VOLKSWAGEN JETTA HYBRID 2013 1B / 6.G User Guide

Instrument explanations ⇒ fig. 10:
(1) Button for setting the instrument cluster clock1.
– With the ignition on, push the

x Warning and information texts
x Odometer displays
x Time
x Outside temperature
x Compass display
x Hybrid drive information
x Open door, engine hood, or luggage compartment lid ⇒ fig. 11.
x Selector lever position
x Multi-Function Indicator (MFI) and menus for different settings
x Service reminder display x Alternative speed display
(Settings menu) Compass

Fig. 12 Compass zones.

x Select the compass zone according to the current location ⇒ fig. 12.
x Adjust and confirm compass zone (1-15) by using the arrow buttons.
Calibrating the compass
In order to calibrate the compass, you need a valid compass zone for the location and enough room to
drive in a circle.
x Switch on the ignition.
x Select the Settings menu followed by the Compass and Calibrate menu items.
x Confirm the Please drive a full circle to calibrate message by pressing the OK
button on the multi-function steering wheel, and then drive in a complete circle at about 6 mph
(10 km/h).
During calibration, CAL is shown in the instrument cluster display. The calibration is complete when
the compass direction is displayed.
Service reminder display

Resetting the service reminder display
If the service was not performed by an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility, the service reminder can be reset as follows:

Vehicles with Premium text message display:
Select the Settings menu.
In the Service submenu, select the Reset menu item.
Confirm request with the OK button on the multi-function steering wheel.


Vehicles with Basic text message display:
Switch off the ignition.
Push the E

Volkswagen Information System

venience settings, and programming). Check the settings and correct as necessary once the vehicle
battery has built up a sufficient charge.
Applicable only in the United States
Menu structure – overview (Basic version)

â–ª Travel time
â–ª Consumption --.- mpg (l/100 km) (current fuel consumption)
â–ª Av. consumption --.- mpg (l/100 km) (average fuel consumption)
â–ª Range
â–ª Route
â–ª Average speed --- mph (km/h)
â–ª xx mph (km/h) (digital speed display)
â–ª Oil temperature
â–ª Speed warning --- mph (km/h)
Hybrid
Audio ⇒ Booklet Radio or ⇒ Booklet Navigation system
Navigation ⇒ Booklet Navigation system
Phone ⇒ Booklet Mobile Phone Package
Assistants (if equipped)
â–ª AFS
Vehicle status Settings
â–ª Language
â–ª MFI data
– Travel time
– Curr. consum. (current fuel consumption)
– Av. consum. (average fuel consumption)
– Route
– Av. speed
– Digit. speed (digital speed display)
– Oil temp.
– Speed warn. (speed warning)
– Back
â–ª Compass (vehicles without navigation system)
â–ª Convenience
– ATA confirm
– Central locking
Auto unlock
Unlock doors
Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror adjust
Individually
Both mirrors
– Factory setting
– Back
â–ª Lights & Vision
– Conv. turn sig. (convenience turn signal)

– Factory setting
– Back
â–ª Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
â–ª Snow tires (winter tires)
– On
– + 5 mph (10 km/h)
– - 5 mph (10 km/h)
– Back
â–ª Units
– Temperature
– Consump./dist.
– Back
â–ª Alt. speed dis. (alternative speed display On / Off)
â–ª Service
– Info
– Reset
– Back
â–ª Factory setting
Applicable only in the United States
Using the instrument cluster menus: Basic version

Fig. 13 On the windshield wiper control stalk: control buttons 1 and 2 on the windshield wiper lever.

The available displays are as follows:
I -- mi: Estimated distance you can drive with the fuel remaining in the tank.
Trip memory 1 (single trip memory) and trip memory 2 (total trip memory)
â–ª Push the /+

The available displays are as follows:
 -- km: Estimated distance you can drive with the fuel remaining in the tank.
Trip memory 1 (single trip memory) and trip memory 2 (total trip memory)
â–ª Push the /+
