Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Roof antenna
(3) Outside door handles
(4) Outside mirror
– Additional turn signal light
(5) Lift points for the jack

Front view

Fig. 2 Vehicle front overview.
Key to fig. 2:
(1) Inside mirror
(2) Front windshield
(3) Windshield wipers
(4) Engine hood
(5) Engine hood release
(6) Side marker lights
(7) Headlights
(8) Fog lights
(9) Front license plate bracket
(10) Threaded hole for the front towing eye (behind cover)

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Indicator light for anti-theft alarm system (if equipped)
(2) Door handle
(3) Power locking button for locking and unlocking the vehicle 0 – 1
(4) Switch for adjusting the outside mirror (equipment varies)
– Adjusting outside mirrors , – / – 2
– Outside mirror heating ?
(5) Lever for releasing the engine hood
(6) Luggage compartment release
(7) Bottle holder
(8) Storage compartment
(9) Reflector
(10) Buttons for operating the power windows
– Power windows
– Safety switch for rear power windows _

The instrument cluster display is divided into 3 parts. The time (digital clock) is displayed in the top part. The bottom part contains the odometer and the trip odometer (“trip”). You can select the following displays for the middle part:
Multi-Function Indicator (MFI)
▪ Travel time
▪ Consumption --.- mpg (l/100 km) (current fuel consumption)
▪ Av. consumption --.- mpg (l/100 km) (average fuel consumption)
▪ Range
▪ Route
▪ Average speed --- mph (km/h)
▪ xx mph (km/h) (digital speed display)
▪ Speed warning --- mph (km/h)
Audio ⇒ Booklet Radio or ⇒ Booklet Navigation system
Navigation ⇒ Booklet Navigation system
Phone ⇒ Booklet Mobile Phone Package
Assistants (if equipped)
▪ AFS
Vehicle status
Settings
▪ Language
▪ MFI data
– Travel time
– Curr. consum. (current fuel consumption)
– Av. consum. (average fuel consumption)
– Route
– Av. speed
– Digit. speed (digital speed display)
– Speed warn. (speed warning)
– Back
▪ Compass (vehicles without navigation system)
▪ Convenience
– ATA confirm
– Central locking
Auto unlock
Unlock doors
Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror adjust
Individually
Both mirrors
– Factory setting
– Back

Convenience menu Function
Unlock doors Doors are unlocked as follows depending on the option selected: – All doors: Pushing the unlock button 0on the remote control vehicle key unlocks all doors and the luggage compartment lid. – Single door: Pushing the unlock button 0on the remote control vehicle key unlocks only the driver door. To unlock all doors and the luggage compartment, push the unlock button 0 on the key a second time within about 5 seconds. On vehicles with Keyless Access, touching the sensor surface of the door handle on the side where the valid vehicle key is located unlocks the respective door – Veh. side: Pushing the unlock button 0 on the remote control vehicle key unlocks the doors on the driver side of the vehicle. On vehicles with Keyless Access, touching the sensor surface of a door handle on the side where the valid vehi-cle key is located unlocks the doors on that side of the vehicle.
Window op.
Off
Manual unlocking/locking: No windows open or close when the key is held in the unlocking or locking position. Keyless Access: No windows close when the locking sensor on the door handle is pressed and held (conven-ience closing)
All
Manual unlocking/locking: All windows open or close when the key is held in the unlocking or locking position. Keyless Access: All windows close when the locking sensor on the door handle is pressed and held.
Driver
Manual unlocking: The driver window opens when the key is held in the unlocking position. Manual locking: All windows close when the key is held in the locking position. Keyless Access: All windows close when the locking sensor on the door handle is pressed and held.
Back The display switches back to the Convenience menu.
Mirror adjust
Individually Both outside mirrors are adjusted separately.
Both mirrors The front passenger outside mirror is adjusted at the same time as the driver outside mirror.
Back The display switches back to the Convenience menu.
Factory setting Resets the features in the Convenience submenu back to the factory settings.
Back The display returns to the Settings menu.
Lights & Vision submenu

Mirrors

For example, visibility through the rear window could be impaired if there is a sunshade on the rear window or clothing on the luggage compartment cover, or if the rear window is covered with ice, snow, or dirt.
Manually adjustable inside mirror
x Home position: Lever on the bottom edge of the mirror points forward.
x To adjust to non-glare visibility, move the lever so that it points backward ⇒ fig. 81.
Outside mirrors

Fig. 82 In the driver door: Adjusting knob for the outside mirrors.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision. But vehicles or other objects seen in a convex mirror will look smaller and farther away than they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by pressing on the edges of the mirror surface.
