Fig. 165 In the engine compartment: Engine oil filler cap.

13. After adding oil, the level must at least be in the center of the ⇒ fig. 164 (C) range and can enter
range (B), but should never enter range (A) ⇒ .
14. After adding oil, securely install the cap on the engine oil filler opening. Otherwise, oil could leak out while the engine is running.
15. Insert the oil dipstick back in the guide tube and push it all the way in.
16. Close the hood ⇒ 
Engine oil level ranges

fig. 164 Required action according to the respective engine oil level:
Range (A) Do not start the engine ⇒ . Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Range (B) Do not refill oil ⇒ .
Range (C) You may add oil, as long as the oil level does not go above the (B) range.
Range (D) You must add oil (about 1 quart / 1.0 liter). After adding oil, make sure that the oil level is about in the middle of the (C) range.

WARNING
Engine oil can ignite when it touches hot engine parts. This can cause fires, burns, and other severe injuries.
x Never spill oil on the engine. Oil spilled on a cold engine can also cause a fire when the engine warms up.
x Always make certain that you screw the cap of the engine oil filler opening back on tightly after adding oil and that the dipstick has been pushed all the way back into the in the guide tube. This helps prevent engine oil from leaking onto the hot engine when the engine is run-ning.
NOTICE
x Do not start the engine if the engine oil level is in range (A). Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Otherwise the catalytic con-verter and engine can be damaged!
x When changing or topping off fluids, make sure that you pour the fluids into the correct reservoirs. Adding the wrong type of operating fluids will cause serious malfunctions and engine damage.
The engine oil level should never be in range (A). Otherwise oil can be drawn in by the crankcase ventilation system and enter the atmosphere via the exhaust system.

Engine oil consumption

WARNING
If you must change the engine oil yourself, be sure to take the following precautions:
x Always wear eye protection.
x To reduce the risk of burns from hot engine oil, let the engine cool down completely be-fore beginning.
x When removing the oil drain plug with your fingers, stay as far away as possible. Always keep your forearm parallel to the ground to help prevent hot oil from running down your arm.
x Drain the oil into a container designed for this purpose, one large enough to hold at least the total amount of oil in your engine.
x To reduce the risk of poisoning, never drain the oil into empty food or beverage contain-ers that might mislead someone into drinking from them.
x Engine oil is poisonous and must be stored out of the reach of children.
x Continuous contact with used engine oil is harmful to your skin. Always protect your skin by washing thoroughly with soap and water.
Before changing the oil, first make sure you know where you can properly dispose of the old oil.
Dispose of the old oil an environmentally-responsible manner. Never dump the old oil on garden soil, in wooded areas, in the street, into streams, rivers, or bodies of water, or down sewage drains.
Recycle used oil by taking it to a collection facility for used engine oil in your area, or contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Volkswagen recommends that you always have your oil and oil filter changed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. They have the required expertise and special tools and will dispose of the old oil properly.

Engine coolant

The following information applies to vehicles without an engine coolant temperature gauge. If your
vehicle is equipped with an engine coolant temperature gauge in the instrument cluster, see ⇒  Warn-ing light and engine coolant temperature gauge.
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
The following table explains what to do if the engine coolant temperature warning light ~ does not go out a few seconds after the engine is started or starts flashing while driving.

Flashes Possible cause Proper response
~
Engine coolant temperature too high.

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Warning light and engine coolant temperature gauge

Fig. 166 Engine coolant temperature gauge in the instrument cluster: A Engine cold; B Normal temperature range; C Warning zone.

Flashes
Temperature gauge needle
⇒ fig. 166
Possible cause Proper response
~
(C) Warning zone Engine coolant tempera-ture too high.

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Engine coolant specifications

Checking engine coolant level and topping off

Fig. 167 Coolant expansion tank in the engine compartment.

Fig. 168 Coolant expansion tank cap in the engine compartment.
