Using the instrument cluster menus

Fig. 15 On the right side of the steering column (vehicles without a multi-function steering wheel): Windshield wiper lever with controls for instrument cluster menus and displays.

Fig. 16 Right side of the multi-function steering wheel (if equipped): Controls for the menus in the instrument cluster display.

Display Function
Route -- mi Distance driven in miles (km) per trip memories 1 and 2 (toggle).
Route -- km
Average speed -- mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been driven about 300 feet (100 m). Until then, dashes may appear instead of a number. The value displayed is updated every 5 seconds. Average speed -- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature ---°F Current engine oil temperature.
Oil temperature ---°C
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h

Switching between the displays
x Use the arrow up and down buttons (* and +) on the multi-function steering wheel or use the 42)0
rocker switch on the windshield wiper lever ⇒ fig. 15 (2).
Storing speed for the speed warning
x Select the Speed warning or c display.
x Press the /+ button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel or use the 42)0
rocker switch ⇒ fig. 15 (2) to set a different speed within about 5 seconds. Then press the /+ button a second time or just wait a few seconds. The speed is saved and the warning is activated.
x To deactivate, toggle to Speed warning or c and press the /+ button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Select the trip memory to be erased.
x Press the /+ button for about 2 seconds.
Enabling and disabling displays (Premium version)
Use the Settings menu, submenu MFI data to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed can also be changed
⇒  Settings menu.

Tire inflation pressure label
A tire inflation pressure label is on the driver door jamb ⇒  Tires and wheels.
Fuel grade sticker
An information sticker listing the correct fuel grade for your vehicle ⇒  Refueling.
Engine data

Minimum turning circle diameter (wall to wall)1 about 36.4 ft (about 11.1 m)
Track1, front 60.1–60.7 in. (1527–1541 mm)
Track1, rear 59.9–60.6 in. (1523–1538 mm)
Ground clearance (unloaded)1 about 3.7–5.5 in. (about 94–139 mm)

NOTICE
x Please be careful when parking your vehicle in areas with parking barriers or curbs. These vary in height and could damage your bumper and related parts if the front of your vehicle hits a barrier or curb that is too high while you are getting into or out of a parking spot.
x Always be careful when you enter a driveway or drive up or down steep ramps or over curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).
1 Slight differences to these figures are possible, depending on wheel and tire size fitted and the equipment level selected.

WARNING
Always adjust seat, safety belts, and head restraints properly before driving and make sure that all passengers are properly restrained.
x Push the passenger seat as far back as possible. Always be sure that there are at least 10 inches (25 cm) between the front passenger's breastbone and the instrument panel.
x Always adjust the driver's seat and the steering wheel so that there are at least 10 inches (25 cm) between your breastbone and the steering wheel.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent. The distance to the instrument panel in the knee area must be at least 4 inches (10 cm).
x If these requirements cannot be met for physical reasons, contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to see whether adaptive equipment is available.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driv-er's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag in-flates.
x Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Never drive with backrests reclined or tilted back farther than necessary to drive comfort-ably. The farther back the backrests are tilted, the greater the risk of injury caused by incor-rect positioning of the safety belts and improper seating position.
x Never drive with the front seat passenger backrest tilted forward. If the front airbag de-ploys, the front backrest can be forced backward and injure passengers on the rear seat.
x Sit as far back as possible from the steering wheel and the instrument panel.
x Always sit upright with your back against the backrest with the front seats properly ad-justed. Never lean against or place any part of your body too close to the area where the air-bags are located.
x Rear seat passengers who are not properly seated and restrained are more likely to be seriously injured in a crash.
WARNING
Improper adjustment of the seats can cause accidents and severe injuries.
x Never adjust the seats while the vehicle is moving. Your seat may move unexpectedly and you could lose control of the vehicle. In addition, you will not be in the correct seating posi-tion while adjusting the seats.
x Adjust the front seat height, angle and longitudinal direction only if the seat adjustment area is clear.
x The adjustment of the front seats must not be restricted by things in the footwell in front or behind the seats.

WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when an airbag deploys and strikes a passenger in an improper seating position.
Proper seating position

Fig. 39 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 40 Proper safety belt positioning and head restraint adjustment.

For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions:
Applies to all vehicle occupants:
x Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of your head as close as possible to the head restraint ⇒ fig. 39 and ⇒ fig. 40.
x Push the head restraint completely down for short people, even if the top of the head is then below the upper edge of the head restraint.
x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly ⇒  Safety belts.
Driver - seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 39. When adjusting the proper distance to the steering wheel, grasp the top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the airbag is deployed.

x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒  Adjusting the front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are proper-ly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged.
Adjusting the steering wheel position

Fig. 47 Manual adjustment for the steering wheel position.

WARNING
Improper use of the steering column adjustment feature can result in serious personal injury and even death.
x Always pull the lever (1) firmly upward after adjusting the steering column so that the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that the steering wheel points toward your chest. Otherwise, the airbag system cannot protect you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of serious personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong way increases the risk of severe injury to the arms, hands, and head if the driver airbag de-ploys.
Center armrest

Fig. 48 Front center armrest.

The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off ⇒  In an emergency.
The indicator light flashes twice as fast if a turn signal bulb is burned out.
High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 79 Headlight switch next to the steering wheel.

Fig. 80 Headlight switch next to the steering wheel (with fog lights and automatic headlights, if equipped).
