⇒ fig. 15 (2) to set a different speed within about 5 seconds. Then press the /+ button a second time or just wait a few seconds. The speed is saved and the warning is activated.
x To deactivate, toggle to Speed warning or c and press the /+ button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Select the trip memory to be erased.
x Press the /+ button for about 2 seconds.
Enabling and disabling displays (Premium version)
Use the Settings menu, submenu MFI data to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed can also be changed
⇒  Settings menu.

Settings menu

Lights & Vision menu Function
Coming Home Set how long the headlights and inside lights stay on after locking or unlocking the vehicle. Feature can also be switched on or off
Leaving Home
Back The display returns to the Settings menu.

Volkswagen Car-Net: Connecting you and your
vehicle

WARNING
Driver distraction causes accidents, collisions and serious personal injury! Using application software and Volkswagen Car-Net services while driving can distract the driver from traffic.
x Always drive attentively and responsibly.
Volkswagen Car-Net service

WARNING
Vehicle health reports do not replace the information provided by the vehicle warning and indicator lights. Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
x Before opening the engine hood, always switch off the engine and let the engine cool down.
x Always be very careful when working in the engine compartment, which is a potentially dangerous area in any motor vehicle and can cause serious personal injury.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Volkswagen collects, processes, transmits, uses and shares information about you and your vehicle in accordance with the Volkswagen Car-Net Terms of Service and Privacy Policy. See the Volkswagen Car-Net Terms of Service and Privacy Policy at http://www.vw.com/carnet for more de-tails.
Volkswagen Car-Net services use a system based on a wireless communication network. If all technical and other conditions are met and Volkswagen Car-Net still does not work properly, please try using the service again later.
Features

Safe & Secure:
Feature Description
Automatic Crash Notification (ACN)
Automatic Crash Notification is initiated in the event of airbag deployment or rollover. When the feature is activated the Volkswagen Car-Net Response Center is notified of your location and contacts your vehicle to determine the risk of injury and to dispatch help. Help is dispatched even if the Volkswagen Car-Net Response Center does not connect to the vehicle's occupants. Auto-matic Crash Notification may be engaged for up to 6 months without activating a trial or paid subscription.
Manual Emergency Call
In the case of an emergency, press the button in the 3-button module: The
Volkswagen Car-Net device initiates a connection to the Volkswagen Car-Net Response Center. The location of the vehicle and customer data for identifica-tion is sent at the same time.
Roadside Assis-tance
Press the > button in the 3-button module: The vehicle will connect directly to the Volkswagen Roadside Assistance Call Center. The vehicle’s location is also transmitted in order to more quickly provide assistance.
Stolen Vehicle Location Assis-tance For use by law enforcement au-thorities only. See Terms of Service at www.vw.com/carnet for details.
After you have reported your vehicle as stolen to law enforcement, you may provide the case information to the Volkswagen Car-Net Response Center. Once the information has been verified, the VW Car-Net Customer Specialist will be able to provide law enforcement with vehicle location data sent by the VW Car-Net module.


Family Guardian:
Feature Description
Boundary Alert
By logging on to your Volkswagen Car-Net account, you can designate an area on a map as a “virtual fence.” The vehicle owner can then choose notification channels (text message or email) for receiving alerts when the vehicle crosses the defined boundary (texts and data rates apply).
Speed Alert
Volkswagen Car-Net can be configured to inform the vehicle owner whenever the vehicle exceeds a speed set by the owner. The owner can select to be informed through multiple channels, including text messages and email (text and data rates apply).


Remote Vehicle Access:
Feature Description
